丁页2HF页岩气水平井钻井技术

何龙; 胡大梁; 朱弘

doi:10.3969/j.issn.1001-0890.2014.04.024

丁页2HF页岩气水平井钻井技术

1.
中国石化西南油气分公司钻井工程处, 四川成都 610041;
2.
中国石化西南油气分公司工程技术研究院, 四川德阳 618002;
3.
中国石化勘探南方分公司, 四川成都 610041

基金项目:

国家科技重大专项课题“低渗气藏复杂地层高效钻井关键技术”（编号：2011ZX05022-005）部分研究成果。

详细信息

作者简介:
何龙（1970- ），1993年毕业于成都理工学院钻探工程专业，高级工程师，主要从事钻井工程项目管理。

中图分类号: TE243⁺.1
计量
- 文章访问数: 4542
- HTML全文浏览量: 79
- PDF下载量: 3807
出版历程
- 收稿日期: 2014-04-28
- 修回日期: 2014-05-21
- 刊出日期: 1899-12-31

Drilling Technologies for Shale Gas Horizontal Well Dingye 2HF

1.
Department of Drilling Engineerin, Sinopec Southwest Petroleum Branch, Chengdu, Sichuan, 610041, China;
2.
Engineering Technology Insititute of Southwest Petroleum Branch, Sinopec, Deyang, Sichuan, 618002, China;
3.
Exploration Southern Company,

摘要

摘要: 丁页2HF井是部署在川东南丁山构造的一口页岩气水平井，目的层为志留系龙马溪组，设计井深5 655.00 m。该井钻进中面临陆相地层厚度大、上部地层出水、气体钻井应用井段受限、地层可钻性差、钻头选型困难、长水平段托压严重、斜井段泥页岩井壁稳定性差等技术难点。为此，首先分析了丁山构造的工程地质特征；然后，结合邻区实钻资料，在钻进中综合应用了气体钻井、高效钻头优选、PDC钻头配合螺杆复合钻井、强封堵油基钻井液和漂浮下套管、三凝水泥浆体系等技术。实钻表明，这些技术的应用效果良好，不但使丁页2HF井顺利钻达目的层，而且完钻井深达到5 700.00 m，创造当时国内页岩气水平井最深纪录。对该井应用的钻井技术和工艺及具体实施效果进行了分析，认为形成的丁页2HF页岩气水平井钻井技术，可为丁山构造页岩气水平井钻井提供参考。
- 页岩气 /
- 水平井 /
- 气体钻井 /
- 固井 /
- 油基钻井液 /
- 丁页2HF井
Abstract: Well Dingye 2HF is a horizontal well with the designed depth 5 655 m drilled for shale gas in Silurian Formation in Dingshan Structure,southeastern Sichuan.There were several drilling challenges,such as extremely thick terrestrial formation,water production in upper formation,limited sections for gas drilling, poor drillability of formation,difficult in selecting bit type,not easy for putting weight on bit in long horizontal section,and poor stability of wellbore in deviated mud-shale section.Therefore,after investigating geological conditions of Dingshan Structure,and considering the drilling data of adjacent areas,Well Dingye 2HF was drilled by integrating several techniques,including gas drilling,efficient drill bit selection,PDC bit with PDM drilling,oil-based drilling fluids with plugging material,floated casing running, and 3-stage cementing slurry system.Practical operations proved good effects of such techniques,which allowed Well Dingye 2HF to penetrate successfully into the target layer,with total depth of 5 700 m,recording the deepest shale gas well in China.The drilling techniques,processes and results of Well Dingye 2HF was reviewed,and suggested that they could be valuable references for drilling other shale gas horizontal wells in Dingshan Structure.
- shale gas /
- horizontal well /
- gas drilling /
- well cementing /
- oil based drilling fluid /
- Well Dingye 2HF

HTML全文

参考文献(14)

