Affecting Mechanism of Rock Mechanical Property on Well Trajectory
-
摘要: 为了提高在极软、极硬地层中钻井时的井眼轨迹预测与控制能力，研究了岩石力学性质对井眼轨迹的影响机理和相应的控制措施。基于纵横弯曲连续梁理论，分析了地层力学性质对下部钻具组合导向性能的影响，在此基础上，建立了考虑地层力学性质的钻头导向模型，利用钻头导向模型定量描述钻压、造斜力、地层可钻性和钻头各向异性对井眼轨迹的影响。对于Φ215.9 mm井眼，井眼瞬时扩径率小于3%时，宜采用弯壳体螺杆钻具，井眼扩径率大于3%时，弯接头配合直螺杆导向能力更强；地层可钻性级值由1增大为10时，趋势角从6.00°降为1.00°。软地层和侧钻井眼推荐使用弯接头配合直螺杆钻具，硬地层推荐使用侧切能力强的钻头配合单弯螺杆钻具。Abstract: To improve the prediction and control ability of well trajectory in very soft and very hard formations,the effect of rock mechanical property on well trajectory and related control measures has been studied.According to beam theory,the effect of rock mechanical property on bottom hole assembly(BHA)property was analyzed,on this basis,a bit steering model was developed considering rock mechanical properties;then the model was used to describe the effect of weight on bit,building force,rock drillability and bit anisotropy on well trajectory quantitatively.For Φ215.9 mm well bore,if the instant expending ratio of well bore diameter is less than 3%,bending house PDM is suitable,if expending ratio is more than 3%,bending sub matched with straight PDM has stronger steering ability.With rock drillability increasing from 1 to 10,well trajectory trending angle decreases from 6.00°to 1.00°.Bending sub matched with straight PDM is recommended for the drilling of soft formation and sidetracking.Bit with more side cutting ability matched with bending house PDM is more effective when drilling hard formations.
-
-
[1] 苏义脑.钻井力学与井眼轨道控制文集[M].北京:石油工业出版社, 2008:126-128. Su Yinao.Drilling mechanics and well trajectory control corpus[M].Beijing:Petroleum Industry Press, 2008:126-128. [2] 高德利.关于UPC模型的理论问题[J].石油钻采工艺, 1993, 15(2):30-36. Gao Deli.Theory study of UPC model[J].Oil Drilling Production Technology, 1993, 15(2):30-36. [3] Ho H-S.Prediction of drilling trajectory in directional wells via a new rock-bit interaction model[R].SPE 16658, 1987.
[4] 闫光庆, 刘匡晓, 郭瑞昌, 等.元坝272H井超深硬地层侧钻技术[J].石油钻探技术, 2013, 41(1):113-117. Yan Guangqing, Liu Kuangxiao, Guo Ruichang, et al.Ultra-deep sidetracking in Well Yuanba 272H[J].Petroleum Drilling Techniques, 2013, 41(1):113-117. [5] 王光磊, 侯建, 于承鹏, 等.元坝1井钻井设计与施工[J].石油钻探技术, 2008, 36(3):41-45. Wang Guanglei, Hou Jian, Yu Chengpeng, et al.Drilling design and operation of Well Yuanba-1[J].Petroleum Drilling Techniques, 2008, 36(3):41-45. [6] Payne M L, Cocking D A.Critical technologies for success in extended reach drilling[R].SPE 28293, 1994.
[7] 韩来聚, 周延军, 唐志军.胜利油田非常规油气优快钻井技术[J].石油钻采工艺, 2012, 34(3):11-15. Han Laiju, Zhou Yanjun, Tang Zhijun.High quality and fast drilling techniques for unconventional oil and gas reservoirs in Shengli Field[J].Oil Drilling Production Technology, 2012, 34(3):11-15. [8] 韩来聚, 牛洪波, 窦玉玲.胜利低渗油田长水平段水平井钻井关键技术[J].石油钻探技术, 2012, 40(3):7-13. Han Laiju, Niu Hongbo, Dou Yuling.Key drilling technologies for long displacement horizontal wells of low permeability reservoirs in Shengli Oilfield[J].Petroleum Drilling Techniques, 2012, 40(3):7-13. [9] 牛洪波.大牛地气田长水平段井眼轨迹控制方法[J].天然气工业, 2011, 31(10):64-67. Niu Hongbo.Trajectory control methods for long sections of horizontal wells at the Daniudi Gas Field[J].Natural Gas Industry, 2011, 31(10):64-67. [10] 赵金洲, 韩来聚, 唐志军.高平1井大位移水平井钻井设计与施工[J].石油钻探技术, 2010, 38(6):29-32. Zhao Jinzhou, Han Laiju, Tang Zhijun.Design and drilling of Gaoping 1 ERD horizontal well[J].Petroleum Drilling Techniques, 2010, 38(6):29-32. [11] 苏义脑.水平井井眼轨道控制[M].北京:石油工业出版社, 2000:78-79. Su Yinao.Well trajectory control for horzontal well[M].Beijing:Petroleum Industry Press, 2000:78-79. [12] 周全兴.中曲率水平井钻井技术[M].北京:科学出版社, 2000:174-175. Zhou Quanxing.Driling technology for medium-radius horzontal well[M].Beijing:Science Press, 2000:174-175. [13] 甲方手册编写组.钻井手册:甲方:上册[M].北京:石油工业出版社, 1990:205-206. Group of Drilling Manual for Part A.Drilling manual:part A:Ⅰ[M].Beijing:Petroleum Indurstry Press, 1990:205-206. [14] 高德利, 刘希圣.钻头与地层相互作用的新模型[J].石油钻采工艺, 1989, 11(5):23-28, 32. Gao Deli, Liu Xisheng.The new model for bit and foramtion interaction[J].Oil Drilling Production Technology, 1989, 11(5):23-28, 32. [15] Nyggard Runar, Hartmann Robin.Steering response for directional well in soft formation in deep water development[R].OTC 19159, 2008.
-
