Development and Application of Environment-Friendly Drilling Fluid GREEN-DRILL
-
摘要: 为了提高海上油气田钻井液的环保性能，在开发环保型高效封堵剂GS、水基润滑剂GL和水溶性抑制剂GG的基础上，研制出了环境友好型水基钻井液GREEN-DRILL。性能评价结果表明，水基钻井液GREEN-DRILL的基本性能稳定，抑制性能与聚合醇钻井液基本相当，其生物需氧量与化学耗氧量的比值为67.5%，对蒙古裸腹溞Ⅰ龄幼体72 h半数致死浓度大于60 000 mg/L，高于国家一级海域生物毒性容许值，符合国家一级海域排放标准。同时，在水中稀释后无油膜、无黑色漂浮物。渤海油田5井次的现场应用表明，水基钻井液GREEN-DRILL能解决渤海油田存在的渗漏和井漏问题，性能稳定，环保性能优良。Abstract: Water based drilling fluid GREEN-DRILL has been developed to improve environmental performance of offshore drilling operation through the development of highly efficient eco-friendly plugging agent(GS),water based lubricant(GL),and soluble inhibitor(GG).Lab evaluation tests indicated that the basic properties of the GREEN-DRILL was stable,its inhibition performance was equivalent to that of glycol drilling fluid,the ratio of biochemical oxygen demand to chemical oxygen consumption was 67.5%,and the 72 h median lethal concentration was more than 60,000 mg/L with larva of Mongolia bare abdomen I age,higher than the permissible value of biological toxicity for levelⅠsea area in China,and meeting the national discharge standard.On the other hand,there was not oil film and black floatage in the surface of GREEN-DRILL diluents fluid.Field application in Bohai Oilfield showed that water based drilling fluid GREEN-DRILL could solve the problem of leakage and lost circulation,with stable properties and environment friendly performance.
-
-
[1] 吴长勇,梁国昌,冯宝红,等.海洋钻井液技术研究与应用现状及发展趋势[J].断块油气田,2005,12(3):69-71. Wu Changyong,Liang Guochang,Feng Baohong,et al.Present state of offshore drilling fluid and its development direction[J].Fault-Block Oil Gas Field,2005,12(3):69-71. [2] Candler J E,Rushing J H,Leuterman A J J.Synthetic-based mud systems offer environmental benefits over traditional mud systems.SPE 25993,1993.
[3] 耿娇娇,鄢捷年,李怀科,等.具有恒流变特性的深水合成基钻井液[J].石油钻探技术,2010,38(2):91-94. Geng Jiaojiao,Yan Jienian,Li Huaike,et al.Synthetic-based drilling fluid with constant-rheology used in deepwater drilling[J].Petroleum Drilling Techniques,2010,38(2):91-94. [4] 胡友林,乌效鸣,岳前升,等.深水钻井气制油合成基钻井液室内研究[J].石油钻探技术,2012,40(6):38-42. Hu Youlin,Wu Xiaoming,Yue Qiansheng,et al.Laboratory research on deepwater GTL synthetic-based drilling fluid[J].Petroleum Drilling Techniques,2012,40(6):38-42. [5] 李自立,罗健生,田荣剑,等.适用于深水钻进的合成基液探索[J].钻井液与完井液,2012,29(6):1-3. Li Zili,Luo Jiansheng,Tian Rongjian,et al.Research on base oils of synthetic base drilling fluid used in deepwater drilling[J].Drilling Fluid Completion Fluid,2012,29(6):1-3. [6] 张琰,任丽荣.酯基钻井液物性及应用研究[J].石油大学学报:自然科学版,2001,25(5):117-119. Zhang Yan,Ren Lirong,Properties and application of ester-based drilling fluid[J].Journal of the University of Petroleum,China:Edition of Natural Science,2001,25(5):117-119. [7] 王西江,曹华庆,郑秀华,等.甲酸盐钻井液完井液研究与应用[J].石油钻探技术,2010,38(4):79-82. Wang Xijiang,Cao Huaqing,Zheng Xiuhua,et al.Study and application of drilling and completion fluid based on formate[J].Petroleum Drilling Techniques,2010,38(4):79-82. [8] 赵向阳,张小平,陈磊,等.甲酸盐钻井液在长北区块的应用[J].石油钻探技术,2013,41(1):40-44. Zhao Xiangyang,Zhang Xiaoping,Chen Lei,et al.Application of formate drilling fluid in Changbei Block[J].Petroleum Drilling Techniques,2013,41(1):40-44. [9] 耿晓光.甲酸盐钻井液体系在大庆开发井的推广应用[J].钻井液与完井液,2007,24(2):77-79. Geng Xiaoguang.Application of formate drilling fluids in development wells in Daqing Oilfield[J].Drilling Fluid Completion Fluid,2007,24(2):77-79. [10] Shyam Kumar Sharma,Jnan Kachari.Use of KCl-polymer clouding out polyol drilling fluid in combating high pressure in deep exploratory wells of Assam Field:a case study[R].SPE 128849,2010.
