Experimental Study of Combined-Jet PDC Bit
-
摘要: 为了将不同射流方式应用于PDC钻头以改变井底流场,并给钻头提供设计依据,通过数值模拟和室内试验分析了反向射流对井底流场的影响规律,并对旋转射流的破岩能力进行了评价。结果表明:PDC钻头加装反向射流喷嘴之后,钻头破岩部位压力降低,并且压降随着反向射流喷嘴距钻头底部距离的增大而减小,随反向射流流量的增大而增大,上部钻井液液柱压力对压降影响不大;在相同压降或排量下,旋转射流较普通直射流有更好的破岩能力。根据试验结论研制出了反向射流与旋转射流组合的PDC钻头,并在坨747井进行现场试验。结果表明,坨747井采用组合射流PDC钻头后,与采用普通PDC钻头的邻井相比,钻速提高40%以上。这表明,将反向射流和旋转射流组合应用于PDC钻头,可以明显提高机械钻速。Abstract: In order to apply different jet modes to PDC bits,numerical simulation and laboratory tests had been done to study the bottom-hole flow field affected by reverse jet.Rock breaking ability of swirling jet in the laboratory was evaluated,which could provide basis for bit design.The results showed that obvious pressure declined at rock breaking with backward jet nozzles on PDC.As the distance between reverse jet nozzle outlet and bit bottom decreased,and reverse flow rate increased and the degree of pressure drop increases at bottom holes.The pressure of drilling fluid column pressure had little effect on the pressure drop.Compared with conventional jet,swirling jet had better rock breaking ability at the same pressure drop and flow rate.According to the test results,a new combined-jet PDC bit,joining reverse jet and swirling jet,was developed and used on Well Tuo 747.The test results showed that it could improve ROP by more than 40% compared with the neighboring wells using conventional PDC bits.It was proved that the combination of reverse jet and swirling jet on PDC bit can improve ROP remarkably.
-
Keywords:
- combined jet /
- PDC bit /
- numerical simulation /
- penetration rate /
- Well Tuo 747
-
-
[1] 张志云,李根生,史怀忠,等.超深井水力脉冲空化射流钻井试验研究[J].石油钻探技术,2009,37(4):11-14. Zhang Zhiyun,Li Gensheng,Shi Huaizhong,et al.Experiment study on ultra-deep well hydraulic pulsating cavitating water jet drilling[J].Detroleum Drilling Techniques,2009,37(4):11-14. [2] 史怀忠,李根生,沈忠厚,等.水力脉冲空化射流发生器配合Power Ⅴ防斜打快技术[J].石油钻探技术,2009,37(1):14-17. Shi Huaizhong,Li Gensheng,Shen Zhonghou,et al.Application of hydraulic pulsation-cavitating generator with Power Ⅴ system in Well Fengcheng 1[J].Petroleum Drilling Techniques,2009,37(1):14-17. [3] 李根生,沈忠厚.高压水射流理论及其在石油工程中应用研究进展[J].石油勘探与开发,2005,32(1):96-99. Li Gensheng,Shen Zhonghou.Advances in researches and applocations of water jet theory in petroleum engineering[J].Petroleum Exploration and Development,2005,32(1):96-99. [4] 王学杰,李根生,康延军,等.利用水力脉冲空化射流复合钻井技术提高钻速[J].石油学报,2009,30(1):117-120. Wang Xuejie,Li Gensheng,Kang Yanjun,et al.Improvement of penetration rate with hydraulic pulsationg-cavitation jet compound drilling technology[J].Acta Petrolei Sinica,2009,30(1):117-120. [5] Veenhuizen S D,Kolle J J,Rice C C,et al.Ultrahigh pressure jet assist of mechanical drilling.SPE/IADC 37579,1997.
[6] 吴彬,周永霞.横向喷射水力学与椭圆切削齿技术相结合提高PDC钻头性能[J].国外石油机械,1998,9(2):17-22. Wu Bin,Zhou Yongxia.Improving the property of PDC bit with lateral-jet hydraulics and ellipse cutting teeth technique[J].Foreign Petroleum Machine,1998,9(2):17-22. [7] 孙伟良.钻头分流降低井底压力的研究.东营:中国石油大学(华东)石油工程学院,2009. Sun Weiliang.Mechanism study on the bottom-hole pressure reduction by drilling fluid shunt on bit.Dongying:China University of Petroleum(Huadong),School of Petroleum Engineering,2010. [8] 葛鹏飞.PDC钻头横向射流流场的实验研究.东营:中国石油大学(华东)石油工程学院,2007. Ge Pengfei.The experimental study on PDC bit lateral-jet flow field.Dongying:China University of Petroleum(Huadong),School of Petroleum Engineering,2007 [9] 杨永印,裴建忠,孙伟良,等.利用射流改进井底流场的研究:2010年钻井基础理论研究与前沿技术开发新进展学术研讨会,成都,2010-10-24-26. Yang Yongyin,Pei Jianzhong,Sun Weiliang,et al.Research on mechanism of improving bottom hole flow field by using jet:2010 Basic Drilling Theory and New Development of Frontier Technology Conference Papers,Chengdu,October 24-26,2010. [10] 杜玉昆,王瑞和,艾飞,等.切向注入式旋转射流喷嘴携岩能力研究[J].钻采工艺,2008,31(6):14-16. Du Yukun,Wang Ruihe,Ai Fei,et al.Study on cuttings-carrying capability of a tangential injection type of swirl jet nozzle[J].Drilling Production Technology,2008,31(6):14-16. [11] 王瑞和,周卫东,沈忠厚,等.旋转射流破岩钻孔机理研究[J].中国安全科学学报,1999,9(增刊1):1-5. Wang Ruihe,Zhou Weidong,Shen Zhonghou,et al.Study on mechanism of rock-breaking by swirling water jet[J].China Safety Science Journal,1999,9(supplement 1):1-5. [12] 曲洪娜,黄中伟,李根生,等.水平井旋转射流冲砂洗井水力参数设计[J].石油钻探技术,2011,39(6):39-43. Qu Hongna,Huang Zhongwei,Li Gensheng,et al.Hydraulic parameters of sand-flushing with rotating jets in horizontal well[J].Petroleum Drilling Techniques,2011,39(6):39-43. [13] 马清明,王瑞和.井底反向射流辅助破岩机理分析[J].钻采工艺,2008,31(1):44-45,65 Ma Qingming,Wang Ruihe,Mechanism analysis of bottom-hole reverse jet assist rock failure[J].Drilling Production Technology,2008,31(1):44-45,65
