Anti-Sloughing Drilling Fluid Technology for Deep Sidetracking Wells in the Tahe Oilfield
-
摘要: 塔河油田深部巴楚组和桑塔木组地层为以伊/蒙混层或伊利石为主的硬脆性泥页岩地层,水化分散性较强且发育有微裂缝,钻井过程中易因泥页岩水化而导致井壁失稳,为此,提出了"抑制表面水化-物化封堵-有效应力支撑"三元协同防塌对策,并构建了三元协同防塌钻井液。室内性能评价试验结果表明:三元协同防塌钻井液抗温达170℃、抗盐5.0%、抗钙0.5%~1.0%、抗劣土8.0%,泥页岩膨胀率和滚动回收率分别为5.05%和91.33%,能封堵宽400 μm的裂缝,承压能力达到4 MPa。三元协同防塌钻井液在塔河油田20余口井进行了应用,均未发生由于井壁失稳造成的井下故障,桑巴楚组和桑塔木组地层的井径扩大率平均降低63.4百分点,建井周期平均缩短4.3 d。这表明,三元协同钻井液防塌技术可有效解决塔河油田深侧钻井巴楚组和桑塔木组地层的井壁失稳问题。Abstract: The deep Bachu and Sangtamu Formation in the Tahe Oilfield are composed of an illite-montmorillonite mixed layer or hard brittle shale formations dominated by illite with strong water dispersion and development of micro-fractures.During drilling operations, wellbore instability can be encountered due to shale hydration.To eliminate these problems, a coordinated anti-collapse program with three elements was developed:sealing and consolidating the side well, inhibiting surface hydration and providing the effective stress support by reasonable drilling fluid density.In addition, anti-collapsing drilling fluids were developed.The evaluation results showed that the newly developed three-element anti-collapse drilling fluid had a temperature tolerance of 170℃, preferable contamination resistibility (5%NaCl, 0.5%-1% CaCl2, and 8% poor clay) strong anti-collapsing capacity (5.05% of shale swelling ratio and 91.33% rolling recovery rate) and favorable well-sealing performances (4 MPa of pressure-bearing capacity for 400 μm simulated fractures).Successful field applications were carried out in the Tahe Oilfield more than 20 wells.There were no downhole problems induced by wellbore instability.The average expansion rate was reduced by 63.4% compared with completed adjacent wells in the same block.The construction period was shorted by 4.3 d.Results showed that the wellbore instability problems of deep sidetracking wells in the Tahe Oilfield can be overcome through the effective deployment of a three-element anti-collapse drilling fluid technology.
-
-
[1] 李梦刚,楚广川,张涛,等.塔河油田优快钻井技术实践与认识[J].石油钻探技术,2008,36(4):18-21. LI Menggang,CHU Guangchuan,ZHANG Tao,et al.Application of optimum drilling techniques in Tahe Oilfield[J].Petroleum Drilling Techniques,2008,36(4):18-21. [2] 郭建国.塔河油田托普台地区钻井液技术[J].山东化工,2010,39(2):35-37. GUO Jianguo.Study on the drilling fluid technology in Tuoputai District of Tahe Oilfield[J].Shandong Chemical Industry,2010,39(2):35-37. [3] 路小帅,孙琳,王谱,等.塔河油田托甫台区复杂穿盐井快速钻井技术[J].石油机械,2014,42(12):1-5. LU Xiaoshuai,SUN Lin,WANG Pu,et al.Drilling techniques for the complicated through-salt layer well in Block Tuofutai of Tahe Oilfield[J].China Petroleum Machinery,2014,42(12):1-5. [4] 易浩,杜欢,贾晓斌,等.塔河油田及周缘超深井井身结构优化设计[J].石油钻探技术,2015,43(1):75-81. YI Hao,DU Huan,JIA Xiaobin,et al.The optimal design of a casing program for ultra-deep wells in the Tahe Oilfield and its periphery[J].Petroleum Drilling Techniques,2015,43(1):75-81. [5] 何伟国,唐明,吴柳根.塔河油田深层侧钻水平井膨胀套管钻井完井技术[J].石油钻探技术,2013,41(5):62-66. HE Weiguo,TANG Ming,WU Liugen.Expandable casing drilling and completion technology in deep sidetracked horizontal wells of Tahe Oilfield[J].Petroleum Drilling Techniques,2013,41(5):62-66. [6] 余福春.塔河油田超深侧钻水平井钻井技术研究与应用[J].石油天然气学报,2009,31(5):312-317. YU Fuchun.Research and application of drilling technology in ultra deep horizontal well in Tahe Oilfield[J].Journal of Oil and Gas Technology,2009,31(5):312-317. [7] BENAISSA S,CLAPPER D,PARIGOT P,et al.Oilfield applications of aluminium chemistry and experience with aluminum-based drilling fluid additive[R].SPE 37268,1997.
[8] CORRA C C,NASCIMENTO R.Study of shale-fluid interactions using thermogravimetry[J].Journal of Thermal Analysis and Calorimetry,2005,79(2):295-298.
[9] 王洪伟,黄治华,李新建,等."适度抑制"及"储层保护"钻井液的研制及应用[J].断块油气田,2014,21(6):797-801. WANG Hongwei,HUANG Zhihua,LI Xinjian,et al.Development and application of drilling fluid with moderate inhibitory and reservoir protection[J].Fault-Block Oil Gas Field,2014,21(6):797-801. [10] JIANG G,XUAN Y,LI Y,et al.Inhibitive effect of potassium methyl-siliconate on hydration swelling of montmorillonite[J].Colloid Journal,2014,76(4):408-415.
