Mechanism of Interaction between Hydraulic Fractures and Weak Plane in Layered Shale
-
摘要: 为了进一步认识水力压裂裂缝在层状页岩中的扩展行为,以四川盆地龙马溪组页岩为研究对象,根据Mohr-Coulomb准则,研究了水力压裂过程中层状页岩压裂裂缝与弱面的干扰机理,以及基质破坏、弱面剪切破坏、弱面张开破坏所对应的临界液压;根据断裂力学,研究了弱面在张开和剪切破坏下的剪切滑移量,建立了水力压裂裂缝与岩体弱面干扰理论模型,并对其进行了应用分析。实例计算分析表明:0° α 20°时(α为弱面法向矢量与最大水平主应力方向的夹角),水力压裂裂缝中的液压容易促使岩石基质发生破坏;25° α 75°时,水力压裂裂缝中的液压容易促使页岩沿弱面剪切破坏;80° α 90°时,水力压裂裂缝的液压容易促使页岩沿弱面张开;剪切滑移量受弱面上摩擦系数、剪应力、正应力的共同影响,其中剪应力是剪切滑移的驱动因素。研究认为,当弱面发生张开或剪切破坏后,弱面滑移量与裂缝长度成正比,与弹性模量成反比;建立的理论模型与现场压裂微地震监测结果基本吻合,可用来预测水力裂缝与弱面的干扰行为。Abstract: Taking Longmaxi Formation of the Sichuan Basin as an example,the mechanism of interaction between hydraulic fractures and weak plane was investigated to further understand the hydraulic fracture propagation in layered shale.Such mechanism in fracturing was analyzed based on Mohr-Coulomb Criteria,and the critical pressure for rock matrix failure,weak plane shear and opening failure were also studied.According to fracture mechanics,the shear displacement under opening and shear failure of a weak plane were considered,and then an interaction theoretical model was developed and applied in shale reservoir.The calculation example showed that,the pressure in hydraulic fracture could stimulate the rock matrix-failure when 0° α 20°,the weak plane shear-failure when 25° α 75°,and the weak plane opening-failure when 80° α 90°;the shear displacement was jointly affected by frictional coefficient,shear stress(as the main factor)and normal stress.After the shear or opening failure of weak plane occurs,its displacement is proportional to fracture length and inversely proportional to elastic modulus.It was suggested that the theoretical model could be used in predicting the interaction between hydraulic fracture and weak plane,which was very consistent with the micro-seismic crack monitoring.
-
Keywords:
- shale /
- hydraulic fracturing /
- fracturing fracture /
- bedding /
- weak plane
-
-
[1] Gu H, Weng X, Lund J B, et al.Hydraulic fracture crossing natural fracture at nonorthogonal angles:a criterion and its validation[J].SPE Production Operations, 2012, 27(1): 20-26.
[2] 杨丽娜, 陈勉.水力压裂中多裂缝间相互干扰力学分析[J].石油大学学报:自然科学版, 2003, 27(3):43-45. Yang Lina, Chen Mian.Mechanism of multi-fracture interaction in multi-layer hydraulic fracturing[J].Journal of the University of Petroleum, China:Edition of Natural Science, 2003, 27(3):43-45. [3] 陈勉, 周健, 金衍, 等.随机裂缝性储层压裂特征实验研究[J].石油学报, 2008, 29(3):431-434. Chen Mian, Zhou Jian, Jin Yan, et al.Experimental study on fracturing features in naturally fractured reservoir[J].Acta Petrolei Sinica, 2008, 29(3):431-434. [4] 周健, 陈勉, 金衍, 等.压裂中天然裂缝剪切破坏机制研究[J].岩石力学与工程学报, 2008, 27(增刊1):2637-2641. Zhou Jian, Chen Mian, Jin Yan, et al.Mechanism study of shearing slippage damage of natural fracture in hydraulic fracturing[J].Chinese Journal of Rock Mechanics and Engineering, 2008, 27(supplement 1):2637-2641. [5] 周健, 陈勉, 金衍, 等.裂缝性储层水力裂缝扩展机理试验研究[J].石油学报, 2007, 28(5):109-113. Zhou Jian, Chen Mian, Jin Yan, et al.Experimental study on propagation mechanism of hydraulic fracture in naturally fractured reservoir[J].Acta Petrolei Sinica, 2007, 28(5):109-113. [6] Zhou Jian, Jin Yan, Chen Mian.Experimental investigation of hydraulic fracturing in random naturally fractured blocks[J].International Journal of Rock Mechanics and Mining Science, 2010, 47(7):1193-1199.
[7] Zhou Jian, Chen Mian, Jin Yan, et al.Analysis of fracture propagation behavior and fracture geometry using a tri-axial fracturing system in naturally fractured reservoirs[J].International Journal of Rock Mechanics and Mining Science, 2008, 45(7):1143-1152.
[8] Zhao Haifeng, Chen Mian.Extending behavior of hydraulic fracture when reaching formation interface[J].Journal of Petroleum Science and Engineering, 2010, 74(1/2):26-30.
[9] Blair S C, Thorpe R K, Heuze F E, et al.Laboratory observations of the effect of geological discontinuities on hydrofracture propagation:proceeding of the 30th U.S.Symposium on Rock Mechanics, Morgantown, West Virginia, June 19-22, 1989[C].
[10] 程万, 金衍, 陈勉, 等.三维空间中水力裂缝穿透天然裂缝的判别准则[J].石油勘探与开发, 2014, 41(2):1-6. Cheng Wan, Jin Yan, Chen Mian, et al.A criterion for identifying hydraulic fractures crossing natural fractures in 3D space[J].Petroleum Exploration and Development, 2014, 41(2):1-6. [11] Lee Hikweon, Ong See Hong, Azeemuddin Mohammed, et al.A wellbore stability model for formations with anisotropic rock strengths[J].Journal of Petroleum Science and Engineering, 2012, 96-97:109-119.
[12] 赵海峰, 陈勉, 金衍, 等.页岩气藏网状裂缝系统的岩石断裂动力学[J].石油勘探与开发, 2012, 39(4):465-470. Zhao Haifeng, Chen Mian, Jin Yan, et al.Rock fracture kinetics of the fracture mesh system in shale gas reservoirs[J].Petroleum Exploration and Development, 2012, 39(4):465-470. [13] 程靳, 赵树山.断裂力学[M].北京:科学出版社, 2008:14-17. Chen Jin, Zhao Shushan.Fracture mechanics[M].Beijing:Science Press, 2008:14-17. -
