“Four Points and Five Types” Remaining Oil Classification in Oilfields with Ultra-High Water Cut
-
摘要: 特高含水期油田的油水分布状况复杂，需要明确其剩余油的定义、属性分类方法和水驱开发潜力评价方法。在油藏水驱极限驱油效率研究和渗流力学分析的基础上，选取油水渗流特征点对应的4个含油饱和度为剩余油分类界限点，建立了特高含水期油田"四点五类"剩余油属性分类方法。将特高含水期油田剩余油划分为富集油、相对富集油、可动用油、难动用油和残余油5类，分析了这5类剩余油的具体属性、开发调整对策及措施方向。根据提出的油田水驱开发潜力评价方法，将特高含水期油田水驱开发潜力划分为水驱极限潜力、可动用潜力和难动用潜力3类，并对中国石化10个中高渗透油田的剩余油属性分类和水驱开发潜力进行了分析，结果表明，特高含水后期普遍分布的剩余油以难动用油为主，局部富集的剩余油以相对富集油为主，注水开发极限潜力巨大，但近4/5为难动用潜力油藏。特高含水期油田"四点五类"剩余油分类方法明确了剩余油的分布特征，为制定不同类型剩余油开发调整措施提供了理论依据。Abstract: Oil and water distribution within the reservoirs in mature oilfields with extremely high water cut is very complicated. To tap the development potential of such fields, it is necessary to have a clear definition of the remaining oil, its attributes and classification method, and the approaches for evaluating the potential for further developing the fields with a waterflooding program. A "Four Points and Five Types" remaining oil classification method for oil fields with ultra-high water cut was developed in this paper by selecting 4 oil saturation points corresponding to the oil-water seepage characteristics as the boundary points of remaining oil classification, based on the investigation of the ultimate oil displacement efficiency and the analysis of the seepage mechanics. The remaining oil in fields with ultra-high water cut was classified into five types, including enriched oil, somewhat enriched oil, movable oil, hard-to-move oil, and residual oil. The specific features and re-development strategies of these five types of remaining oil were analyzed. Based on the presented method for evaluating the waterflooding development potential of oilfields, the waterflooding development potential of oil fields with extremely high water cut was categorized into three types, namely, ultimate waterflooding potential, movable potential and hard-to-move potential. Investigation of the remaining oil types and waterflooding development potential of 10 fields with mid-high permeability showed that majority of the remaining oil in fields with extremely high water cut was hard-to-move oil, and there was rather enriched oil in some local areas. Although there was huge waterflooding development potential in such fields, nearly 4/5 of the remaining oil was hard to produce. In summary, the "Four Points and Five Types" remaining oil classification method for fields with extremely high water cut helped to make clear the remaining oil distribution features and provided supports for working out re-development strategies of the various types of remaining oil.
