Study and Field Test of Drilling Fluid with Constant Rheology at High Temperature in West Yueman Block, Tarim Oilfield
-
摘要: 塔里木油田跃满西区块深部地层钻井液安全密度窗口窄，易出现井漏、井塌、卡钻和盐水侵等井下复杂情况，目前所用钻井液存在高温增稠、抗CO32–/HCO3–和劣质土污染能力差等问题。为解决这些问题，研究了以抗高温聚合物降滤失剂APS220和新型高温稳定剂HTS220为主剂的高温恒流变钻井液，在试验分析主要试剂性能的基础上确定了基本配方。通过室内试验，评价了该钻井液的高温恒流变性、抗CO32–/HCO3–污染性能和抗钠膨润土污染性能，试验发现，其100与180 ℃时的塑性黏度比值为1.3，动切力比值为1.5，初切力比值为1.7，终切力比值为1.2，随温度升高各流变参数的变化幅度明显低于常用钻井液，可抗2.0%的CO32–/HCO3–复合污染、10.0%的钠膨润土污染。高温恒流变钻井液在跃满西区块2口井现场试验中，流变性能稳定，钻后井眼畅通，减少了井下复杂情况，取得了显著效果。Abstract: Safe density window of drilling fluids in the deep formations of the West Yueman Block in Tarim Oilfield is narrow, and as a result, downhole complications such as lost circulation, well collapse, drill string sticking, and salt water contamination are frequently encountered. Some drawbacks exist in available drilling fluids including thickening at high temperature and a weak resistance to pollution by CO32–/ HCO3– and poor quality soil. In this paper, a drilling fluid with constant rheology at high temperature was studied, with a high-temperature-resistant polymer fluid loss additive (APS220) and a new high-temperature stabilizer (HTS220) as the base. The basic formula was determined on the basis of the performance analysis of the main agents. Laboratory tests were performed to evaluate the constant rheology at high temperature and the resistance to CO32– / HCO3– and sodium bentonite pollution of the drilling fluid. The results showed that, the drilling fluid had a plastic viscosity ratio of 1.3, dynamic shear ratio of 1.5, initial shear ratio of 1.7 and final shear ratio of 1.2 at 100 °C and 180 °C. As temperatures rose, it presented a variation range of rheological parameters significantly lower than that of other commonly used drilling fluids, with the resistance to pollution by 2% CO32– / HCO3– and 10% sodium bentonite. In the field test of two wells in the West Yueman Block, the drilling fluid demonstrated stable rheological properties, with smooth drilled borehole and considerable downhole complication reduction.
-
-
表 1 APS220性能评价结果
Table 1 Performance evaluation of APS220
配方 塑性黏度/
（mPa·s）动切力/Pa 旋转黏度计读数 静切力/Pa API滤失量/
mL高温高压
滤失量/mLpH值 试验条件 ϕ6 ϕ3 初切 终切 1# 28 4.0 2.0 1.0 1.0 8.0 1.4 12.0 10.5 热滚前 35 10.0 13.0 12.0 6.0 20.0 2.6 22.0 8.5 热滚后 2# 25 2.0 1.0 0.5 0.5 4.0 1.6 14.2 10.5 热滚前 31 6.5 8.0 7.0 3.0 12.0 3.2 26.0 9.0 热滚后 注：热滚条件为180 ℃×16 h，流变性能测试温度为60 ℃，高温高压测试温度为180 ℃。
下载: 导出CSV
表 2 HTS220性能评价结果
Table 2 Performance evaluation of HTS220
HTS220
加量，%塑性黏度/
（mPa·s）动切力/
Pa旋转黏度计读数 静切力/ Pa API滤失量/
mL高温高压
滤失量/mLpH值 试验条件 ϕ6 ϕ3 初切 终切 0 25 2.0 1.0 0.5 0.5 4.0 1.6 14.2 10.5 热滚前 31 6.5 8.0 7.0 3.0 12.0 3.2 26.0 9.0 热滚后 0.5 24 2.5 2.0 1.0 1.0 4.0 1.6 14.0 10.0 热滚前 28 5.5 7.0 6.0 3.0 10.0 3.6 25.4 9.0 热滚后 1.0 20 4.0 3.0 2.0 2.0 9.0 1.3 13.2 9.5 热滚前 18 3.0 3.0 2.0 2.0 8.0 3.4 18.4 7.5 热滚后 2.0 20 2.0 2.0 1.0 1.5 4.5 1.2 12.6 9.5 热滚前 15 2.0 2.0 1.0 1.5 6.0 3.2 15.8 7.5 热滚后 2.5 22 2.5 2.0 1.5 2.0 6.0 1.2 12.8 9.5 热滚前 18 3.0 3.0 2.0 2.0 6.5 3.1 16.0 7.5 热滚后 注：热滚条件为180 ℃×16 h，流变性能测试温度为60 ℃，高温高压测试温度为180 ℃。
