塔河油田深层侧钻水平井膨胀套管钻井完井技术

何伟国; 唐明; 吴柳根

doi:10.3969/j.issn.1001-0890.2013.05.012

塔河油田深层侧钻水平井膨胀套管钻井完井技术

1.
中国石化西北油田分公司钻井完井工程管理处, 新疆乌鲁木齐 830011;
2.
中石化胜利石油工程有限公司钻井工艺研究院, 山东东营 257017

基金项目:

中国石化集团科技攻关项目"裸眼封堵等井径膨胀套管技术研究"(编号:JP11007)部分研究内容。

详细信息

作者简介:
何伟国(1967—),男,新疆乌鲁木齐人,1989年毕业于南京大学地质系找矿专业,高级工程师,现从事石油钻井和完井新技术推广及管理工作。

中图分类号: TE257⁺.9
计量
- 文章访问数: 3177
- HTML全文浏览量: 92
- PDF下载量: 3716
出版历程
- 收稿日期: 2013-06-19
- 修回日期: 2013-08-28
- 刊出日期: 1899-12-31

Expandable Casing Drilling and Completion Technology in Deep Sidetracked Horizontal Wells of Tahe Oilfield

1.
Drilling and Completion Engineering Department, Sinopec Northwest Oilfield Company, Urumqi, Xinjiang, 830011, China;
2.
Drilling Technology Research Institute, Sinopec Shengli Oilfield Service Corporation, Dongying, Shandong, 257017, China

摘要

摘要: 塔河油田奥陶系储层侧钻水平井受老井井身结构、地层及地质避水要求等的限制,需要提高造斜点至上部石炭系泥岩段地层,而该地层与奥陶系储层为2套不同的压力系统,因此如何有效封堵石炭系易塌地层,是高效开发该地区奥陶系剩余油的关键。采用膨胀套管充当技术套管封堵钻井复杂地层,通过优化井身结构及后续的钻井工艺,为解决塔河油田深层侧钻水平井钻井、完井难点提供了一套全新的方案。针对塔河油田φ177.8 mm套管深层开窗侧钻井的钻井、完井难点,通过深入分析研究膨胀套管管材和膨胀螺纹等关键问题,完善了深井膨胀套管的施工工艺和实施程序,探索出一套塔河油田深层侧钻水平井膨胀套管钻井完井技术。该技术在塔河油田现场试验3口井,开窗层位均位于石炭系地层,开窗点深于5 100 m,侧钻后在斜井段成功封堵裸眼复杂地层,实现了国产膨胀套管首次在裸眼定向井段的封堵应用,为钻井、完井中封堵复杂地层提供了新的技术手段。
- 膨胀套管 /
- 侧钻 /
- 水平井 /
- 祼眼 /
- 封堵 /
- 完井 /
- 塔河油田
Abstract: Restricted by the existent casing program,formation and the requirement to avoid acquifer,when sidetracking horizontal wells into Ordovician reservoir in Tahe Oilfield,the kickoff point must be moved up to upper Carboniferous mudstone formation.The two formations belong to different pressure systems,so how to effectively seal the Carboniferous unstable formation is the key for developing the Ordovician remaining oil efficiently.Using expandable casing as intermediate casing to seal complex formations during drilling,provides a new way to solve the problems encountered in sidetracking horizontal wells in Tahe Oilfield by optimizing the casing program and follow-up drilling process.According to the difficulties encountered in deep sidetracking from φ177.8 mm casing in Tahe Oilfield,through dissecting the key technologies of expandable casing,such as expandable pipes and expansion thread,the operation process and procedure of running expandable casing in deep wells were improved,finding out a set of drilling technology with expandable casing.The technology has been tested in 3 wells in Tahe Oilfield,in which the window were all at the Carboniferous layer below 5 100 m,the inclined segments after sidetracking sealed the complex formation successfully,realizing the first sealing with domestic expandable casing in open hole,providing a new technical means to seal complex formations during drilling.
- expandable casing /
- sidetracking /
- horizontal well /
- open hole /
- seal /
- well completion /
- Tahe Oilfield

HTML全文

参考文献(11)

