Casing Program of Deep Well with Evaporite Bed in Tuofutai Block
-
摘要: 为解决托甫台区块深井钻井过程中长裸眼穿过盐膏层时火成岩地层易漏、易塌及盐膏层易卡的问题，确保安全快速成井，将地应力分析软件Drillworks对测井资料的反演结果与实钻、测试资料结合，分析了托甫台区块地层的三压力剖面；利用巴西劈裂法与应力-应变试验评价了火成岩地层的强度；根据成像测井资料和电镜扫描结果分析了火成岩裂缝分布特征，分析了桥堵技术难以提高火成岩地层承压能力的原因。通过以上分析，确定了托甫台区块含盐膏层深井的3个必封点与1个风险点，并据此设计了“专封盐膏层”井身结构。实钻效果表明，“专封盐膏层”井身结构可以解决托甫台区块深井长裸眼钻穿盐膏层过程中的井漏、坍塌和卡钻等井下故障。Abstract: In order to solve the problems of lost circulation and collapsing in the igneous rock and sticking in evaporite formation during drilling long open hole through evaporite bed in Tuofutai Block,optimization of casing program was carried out to ensure the safe and rapid drilling practices.By combining inversion results of Drillworks software with the practical field test data,the three pressure profiles of Tuofutai Block were analyzed.The strength of the igneous rock samples was assessed by using Brazilian test and stress-strain test.To determine the reason why the pressure sealing technology was difficult to improve bearing capacity of igneous rock formation,the fracture distribution of the igneous rock was researched by using imaging logging data and scanning electron microscopy techniques.Based on three positions that had to be sealed and one risk in deep evaporates bed that were determined according to the analysis of the above results,a special casing program for sealing evaporite bed was designed.Field application demonstrated that this new casing program could keep igneous rock and evaporite bed from downhole problems such as lost circulation,collapsing and sticking.
-
Keywords:
- evaporite bed /
- igneous rock /
- casing program /
- resistance to pressure /
- loss circulation control /
- Tuofutai Block
-
-
[1] 王京红, 邹才能, 靳久强, 等.火成岩储集层裂缝特征及成缝控制因素[J].石油勘探与开发, 2011, 38(6):708-715. Wang Jinghong, Zou Caineng, Jin Jiuqiang, et al.Characteristics and controlling factors of fractures in igneous rock reservoirs[J].Petroleum Exploration and Development, 2011, 38(6):708-715. [2] 陈亮, 王立峰, 蔡利山, 等.塔河油田盐上承压堵漏工艺技术[J].石油钻探技术, 2006, 34(4):60-64. Chen Liang, Wang Lifeng, Cai Lishan, et al.High pressure circulation lost teehniques for salt beds in the Tahe Oilfield[J].Petroleum Drilling Techniques, 2006, 34(4):60-64. [3] 刘四海, 崔庆东, 李卫国.川东北地区井漏特点及承压堵漏技术难点与对策[J].石油钻探技术, 2008, 36(3):20-23. Liu Sihai, Cui Qingdong, Li Weiguo.Circulation loss characteristics and challenges and measures to plug under pressure in Northeast Sichuan Area[J].Petroleum Drilling Techniques, 2008, 36(3):20-23. [4] 郭春华, 马玉芬.塔河油田盐下区块盐膏层钻井液技术[J].钻井液与完井液, 2004, 21(6):19-22. Guo Chunhua, Ma Yufen.Drilling fluid technology for salt-gypsum formation of Yanxia Block in Tahe Oilfield[J].Drilling Fluid Completion Fluid, 2004, 21(6):19-22. [5] 杨玉坤.川东北地区深井井身结构优化设计[J].石油钻探技术, 2008, 36(3):33-36. Yang Yukun.Deep well casing structure optimization in Northeast Sichuan Area[J].Petroleum Drilling Techniques, 2008, 36(3):33-36. [6] 金衍.井壁稳定力学研究[D].北京:石油大学(北京)石油天然气工程学院, 1998. Jin Yan.Research on mechanics of borehole stability[D].Beijing:University of Petroleum(Beijing), Faculty of Petroleum Engineering, 1998. [7] 刘之的, 戴诗华, 王洪亮, 等.火成岩裂缝有效性测井评价[J].西南石油大学学报, 2008, 30(2):66-68. Liu Zhide, Dai Shihua, Wang Hongliang, et al.Evaluation of the fracture effectiveness of igneous rock by using logging data[J].Journal of Southwest Petroleum University, 2008, 30(2):66-68. [8] 孙宁.钻井手册:上[M].北京:石油工业出版社, 2013:456-462. Sun Ning.Drilling handbook:part A[M].Beijing:Petroleum Industry Press, 2013:456-462. -