[11] GB/T 18420.2—2009 海洋石油勘探开发污染物生物毒性:第2部分:检验方法[S]. GB/T 18420.2—2009 Biological toxicity for pollutants from marine petroleum exploration and exploitation:part 2:test method[S]. [12] GB/T 18420.1—2009 海洋石油勘探开发污染物生物毒性:第1部分:分级[S]. GB/T 18420.1—2009 Biological toxicity for pollutants from marine petroleum exploration and exploitation:part 1:grading[S]. [13] API RP 13 B-1 Recommended practice for field testing water-based drilling fluids:fourth edition[S].
[14] 王奕,杨凤林,张兴文,等.化学品生物降解性的评价与预测[J].化工环保,2002,22(4):209-212. Wang Yi,Yang Fenglin,Zhang Xingwen,et al.Evaluation and prediction of biodegradability of chemicals[J].Environmental Protection of Chemical Industry,2002,22(4):209-212. [15] JJG 824—1993 生物化学需氧量(BOD5)测定仪[S]. JJG 824—1993 Biochemicaloxygen demand (BOD5) meter[S]. -
期刊类型引用(21)
1. 田文欣，俞浩杰. 页岩储层高性能环保型水基钻井液体系及其环境影响评价. 断块油气田. 2023(01): 38-43 .
百度学术
2. 母晓明. 环境友好型钻井液技术现状与发展趋势. 西部探矿工程. 2023(05): 55-57 . 百度学术
3. 雷志永，郭磊，耿铁，陈强. 环保型可循环利用BIODRILL A水基钻井液评价与应用. 中国海上油气. 2022(03): 139-145 . 百度学术
4. 邱春阳，王其星，杨世鑫，张翔宇. 富源201–3X超深定向井钻井液技术. 石油地质与工程. 2021(04): 98-101 . 百度学术
5. 刘均一，郭保雨，王勇，柴金鹏，陈二丁. 环保型水基钻井液在胜利油田的研究与应用. 钻井液与完井液. 2020(01): 64-70 . 百度学术
6. 王兰，吴琦，蒋官澄. 改性大豆卵磷脂在水基钻井液中的润滑性能. 钻井液与完井液. 2019(01): 10-14 . 百度学术
7. 吴梦欣，马建中，田振华，吕斌. 不同醛Mannich改性丙烯酸树脂及其应用性能研究. 中国皮革. 2019(03): 21-27 . 百度学术
8. 蒲磊，许明标，王朝飞，陈侃，周姗姗. 生态钻井液研制及其盐碱地改良效果研究. 钻井液与完井液. 2019(05): 587-593 . 百度学术
9. 郭浩，同武军，汪俊锋，张帅杰，刘贤玉. 大位移井水基钻井液适用性研究. 化学工程与装备. 2018(08): 101-102 . 百度学术
10. 秦岩. 新型环保水基钻井液应用实践. 西部探矿工程. 2018(09): 39-41+45 . 百度学术
11. 吕斌，李鹏飞，高党鸽，李蕊，陈学森. 水性环氧树脂在制革复鞣中的应用. 中国皮革. 2018(02): 15-21+27 . 百度学术
12. 赵小平，孙强. 环境友好型水基钻井液技术研究新进展. 山东化工. 2018(20): 52-53 . 百度学术
13. 陈二丁，王金利，张海青，杨倩云. 环保型水基钻井液体系的研究与应用. 中国石油大学胜利学院学报. 2018(03): 39-42 . 百度学术
14. 刘均一. 高性能环保水基钻井液技术研究新进展. 精细石油化工进展. 2018(06): 29-34 . 百度学术
15. 金军斌. 钻井液用润滑剂研究进展. 应用化工. 2017(04): 770-774 . 百度学术
16. 潘丽娟，孔勇，牛晓，钱晓琳，金军斌. 环保钻井液处理剂研究进展. 油田化学. 2017(04): 734-738 . 百度学术
17. 金军斌. 塔里木盆地顺北区块超深井火成岩钻井液技术. 石油钻探技术. 2016(06): 17-23 . 本站查看
18. 魏殿举，金军斌，何青水. YD油田高渗灰岩储层水平井钻井液技术. 石油钻探技术. 2015(03): 23-28 . 本站查看
19. 侯杰，刘永贵，李海. 高性能水基钻井液在大庆油田致密油藏水平井中的应用. 石油钻探技术. 2015(04): 59-65 . 本站查看
20. 赵欣，邱正松，高永会，张永君，马永乐，刘晓栋. 缅甸西海岸深水气田水基钻井液优化设计. 石油钻探技术. 2015(04): 13-18 . 本站查看
21. 覃勇，黄平，万伟. 环境友好型聚合物钻井液抑制剂的室内研究. 钻井液与完井液. 2015(05): 37-40+103 . 百度学术
其他类型引用(4)