[1]	余金陵,周延军,王锡洲.膨胀管技术的应用研究初探[J].石油钻探技术,2002,30(5):55-57. Yu Jinling,Zhou Yanjun,Wang Xizhou.Primary research on expandable tubular techniques[J].Petroleum Drilling Techniques,2002,30(5):55-57.
[2]	张建兵,练章华,贾应林.采用膨胀套管技术优化复杂深井超深井下部井身结构[J].石油钻采工艺,2008,30(4):1-4. Zhang Jianbing,Lian Zhanghua,Jia Yinglin.Optimization of bottom casing program of complicated deep and ultra-deep wells based on expandable casing techniques[J].Oil Drilling Production Technology,2008,30(4):1-4.
[3]	龙斌.实体膨胀管技术在塔河TK1051井的应用[J].西部探矿工程,2009,32(9):46-48. Long Bin.Solid expandable casing technology applied in TK1051 Well of Tahe Oilfield[J].West-China Exploration Engineering,2009,32(9):46-48.
[4]	吴福源,魏增红,柳涛,等.实体膨胀管补贴修井技术在江苏油田的应用[J].石油钻探技术,2008,36(1):80-82. Wu Fuyuan,Wei Zenghong,Liu Tao,et al.Application of solid expansion tube repairing technique in Jiangsu Oilfield[J].Petroleum Drilling Techniques,2008,36(1):80-82.
[5]	杨顺辉,黄永洪,陶兴华,等.可膨胀波纹管技术在韦 15-19 井的应用[J].石油钻探技术,2007,35(3):55-57. Yang Shunhui,Huang Yonghong,Tao Xinghua,et al.The application of expandable convoluted tubing technique in Well Wei 15-19[J].Petroleum Drilling Techniques,2007,35(3):55-57.
[6]	陶兴华,马开华,吴波,等.膨胀波纹管技术现场试验综述及存在问题分析[J].石油钻探技术,2007,35(4):63-66. Tao Xinghua,Ma Kaihua,Wu Bo,et al.Summary of expandable bellows field test and existing problem analysis[J].Petroleum Drilling Techniques,2007,35(4):63-66.
[7]	胡彦峰,涂玉林,陶兴华.φ149.2 mm膨胀波纹管在塔河油田侧钻井的应用[J].石油机械,2013,41(1):27-30. Hu Yanfeng,Tu Yulin,Tao Xinghua.Application of the φ149.2 mm expandable bellows in sidetracked wells of Tahe Oilfield[J].China Petroleum Machinery,2013,41(1):27-30.
[8]	唐明,王璐璐,马建忠,等.石油膨胀套管的力学性能及膨胀后的残余应力[J].西安交通大学学报:自然科学版,2010,44(7):90-94,113. Tang Ming,Wang Lulu,Ma Jianzhong,et al.Mechanical properties of expansion casing and residual stress after expansion[J].Journal of Xi’an Jiaotong University:Natural Science,2010,44(7):90-94,113.
[9]	杨进,龚龙祥,付建红,等.膨胀套管的弹塑性理论分析[J].石油钻探技术,2006,34(3):32-34. Yang Jin,Gong Longxiang,Fu Jianhong,et al.The elastic-plastic theoretic analysis of the expandable casing[J].Petroleum Drilling Techniques,2006,34(3):32-34.
[10]	唐明,吴柳根,赵志国,等.深层侧钻水平井膨胀套管钻井封堵技术研究[J].石油机械,2013,41(2):6-9. Tang Ming,Wu Liugen,Zhao Zhiguo,et al.Research on the technology of expandable casing drilling plugging for deep layer sidetrack horizontal well[J].China Petroleum Machinery,2013,41(2):6-9.
[11]	朱春林,刘爱民,赵志国.膨胀套管技术在塔河油田超深井侧钻井中的应用[J].科学技术与工程,2012,12(31):8384-8388. Zhu Chunlin,Liu Ai’min,Zhao Zhiguo.Application of expanding casing technique in Tahe Oilfield superdeep sidetracking well[J].Science Technology and Engineering,2012,12(31):8384-8388.