[1]	路保平.中国石化页岩气工程技术进步及展望[J].石油钻探技术, 2013, 41(5):1-8. Lu Baoping.Sinopec engineering technical advance and its developing tendency in shale gas[J].Petroleum Drilling Techniques, 2013, 41(5):1-8.
[2]	郭彤楼, 张汉荣.四川盆地焦石坝页岩气田形成与富集高产模式[J].石油勘探与开发, 2014, 41(1):28-36. Guo Tonglou, Zhang Hanrong.Formation and enrichment mode of Jiaoshiba shale gas field, Sichuan Basin[J].Petroleum Exploration and Development, 2014, 41(1):28-36.
[3]	周贤海.涪陵焦石坝区块页岩气水平井钻井完井技术[J].石油钻探技术, 2013, 41(5):26-30. Zhou Xianhai.Drilling completion techniques used in shale gas horizontal wells in Jiaoshiba Block of Fuling Area[J].Petroleum Drilling Techniques, 2013, 41(5):26-30.
[4]	段军.丁山1井古生界地层钻头选型[J].石油天然气学报, 2008, 30(3):384-386. Duan Jun.Selection of drilling bits used in Well Dingshan 1 in Palaeozoic Formation[J].Journal of Oil and Gas Technology, 2008, 30(3):384-386.
[5]	孙玮, 刘树根, 王国芝, 等.川东南丁山构造震旦系—下古生界油气成藏条件及成藏过程[J].地质科技情报, 2010, 29(1): 49-55. Sun Wei, Liu Shugen, Wang Guozhi, et al.Petroleum formed condition and process research for Sinian to Low Paleozoic at Dingshan Structure in southeast of Sichuan Basin[J].Geological Science and Technology Information, 2010, 29(1):49-55.
[6]	姜政华, 童胜宝, 丁锦鹤.彭页HF-1页岩气水平井钻井关键技术[J].石油钻探技术, 2012, 40(4):28-31. Jiang Zhenghua, Tong Shengbao, Ding Jinhe.Key technologies adopted for shale gas horizontal Well Pengye HF-1[J].Petroleum Drilling Techniques, 2012, 40(4):28-31.
[7]	马庆涛, 葛鹏飞, 王晓宇, 等.涪页HF-1页岩气水平井钻井关键技术[J].石油机械, 2013, 41(8):107-110. Ma Qingtao, Ge Pengfei, Wang Xiaoyu, et al.Key technology of shale gas horizontal drilling in Well HF-1 of Fuye[J].China Petroleum Machinery, 2013, 41(8):107-110.
[8]	王显光, 李雄, 林永学.页岩水平井用高性能油基钻井液研究与应用[J].石油钻探技术, 2013, 41(2):17-22. Wang Xianguang, Li Xiong, Lin Yongxue.Research and application of high performance oil base drilling fluid for shale horizontal well[J].Petroleum Drilling Techniques, 2013, 41(2):17-22.
[9]	聂靖霜, 王华平, 王富渝, 等.长宁威远地区页岩气大斜度水平井钻井技术研究[J].钻采工艺, 2013, 36(3):118-120. Nie Jingshuang, Wang Huaping, Wang Fuyu, et al.Research on shale gas horizontal well drilling technology of Changning-Weiyuan District[J].Drilling Production Technolgoy, 2013, 36(3):118-120.
[10]	刘伟, 陶谦, 丁士东.页岩气水平井固井技术难点分析与对策[J].石油钻采工艺, 2012, 34(3):40-43. Liu Wei, Tao Qian, Ding Shidong.Difficulties and countermeasures for cementing technology of salle gas horizontal well[J].Oil Drilling Production Technology, 2012, 34(3): 40-43.
[11]	武治强, 周建良, 靳勇, 等.页岩气水平井气层封固难点分析与技术对策[J].石油钻采工艺, 2012, 34(增刊1):26-29. Wu Zhiqiang, Zhou Jianliang, Jin Yong, et al.Difficulty analysis and technical countermeasures to the gas layer sealing ablilty for the shale gas horizontal well[J].Oil Drilling Production Technology, 2012, 34(supplement 1):26-29.
[12]	王华平, 张铎, 张德军, 等.威远构造页岩气钻井技术探讨[J].钻采工艺, 2012, 35(2):9-11. Wang Huaping, Zhang Duo, Zhang Dejun, et al.Drilling technologies on shale gas in Weiyuan Structure[J].Drilling Production Technolgoy, 2012, 35(2):9-11.
[13]	田林海, 张传, 田海, 等.液力推进器配合单弯接头防斜钻井技术[J].新疆石油科技, 2012, 22(3):4-7. Tian Linhai, Zhang Chuan, Tian Hai, et al.Anti-deflection drilling technology of hydraulic thruster with single bend elbow[J].Xinjiang Petroleum Science Technology, 2012, 22(3):4-7.
[14]	李子丰, 杨海滨, 许春田, 等.定向井滑动钻进送钻原理与技术[J].天然气工业, 2013, 33(12):94-98. Li Zifeng, Yang Haibin, Xu Chuntian, et al.Bit feed principles and technologies in slide-drilling directional wells[J].Natural Gas Industry, 2013, 33(12):94-98.