[11] EID H T.Factors influencing determination of shale classification indices and their correlation to mechanical properties[J].Geotechnical Geological Engineering,2006,24(6):1695-1713.
[12] 雷宗明.高陡构造地层钻井液密度的设计[J].大庆石油学院学报,1997,21(3):29-31. LEI Zongming.Drilling fluid density design for high inclined formation drilling[J].Journal of Daqing Petroleum Institute,1997,21(3):29-31. [13] 孔庆祥.泥浆动失水的试验研究[J].大庆石油学院学报,1985,9(4):64-72. KONG Qingxiang.Experimental study on dynamic water loss of mud[J].Journal of Daqing Petroleum Institute,1985,9(4):64-72. [14] 马海佳,张海军,张冶.基于THM的井壁稳定性分析[J].大庆石油学院学报,2008,32(6):50-55. MA Haijia,ZHANG Haijun,ZHANG Ye.Well bore stability analysis based on THM[J].Journal of Daqing Petroleum Institute,2008,32(6):50-55. [15] 黄荣樽,陈勉,邓金根,等.泥页岩井壁稳定力学与化学的耦合研究[J].钻井液与完井液,1995,12(3):15-21,25. HUANG Rongzun,CHEN Mian,DENG Jingen,et al.Study on shale stability of wellbore by mechanics coupling with chemistry method[J].Drilling Fluid Completion Fluid,1995,12(3):15-21,25. [16] 邱正松,徐加放,吕开河,等."多元协同"稳定井壁新理论[J].石油学报,2007,28(2):117-119. QIU Zhengsong,XU Jiafang,LV Kaihe,et al.A multivariate cooperation principle for well-bore stabilization[J].Acta Petrolei Sinica,2007,28(2):117-119. [17] 黄维安,邱正松,徐加放,等.吐哈西部油田井壁失稳机理实验研究[J].石油学报,2007,28(3):116-119. HUANG Weian,QIU Zhengsong,XU Jiafang,et al.Experimental study on sidewall instability mechanism of oil wells in the western Tuha Oilfield[J].Acta Petrolei Sinica,2007,28(3):116-119. [18] 胡友林,岳前升,刘书杰,等.BZ29-4S油田软泥页岩钻井液技术研究[J].石油天然气学报,2012,34(10):94-97. HU Youlin,YUE Qiansheng,LIU Shujie,et al.Drilling fluid technology of soft shale in BZ29-4S Oilfield[J].Journal of Oil and Gas Technology,2012,34(10):94-97. [19] 赵福麟.油田化学[M].青岛:中国石油大学出版社,2010:10-13. ZHAO Fulin.Oilfield chemistry[M].Qindao:China University of Petroleum Press,2010:10-13. [20] 徐同台,崔茂荣,王允良,等.钻井工程井壁稳定新技术[M].北京:石油工业出版社,1999:1-17. XU Tongtai,CUI Maorong,WANG Yunliang,et al.New technology of borehole stability in drilling engineering[M].Beijing:Petroleum Industry Press,1999:1-17. [21] 马超,赵林,宋元森.聚铝胺盐防塌钻井液研究与应用[J].石油钻探技术,2014,42(1):55-60. MA Chao,ZHAO Lin,SONG Yuansen.Research and application of anti-sloughing drilling fluid of poly aluminum-amine salt[J].Petroleum Drilling Techniques,2014,42(1):55-60. [22] 王沫,杜欢,伊尔齐木,等.顺南井区优快钻井技术[J].石油钻探技术,2015,43(3):50-54. WANG Mo,DU Huan,EERQM,et al.Optimal and fast drilling technology for Shunnan Block[J].Petroleum Drilling Techniques,2015,43(3):50-54. [23] 徐加放,邱正松.泥页岩水化应力模拟[J].大庆石油学院学报,2010,34(3):73-76. XU Jiafang,QIU Zhengsong.Laboratory simulation of shales hydration pressure[J].Journal of Daqing Petroleum Institute,2010,34(3):73-76. [24] 钟汉毅,邱正松,黄维安,等.胺类页岩抑制剂特点及研究进展[J].石油钻探技术,2010,38(1):104-108. ZHONG Hanyi,QIU Zhengsong,HUANG Weian,et al.Development and features of amine shale inhibitors[J].Petroleum Drilling Techniques,2010,38(1):104-108. [25] 钟汉毅,邱正松,黄维安,等.聚胺水基钻井液特性实验评价[J].油田化学,2010,27(2):119-123. ZHONG Hanyi,QIU Zhengsong,HUANG Weian,et al.Experimental evaluation on polyamine water-based drilling fluid[J].Oilfield Chemistry,2010,27(2):119-123. [26] 钟汉毅,黄维安,邱正松,等.新型两亲性低分子多胺页岩抑制剂的特性[J].东北石油大学学报,2012,36(5):51-55. ZHONG Hanyi,HUANG Weian,QIU Zhengsong,et al.Properties of a novel amphipathic low molecular weight multi-amine shale inhibitor[J].Journal of Northeast Petroleum University,2012,36(5):51-55. [27] 邱春阳,秦涛,司贤群,等.准中征沙村区块定向防塌钻井液技术[J].断块油气田,2015,22(5):664-667. QIU Chunyang,QIN Tao,SI Xianqun,et al.Anti-caving drilling fluid for directional well in Zhengshacun Oilfield,middle Junggar Basin[J].Fault-Block Oil Gas Field,2015,22(5):664-667. -