-
Keywords:
- ultra-high water cut /
- remaining oil /
- classification /
- waterflooding /
- development potential
-
-
[1] 刘宝珺,谢俊,张金亮.我国剩余油技术研究现状与进展[J].西北地质,2004,37(4):1-6. LIU Baojun,XIE Jun,ZHANG Jinliang.Present situation and advance of remaining oil research technology in China[J].Northwestern Geology,2004,37(4):1-6. [2] 李阳,王端平,刘建民.陆相水驱油藏剩余油富集区研究[J].石油勘探与开发,2005,32(3):91-96. LI Yang,WANG Duanping,LIU Jianmin.Remaining oil enrichment areas in continental water flooding reservoirs[J].Petroleum Exploration and Development,2005,32(3):91-96. [3] 韩大匡.准确预测剩余油相对富集区 提高油田注水采收率研究[J].石油学报,2007,28(2):73-78. HAN Dakuang.Precisely predicting abundant remaining oil and improving the secondary recovery of mature oilfields[J].Acta Petrolei Sinica,2007,28(2):73-78. [4] 纪淑红,田昌炳,石成方,等.高含水阶段重新认识水驱油效率[J].石油勘探与开发, 2012,39(3):338-345. JI Shuhong,TIAN Changbing,SHI Chengfang,et al.New understanding on water-oil displacement efficiency in a high water-cut stage[J].Petroleum Exploration and Development, 2012,39(3):338-345. [5] 邴绍献.基于特高含水期油水两相渗流的水驱开发特征研究[D].成都:西南石油大学,2013. BING Shaoxian.Study on water drive development characteristics based on the oil-water two phase flow of ultra-high water cut stage[D].Chengdu:Southwest Petroleum University,2013. [6] 刘浩瀚,刘志斌,丁显峰.特高含水期剩余油孔道选择微观机理研究[J].石油天然气学报,2013,35(5):92-97. LIU Haohan,LIU Zhibin,DING Xianfeng.Micro-pore path selection mechanism of remaining oil at ultra-high water-cut stage[J].Journal of Oil and Gas Technology,2013,35(5):92-97. [7] 王端平.对胜利油区提高原油采收率潜力及转变开发方式的思考[J].油气地质与采收率,2014,21(4):1-4. WANG Duanping.Some thoughts about potential of oil recovery efficiency and development model transition in Shengli District[J].Petroleum Geology and Recovery Efficiency,2014,21(4): 1-4. [8] 闫文华,焦龙.高注水倍数非均质岩心驱油效果实验研究[J].石油化工高等学校学报,2014,27(4):48-51. YAN Wenhua,JIAO Long.Heterogeneous cores of high injection multiples flooding effect[J].Journal of Petrochemical Universities,2014,27(4):48-51. [9] 崔传智,徐建鹏,王端平,等.特高含水阶段新型水驱特征曲线[J].石油学报, 2015,36(10):1267-1271. CUI Chuanzhi,XU Jianpeng,WANG Duanping,et al.A new water flooding characteristic curve at ultra-high water cut stage[J].Acta Petrolei Sinica,2015,36(10):1267-1271. [10] 王友启.陆相特高含水油田固水提高采收率机制研究[J].中国石油大学学报(自然科学版),2012,36(6):108-112. WANG Youqi.Research on mechanism of enhanced oil recovery using immobilizing movable water in continental extra-high water cut oilfield[J].Journal of China University of Petroleum(Edition of Natural Science),2012,36(6):108-112. [11] 王友启.胜利油田高含水期油藏水驱精细调整技术方向[J].石油钻探技术,2011,39(1):101-104. WANG Youqi.Fine adjustment direction of water flooding in high watercut oil reservoirs of Shengli Oilfield[J].Petroleum Drilling Techniques,2011,39(1):101-104. [12] 董利飞,岳湘安,苏群,等.非均质储层水驱剩余油分布及其挖潜室内模拟研究[J].石油钻采工艺,2015,37(6):63-66. DONG Lifei,YUE Xiang’an,SU Qun,et al.Distribution of remaining oil by water flooding in heterogeneous reservoirs and indoor simulation study for its potential tapping[J].Oil Drilling Production Technology,2015,37(6):63-66. [13] 姜瑞忠,乔欣,滕文超,等.储层物性时变对油藏水驱开发的影响[J].断块油气田,2016,23(6):768-771. JIANG Ruizhong,QIAO Xin,TENG Wenchao,et al.Impact of physical properties time variation on waterflooding reservoir development[J].Fault-block Oil Gas Field,2016,23(6):768-771. [14] 马康,姜汉桥,李俊键,等.基于核磁共振的复杂断块油藏微观动用均衡程度实验[J].断块油气田,2016,23(6):745-748. MA Kang,JIANG Hanqiao,LI Junjian,et al.Experimental study on micro balanced development of complex fault-block reservoirs based on nuclear magnetic resonance[J].Fault-Block Oil Gas Field,2016,23(6):745-748. -
