Application of High Temperature Resisting sureshot-MWD in Xinggu 7 Block
-
摘要: 随着油田开发难度加大,高温高压深井、超深井也越来越多,普通随钻测量仪在高温高压环境下发生故障的概率很高,无法正常工作和保证测试的准确性、连续性。为了解决这个问题,引进了抗高温sureshot-MWD测量仪。该仪器设计工作温度可达175 ℃,由无刷电机正脉冲发生器、电池和探管组成,具有抗高温、设置灵活和可扩展的特点;仪器独特的旋转阀结构具有自动解卡功能,能够在含砂量3%的钻井液中正常工作。现场应用表明,抗高温sureshot-MWD在高温环境下工作正常,扩展成的LWD可以进行精确的地质导向,缩短了钻井周期,提高了油层钻遇率。
-
关键词:
- 水平井 /
- 抗高温 /
- 地质导向 /
- sureshot-MWD
Abstract: With the increasing of oilfield development difficulty,more and more high-temperature high-pressure (HTHP) deep wells and super-deep wells are being drilled.Common measurement while drilling (MWD) has high failure rate in HTHP environment,so it can not ensure the accuracy and continuity of measurement.In order to solve this problem,high temperature resisting sureshot-MWD is introduced.This measurement is designed to resist high temperature up to 175 ℃ and it is composed of brushless motor positive pulse generator,battery and probe.It features high temperature resistance,flexible setup and expandability.The unique rotary valve of sureshot-MWD has the function of automatic unfreezing and it can work normally in the intervals with sand content 3%.In field application,sureshot-MWD works normally in drilling high temperature intervals,the expanded LWD could realize accurate geo steering,which shortens drilling period and increases reservoir targeting ratio.-
Keywords:
- horizontal well /
- high temperature resistance /
- geo-steering /
- sureshot-MWD
-
-
[1] 刘修善,王继平.基于大地测量理论的井眼轨迹检测方法[J].石油钻探技术,2007,35(4):1-5.Liu Xiushan,Wang Jiping.A method for monitoring wellbore trajectory based on the theory of geodesy[J].Petroleum Drilling Techniques,2007,35(4):1-5. [2] 马天寿,陈平,黄万志,等.钻井井下工程参数测量仪研究进展[J].断块油气田,2011,18(3):389-392.Ma Tianshou,Chen Ping,Huang Wanzhi,et al.Research progress on measuring instrument for downhole drilling engineering parameters[J].Fault-Block Oil Gas Field,2011,18(3):389-392. [3] Liu Xiushan.Universal technique normalizes and plans various well-paths for directional drilling.SPE 142145,2011.
[4] Liu Xiushan,Shi Zaihong.Improved method makes a soft landing of well path[J].Oil Gas Journal,2001,99(43):47-51.
[5] Liu Xiushan.New techniques accurately model and plan 3D well paths based on formation’s deflecting behaviors.IADC/SPE 115024,2008.
[6] SY/T 5955—2004 定向井井身轨迹质量[S]. SY/T 5955—2004 Trajectory quality for directional wells[S]. [7] Albahlani A M,Babadagli T.A critical review of the status of SAGD:where are we and what is next?.SPE 113283,2008.
[8] Pratt C K,Hartmann R A.A magnetostatic well tracking technique for drilling of horizontal parallel wells.SPE 28319,1994.
[9] 刘传鹏,林承焰,赵玉华.樊107块特低渗透油藏有效开发技术讨论[J].断块油气田,2008,15(6):76-79.Liu Chuanpeng,Lin Chengyan,Zhao Yuhua.Effective development techniques of ultra-low permeability reservoir at Block Fan 107,Daluhu Oilfield[J].Fault-Block Oil Gas Field,2008,15(6):76-79. [10] 苏义脑.水平井井眼轨道控制[M].北京:石油工业出版社,2000:172-184.Su Yinao.Horizontal well trajectory control[M].Beijing:Petroleum Industry Press,2000:172-184. [11] Wade D,Herman D,Nees J M,et al.The ultrashort radius radial system applied to thermal recovery of heavy oil.SPE 24087,1992.
[12] 赵峰.超短半径侧钻分支水平井曙1-23-0370CH井设计与施工[J].石油钻采工艺,2009,31(6):37-39.Zhao Feng.Design and application of super-short radius side-tracking technology in Shu 1-23-0370CH multilateral horizontal well[J].Oil Drilling Production Technology,2009,31(6):37-39. [13] 秦绪英,肖立志,索佰峰.随钻测井技术最新进展及其应用[J].勘探地球物理进展,2003,26(4):313-322.Qin Xuying,Xiao Lizhi,Suo Baifeng.The development of logging-while-drilling and its application [J].Progress in Exploration Geophysics,2003,26(4):313-322. [14] 刘鹏飞,刘良跃,司念亭,等.随钻测压工具Geo Tap在渤中25-1油田E3S井的应用[J].石油钻探技术,2009,37(3):42-44.Liu Pengfei,Liu Liangyue,Si Nianting,et al.Application of Geo Tap in E3S Well of Bozhong25-1 Oilfield[J].Petroleum Drilling Techniques,2009,37(3):42-44. [15] 刘修善.定向钻井中方位角及其坐标的归化问题[J].石油钻采工艺,2007,29(4):1-5.Liu Xiushan.Naturalization of azimuth angles and coordinates in directional drilling[J].Oil Drilling Production Technology,2007,29(4):1-5.