下载: 导出CSV
表 3 不同温度下高温恒流变钻井液的流变性评价结果
Table 3 Rheological properties at different temperatures of the drilling fluid with constant rheology at high temperature
热滚温度/
℃塑性黏度/
（mPa·s）动切力/
Pa旋转黏度计读数 静切力/ Pa API滤失量/
mL高温高压
滤失量/mLpH值 ϕ6 ϕ3 初切 终切 室温 20 2.0 2 1 1.50 4.50 1.2 9.5 100 20 3.0 4 3 2.50 7.00 1.0 4.2 9.5 120 18 2.5 3 2 1.75 6.00 1.4 4.6 9.0 140 18 3.0 3 2 2.00 6.00 2.2 8.5 8.5 160 17 3.5 3 2 2.00 6.50 2.6 12.2 7.5 180 15 2.0 2 1 1.50 6.00 3.2 15.8 7.5 注：热滚时间16 h，热滚后测试温度60 ℃，高温高压测试温度跟热滚温度一致。
下载: 导出CSV
表 4 高温恒流变钻井液抗CO32–/HCO3–污染性能评价结果
Table 4 Resistance of the drilling fluid with constant rheology at high temperature to CO32–/HCO3– pollution
试验配方 塑性黏度/
（mPa·s）动切力/
Pa旋转黏度计读数 静切力/ Pa API滤失量/
mL老化条件 ϕ6 ϕ3 初切 终切 基浆 20 2.0 2 1 1.5 4.5 1.2 热滚前 18 3.0 3 2 2.0 6.0 2.2 热滚后 基浆+1.0%Na2CO3 18 6.5 10 9 5.0 10.0 1.8 热滚前 20 7.0 10 9 5.0 8.5 2.6 热滚后 基浆+1.0%NaHCO3 19 4.5 5 4 3.5 9.0 1.0 热滚前 17 3.0 4 3 2.5 6.0 3.2 热滚后 基浆+1.0%Na2CO3 +1.0%NaHCO3 23 9.0 13 12 6.0 10.5 2.0 热滚前 27 9.5 15 13 6.5 12.0 4.2 热滚后 基浆+1.0%Na2CO3 +1.0%NaHCO3+
1.0%HTS220+0.5%CaO21 5.0 4 3 2.0 10.0 1.8 热滚前 17 3.0 3 2 2.0 8.0 3.8 热滚后 基浆+1.0%Na2CO3+ 1.0%NaHCO3+0.5%CaO 18 5.0 6 5 3.5 12.0 2.4 热滚前 23 8.0 10 8 6.0 15.0 4.0 热滚后 注：基浆即高温恒流变钻井液基本配方，下同；热滚条件为140 ℃×16 h。
下载: 导出CSV
表 5 高温恒流变钻井液抗钠膨润土污染性能评价结果
Table 5 Resistance of the drilling fluid with constant rheology at high temperature to sodium bentonite
钠膨润土加量，% 塑性黏度/
（mPa·s）动切力/
Pa旋转黏度计读数 静切力/ Pa 老化条件 ϕ6 ϕ3 初切 终切 0 20 2.0 2 1 1.5 4.5 热滚前 18 3.0 3 2 2.0 6.0 热滚后 5 21 3.5 4 3 2.0 7.5 热滚前 17 3.0 3 2 2.0 6.0 热滚后 10 22 4.0 4 3 2.0 9.0 热滚前 19 4.5 5 4 3.0 8.0 热滚后 注：老化条件140 ℃×16 h，测试温度60 ℃；关于钠膨润土加量，基浆用体积计算，加入的钠膨润土以质量计算。
下载: 导出CSV
表 6 YM21X井实钻钻井液性能
Table 6 Performance of the drilling fluid in Well YM21X
井深/m 密度/
（kg·L–1）漏斗黏度/
s塑性黏度/
（mPa·s）动切力/
Pa静切力/Pa API滤失量/
mL离子质量浓度/（mg·L–1） 初切 终切 Cl– Ca2+ CO32– HCO3– 6 128.00 1.41 56 30 5.0 1.0 7.5 4.6 27 106 148 1 920 1 830 6 139.97 1.42 88 41 10.0 8.5 24.0 5.8 36 141 87 3 840 5 856 6 377.00 1.42 65 35 6.0 1.5 7.0 7.6 34 636 0 2 160 6 832 6 419.98 1.43 108 43 12.0 6.0 23.0 8.4 30 620 0 4 200 5 185 6 613.00 1.43 63 30 7.5 4.5 20.0 5.6 33 632 0 4 080 4 148 6 705.14 1.43 76 37 8.5 9.0 26.0 6.4 33 130 0 3 600 6 100 7 030.00 1.45 54 30 4.5 1.0 10.0 4.0 45 679 462 1 800 3 660 7 510.00 1.45 56 29 5.5 1.0 11.0 2.8 47 185 372 1 500 2 928 注：井温梯度为2.0 ℃/100m。
下载: 导出CSV
表 7 YM20X井实钻钻井液性能
Table 7 Performance of the drilling fluid in Well YM20X
井深/m 密度/
（kg·L–1）漏斗黏度/
s塑性黏度/
（mPa·s）动切力/
Pa静切力/Pa API滤失量/
mL离子质量浓度/（mg·L–1） 初切 终切 Cl– Ca2+ 5 969.00 1.29 59 31 9.0 2.0 8.0 4.4 27 000 480 6 706.00 1.42 62 28 8.0 2.0 11.0 4.4 34 000 120 7 226.00 1.46 58 27 5.5 1.5 8.0 3.2 36 000 300 7 458.00 1.46 59 30 6.0 1.5 6.0 3.0 31 000 200 7 479.00 1.46 56 23 8.0 2.0 8.0 2.4 30 700 120 注：YM20X井三开钻井液中CO32–质量浓度为1 800～2 880 mg/L，HCO3–质量浓度为2 196～4 880 mg/L。
下载: 导出CSV
-
