Development and Solution to the Coupling Model of the Productivity of Interbeded Reserviors in Stepped Horizontal Wells
-
摘要: 在阶梯井多个生产段同时对多个油层合采时产能预测难度较大。针对该问题,依据渗流力学、工程流体力学、油藏工程和数值分析有关理论,考虑油藏各向异性、渗流干扰、井筒管流压降和钻完井污染等因素,利用离散化处理方法,建立了阶梯井与薄互层油藏耦合的多层合采阶梯井产能计算模型,分析了该模型具有唯一解的充要条件,给出了求解方法。利用某三层薄互层油藏数据进行了实例计算,分析了井筒径向流率、井筒流量和井筒流压的分布规律,发现阶梯井生产过程中,井筒径向流率分布规律满足高阶偶次多项式,流量分布规律满足三次多项式,流压沿井筒呈抛物线状分布且越靠近跟端下降越快,并认为管流摩阻造成的压降和产量损失不可避免;将利用该模型计算的全井产量与Joshi公式的计算结果进行了对比,发现二者仅相差1.79%。研究表明,建立的多层合采阶梯井产能计算模型的计算结果合理,为相关产能预测提供了新方法。Abstract: It is difficult to forecast the production capacities of stepped horizontal wells when producing multiple reservoirs at multiple sections. On the basis of the relevant theories such as seepage mechanics, engineering fluid mechanics, reservoir engineering and numerical analysis, a new detailed coupled model of stepped wells and thin interbedded reservoirs was established by utilizing discretization processing and considering factors such as anisotropy, filtering interference, pipe flow pressure drop and contamination caused by drilling and/or completion. This productivity calculation model of multilayer commingled production of stepped wells has a unique solution. Taking a three thin interbedded reservoir as an example, we analyzed with this model the wellbore radial flow rate, wellbore flow and wellbore flow pressure distribution rules of stepped horizontal wells. Numerical simulation results showed that flow friction in the wells should not be overlooked, and the stepped horizontal well flow rate distribution presented the shape of a high-order polynomial, the flow rate distribution adhered to cubic polynomial law, flow pressure distribution stayed within parabolic limits, and pressure dropped faster at the heel section. The entire well production calculated by this model is just 1.79% less than Joshi’s. It demonstrated that the calculation results for production were reasonable and provided a new method for productivity prediction of stepped horizontal wells.
-
Keywords:
- stepped horizontal well /
- thin interbed /
- coupling /
- mathematical model /
- productivity forecast
-
-
[1] 冯志明,颉金玲.阶梯水平井钻井技术[J].石油钻采工艺,2000,22(5):22-26. Feng Zhiming,Jie Jinling.Stepped horizontal drilling technology[J].Oil Drilling Production Technology,2000,22(5): 22-26. [2] 王爱国,王敏生,牛洪波,等.深部薄油层、双阶梯水平井钻井技术[J].石油钻采工艺,2003, 25(2):5-8. Wang Aiguo,Wang Minsheng,Niu Hongbo,et al.Horizontal drilling technolngy of two-stage in deep thin reservoir[J].Oil Drilling Production Technology,2003,25(2): 5-8. [3] 荣宁,吴迪,韩易龙,等.微地震监测水驱前缘技术在哈得双台阶水平井的应用效果评价[J].大庆石油地质与开发,2006,25(2):94-96. Rong Ning,Wu Di,Han Yilong,et al.Application evaluation of microearthquake monitoring waterflood front technique used to double step horizontal wells in Hade Oilfield[J].Petroleum Geology Oilfield Development in Daqing,2006,25(2): 94-96. [4] 黄世军,程林松,赵凤兰,等.薄互层油藏中阶梯水平井产能评价模型研究[J].西南石油大学学报,2007,29(3):60-65. Huang Shijun,Cheng Linsong,Zhao Fenglan,et al.The productivity evaluation model of the stepped horizontal well in thin interbeded reservoirs[J].Journal of Southwest Petroleum University,2007,29(3): 60-65. [5] 陆程,丁一萍,关云东,等.双台阶水平井产能的确定方法[J].油气地质与采收率,2009,16(5):82-85. Lu Cheng,Ding Yiping,Guan Yundong,et al.The study on productivity of stepped horizontal well[J].Petroleum Geology and Recovery Efficiency,2009,16(5): 82-85. [6] 任岚,赵金洲,胡永全,等.断块油藏中阶梯水平井的渗流特性[J].石油学报,2011,32(1):107-112. Ren Lan,Zhao Jinzhou,Hu Yongquan,et al.Seepage characteristics of stepped horizontal wells in fault-block reservoirs[J].Acta Petrolei Sinica,2011,32(1): 107-112. [7] Joshi S D.Augmentation of well productivity with slant and horizontal wells (includes associated papers 24547 and 25308)[J].Journal of Petroleum Technology,1988,40(6): 729-739.
[8] 程林松.高等渗流力学[M].北京:石油工业出版社,2011:336-346. Cheng Linsong.Advanced percolation mechanics[M].Beijing: Petroleum Industry Press,2011: 336-346. [9] 刘想平,郭呈柱,蒋志祥,等.油层中渗流与水平井筒内流动的耦合模型[J].石油学报,1999,20(3):82-86. Liu Xiangping,Guo Chengzhu,Jiang Zhixiang,et al.The model coupling fluid flow in the reservoir with flow in the horizontal wellbore[J].Acta Petrolei Sinica,1999,20(3): 82-86. [10] Frick T P,Economides M J.State-of-the-art in the matrix stimulation of horizontal wells[J].SPE Advanced Technology Series,1996,4(1): 94-102.
[11] 熊友明,潘迎德.裸眼系列完井方式下水平井产能预测研究[J].西南石油学院学报,1997,19(2):42-46. Xiong Youming,Pan Yingde.Study on productivity prediction of the horizontal wells with open hole series of completion methods [J].Journal of Southwest Petroleum Institute,1997,19(2): 42-46. [12] Ouyang Liangbiao, Bill Huang W S.A comprehensive evaluation of well-completion impacts on the performance of horizontal and multilateral wells[R].SPE 96530,2005.
[13] 袁恩熙.工程流体力学[M].北京:石油工业出版社,1986:128-131. Yuan Enxi.Engineering fluid mechanics[M].Beijing: Petroleum Industry Press,1986: 128-131. [14] Ouyang Liangbiao,Arbabi Sepehr,Aziz Khalid.A single-phase wellbore-flow model for horizontal,vertical,and slanted wells[R].SPE 36608,1998.
[15] Ouyang Liangbiao,Aziz Khalid.A simplified approach to couple wellbore flow and reservoir inflow for arbitrary well configurations[R].SPE 48936,1998.
[16] 曾祥林,林玲,杜志敏,等.考虑井壁径向流入的大位移井井筒压降计算[J].西南石油学院学报,2002,24(6):40-43. Zeng Xianglin,Lin Ling,Du Zhimin,et al.Wellbore pressure drop calculation considering the radial inflow through wall in the extended reach well[J].Journal of Southwest Petroleum Institute,2002,24(6):40-43. [17] 耿正玲,崔传智,杨赤宸,等.各向异性油藏油水两相流水平井产能计算[J].石油天然气学报,2012,34(12):119-122,156. Geng Zhengling,Cui Chuanzhi,Yang Chichen,et al.Productivity calculation of horizontal well in two phase anisotropy reservoirs[J].Journal of Oil and Gas Technology,2012,34(12): 119-122,156. -
