Correction Methods for Axial Magnetic Interference of the Magnetic Inclinometer while Drilling
-
摘要: 针对磁力随钻测斜仪在受到轴向磁干扰时会出现方位角测量结果不准确的问题，在介绍磁力随钻测斜仪测量原理的基础上，研究了Russell法和短钻铤测量修正法2种间接磁干扰校正方法的原理及迭代计算过程，提出了矢量和法和钻具截面法2种直接磁干扰校正方法，并对这4种方法进行了数据仿真分析。数据仿真结果表明，直接校正方法计算简单，但具有一定的局限性；间接校正方法计算复杂，但具有较好的准确性。在其他井眼参数不变的条件下，方位角偏差随干扰磁场增强而增大；在轴向干扰磁场固定的情况下，方位角偏差随井斜角增大而增大，井斜角相同时，0°~360°范围内方位角偏差先增大后减小，呈现对称性；井眼轨迹接近水平东西方向时，轴向磁干扰的校正效果最差。4种校正方法均可以降低轴向磁干扰对方位角测量精度的影响，减少无磁钻铤的使用长度，具有较好的现场实用性。Abstract: When the magnetic inclinometeris subjected to axial magnetic interference while drilling,the measured azimuth is inaccurate.To deal with this problem,the measurement principle of magnetic inclinometer while drilling was introduced.Then,the principle and iterative calculation process of two indirect magnetic interference correction methods(i.e.,the Russell method and the short drill collar measurement correction method)were analyzed,and two direct magnetic interference correction methods(i.e.,vector sum method and drilling tool section method)were proposed.And finally,numerical simulations were performed for these four methods.Results indicated that direct correction methods are simple,but their calculation is limited in several ways.Indirect correction methods are complicated,but their calculation accuracy is higher.Meanwhile,the azimuth deviation increases with the increase of the interference magnetic fields while the other borehole parameters are unchanged.When the axial interference magnetic field is fixed,the azimuth deviation increases when the inclination angle increases.When the inclination angle is the same,the azimuth angle increases first and then decreases in the range of 0°-360°,revealing the symmetry.When the well trajectory is close to horizontal EW orientation,the correction effect of axial magnetic interference is the worst.All the four correction methods can be better applied in field. They can decrease the influence of axial magnetic interference on the measurement accuracy of the azimuth angle and reduce the service length of non-magnetic drill collar.
-
-
[1] 石在虹,滕少臣,刘子恒.国际地磁参考场解算方法及石油工程应用[J].石油钻采工艺,2016,38(4):409-414. SHI Zaihong,TENG Shaochen,LIU Ziheng.Algorithm for international geomagnetic reference field and its application in petroleum engineering[J].Oil Drilling Production Technology,2016,38(4):409-414. [2] 曹向峰,管志川,王智锋,等.煤层气连通井导向钻井钻头定位方法[J].石油钻采工艺,2016,38(2):151-155. CAO Xiangfeng,GUAN Zhichuan,WANG Zhifeng,et al.Drill bit positioning method based on connected well guidance for coalbed methane[J].Oil Drilling Production Technology,2016,38(2):151-155. [3] 乔传尚.YST-48R型MWD仪器的Bt值异常分析与判断[J].石油仪器,2011,25(4):23-25. QIAO Chuanshang.Measurement and analysis of abnormal Bt value of YST-48R MWD[J].Petroleum Instruments,2011,25(4):23-25. [4] 梁奇敏,何俊才,董文涛,等."井工厂"作业时直井段防碰设计与控制探讨[J].石油钻采工艺,2016,38(3):302-306. LIANG Qimin,HE Juncai,DONG Wentao,et al.Anti-collision design and control of vertical section in ‘well plant’ mode[J].Oil Drilling Production Technology,2016,38(3):302-306. [5] RUSSELL M K,RUSSELL A W.Surveying of borehole:US 4163324[P].1979-08-07.
[6] 罗武胜,徐涛,杜列波.基于加速度计和磁强计的定向钻进姿态测量及方位校正[J].国防科技大学学报,2007,29(1):106-110. LUO Wusheng,XU Tao,DU Liebo.Directional drilling attitude measurement and azimuth correction with accelerometers and magnetometers[J].Journal of National University of Defense Technology,2007,29(1):106-110. [7] 徐涛,温东,孙晓磊.基于加速度计和磁强计的方位测量与校正技术研究[J].仪器仪表学报,2009,30(10):2018-2022. XU Tao,WEN Dong,SUN Xiaolei.Research on azimuth measurement and correction technique with accelerometer and magnetometer[J].Chinese Journal of Scientific Instrument,2009,30(10):2018-2022. [8] Sperry-Sun Drilling Services Company.Basic concepts of directional surveying[R].1995.
[9] 张苏,管志川,王建云,等.邻井套管对井斜方位角的影响[J].石油钻探技术,2013,41(6):51-55. ZHANG Su,GUAN Zhichuan,WANG Jianyun,et al.Impact of casing on adjacent well azimuth[J].Petroleum Drilling Techniques,2013,41(6):51-55. [10] 高德利,刁斌斌.复杂结构井磁导向钻井技术进展[J].石油钻探技术,2016,44(5):1-9. GAO Deli,DIAO Binbin.Development of the magnetic guidance drilling technique in complex well engineering[J].Petroleum Drilling Techniques,2016,44(5):1-9. [11] 许昊东,黄根炉,张然,等.磁力随钻测量磁干扰校正方法研究[J].石油钻探技术,2014,42(2):102-106. XU Haodong,HUANG Genlu,ZHANG Ran,et al.Method of magnetic interference correction in survey with magnetic MWD[J].Petroleum Drilling Techniques,2014,42(2):102-106. [12] 王明哲,陆斌,于跃军.Sperry-Sun MWD轴向磁干扰的解决方法及应用[J].石油仪器,2008,22(2):47-49. WANG Mingzhe,LU Bin, YU Yuejun.Solution to the axial magnetic interference on Sperry-Sun MWD[J].Petroleum Instruments,2008,22(2):47-49. [13] van DONGEN J C M,MAEKIAHO L B.Method for determining the azimuth of a borehole:US 4682421[P].1987-07-28.
[14] 王锐,崔朋波,刘培军.MWD独立误差源的确定分析[J].特种油气藏,2011,18(5):120-123. WANG Rui,CUI Pengbo,LIU Peijun.Determinative analysis of MWD independent error sources[J].Special Oil Gas Reservoirs,2011,18(5):120-123. [15] 李翠,高德利,刘庆龙,等.邻井随钻电磁测距防碰计算方法研究[J].石油钻探技术,2016,44(5):52-59. LI Cui,GAO Deli,LIU Qinglong,et al.A method of calculating of avoiding collisions with adjacent wells using electromagnetic ranging surveying while drilling tools[J].Petroleum Drilling Techniques,2016,44(5):52-59. -
