Fracturing Pressure Reducing Technique for Shale Gas Well in the Southeastern Sichuan
-
摘要: 为实现川东南超深页岩储层有效改造，并最大限度地降低压裂施工压力，提出了优选射孔参数、进行压前酸液预处理、设计降阻率高的滑溜水体系及采用前置粉砂段塞技术等技术对策。通过分析和计算，采用φ89 mm射孔枪配合 SDP40HMX28-8 射孔弹，60°相位和18孔/m的孔密进行射孔。利用川东南超深页岩储层的岩心进行了溶蚀试验，根据试验结果结合地层特点确定了15.0%HCl+1.5%HF+2.0%高温缓蚀剂+1.5%铁离子稳定剂的酸液配方。根据地层特征，通过室内试验优选了配方为0.2%高效减阻剂SRFR-1+0.3%复合防膨剂+0.1%复合增效剂＋0.02%消泡剂的滑溜水，其性能稳定，易返排，黏度约9~12 mPa·s，降阻率大于75%，对地层的伤害率小于10%。现场应用表明：采用优化后的射孔参数进行射孔，可以满足降低孔眼摩阻的要求；应用优选的酸液进行压前预处理，施工压力降低10~15 MPa；采用前置粉砂段塞技术，可以有效降低裂缝弯曲摩阻，达到降低施工压力的目的。这表明，采用提出的技术对策可以降低川东南超深页岩气井压裂施工压力。Abstract: In order to effectively stimulate the ultra-deep shale reservoirs in southeastern Sichuan and minimize the fracturing pressure,some technical solutions were proposed,such as optimization of perforation parameters,acid pretreatment before fracturing,design of slick water system with high friction reducing rate,and application of lead silt slug techniques.Through analysis and calculation,it was decided to use the φ89 mm perforating gun with type SDP40HMX28-8 charges for perforation at 18 shots/m and phase 60°.Based on core dissolution tests and characteristics of such ultra-deep shale reservoirs,a formula of 15.0% HCl+1.5% HF+2.0% HT corrosion inhibitor+1.5% ferric ion stabilizer was determined.According to the stratigraphic characteristics,a laboratory experiment was performed and it revealed a slick water system consisting of 0.2% efficient friction reducer SRFR-1+0.3% compound anti-swelling agent+0.1% compound synergist + 0.02% defoamer,which is stable and easy to flowback,with viscosity of about 9-12 mPa·s,friction reducing rate than 75% and formation damage less than 10%.Field application showed that the optimized perforation parameters could meet the requirement for perforation friction reduction;acid pretreatment before fracturing enabled the pressure reduced by 10-15 MPa;the lead silt slug technique could effectively reduce the friction due to fractures curvature,thereby reducing the fracturing pressure.It showed that these technical solutions could help to reduce the fracturing pressure in ultra-deep shale gas wells in the southeastern Sichuan.
-
Keywords:
- shale gas well /
- fracturing /
- perforating parameter /
- acid treatment /
- slick water /
- southeastern Sichuan
-
-
[1] 薛承瑾.页岩气压裂技术现状及发展建议[J].石油钻探技术, 2011, 39(3):24-29. Xue Chengjin.Technical advance and development proposals of shale gas fracturing[J].Petroleum Drilling Techniques, 2011, 39(3):24-29. [2] 谭明文, 张应科, 钟水清, 等.川东北高温高压深井超深井酸压改造技术研究与应用[J].钻采工艺, 2011, 34(3):35-40, 114. Tan Mingwen, Zhang Yingke, Zhong Shuiqing, et al.Research and application of acid fracturing technology in HTHP deep and ultradeep well of northeast Sichuan Area[J].Drilling Production Technology, 2011, 34(3):35-40, 114. [3] 李海涛, 王永清, 李洪建, 等.压裂施工井的射孔优化设计方法[J].天然气工业, 1998, 18(2):53-56. Li Haitao, Wang Yongqing, Li Hongjian, et al.An optimum perforation design method for prefratureing wells[J].Natural Gas Industry, 1998, 18(2):53-56. [4] 王超, 刘广燕, 孙桓.超深水平井射孔的优化设计[J].内江科技, 2008, 29(8):91-92. Wang Chao, Liu Guangyan, Sun Huan.Optimized design of ultra-deep horizontal well perforation[J].Neijiang Science and Technology, 2008, 29(8):91-92. [5] 刘红现, 赵立强, 刘平礼, 等.前置酸改善水力压裂效果机理分析[J].石油天然气学报, 2008, 30(1):332-334, 398. Liu Hongxian, Zhao Liqiang, Liu Pingli, et al.Analysis on pore micro structure for sand stone acidizing[J].Journal of Oil and Gas Technology, 2008, 30(1):332-334, 398. [6] 何鹏, 刘寒梅, 李向东, 等.前置酸压裂技术在低渗透油田中的研究与应用[J].延安大学学报:自然科学版, 2013, 32(2):78-80, 85. He Peng, Liu Hanmei, Li Xiangdong, et al.Research and application of the pre-positioned acid fracturing technology in low permeability oilfield[J].Journal of Yan’an University:Natural Science Edition, 2013, 32(2):78-80, 85. [7] 唐颖, 张金川, 张琴, 等.页岩气井水力压裂技术及其应用分析[J].天然气工业, 2010, 30(10):33-38. Tang Ying, Zhang Jinchuan, Zhang Qin, et al.An analysis of hydraulic fracturing technology in shale gas wells and its application[J].Natural Gas Industry, 2010, 30(10):33-38. [8] 曾雨辰.砂段塞工艺在中原油田斜井压裂中的应用[J].天然气工业, 2004, 24(9):60-63. Zeng Yuchen.Application of sand-slug technology in deviated well fracturing in Zhongyuan Oilfield[J].Natural Gas Industry, 2004, 24(9):60-63. [9] Lord D L.Turbulent flow of stimulation fluids:an evaluation of friction loss scale-up methods[R].SPE 16889, 1987.
[10] Nolte K G, Smith M B.Interpretation of fracturingpressured[J].JPT, 1981, 33(9):1767-1775.
-
