The Effects of Temperature and Pressure on the Hydration Swelling Characteristics of Clay Mineral
-
摘要: 为进一步认识黏土矿物水化膨胀特性，利用新型高温高压泥页岩膨胀仪，通过试验分析了温度、压力及二者共同作用对怀俄明钠基膨润土和钙膨润土水化膨胀性能的影响，并从黏土矿物含水量、颗粒形态、毛管力及颗粒间相互作用等方面进一步分析了黏土矿物水化膨胀过程的微观变化特征。结果表明：温度和压力对黏土矿物水化膨胀性能影响显著，温度越高，黏土矿物水化膨胀量越大，且初始膨胀速率较快；压力对黏土矿物水化膨胀有2方面的作用（促进黏土矿物水化膨胀和抑制其水化膨胀），且与温度密切相关，压力越高初始膨胀速率越小；黏土矿物中含水量、颗粒形态及毛细管力等的变化均影响黏土矿物水化膨胀特性，当黏土矿物中的含水量上升时，黏土颗粒间的粘结力发生较大变化，且颗粒形态产生不均匀变化致使黏土矿物遇水产生不均匀膨胀和强大的膨胀压。Abstract: In order to find out the effects of temperature and pressure on the hydration swelling characteristics of clay mineral,based on the hydration of Wyoming sodium bentonite and calcium bentonite which is influenced by different temperature and pressure,the lab investigation of the hydration expansion characteristics of two clay mineral were carried by new HTP-3A dilatometer,and the microscopic changes in hydration expansion was analyzed from water content in clay mineral,particle morphology,capillary force and inter-particle interactions.etc.The results show that,temperature and pressure have an significant effect on hydration expansion characteristics of clay mineral and follow some certain rules.The higher the temperature,the greater the swelling capacity is and the faster the initial expansion rate is.There are two aspects of the role of pressure on the clay mineral hydration expansion closely related with temperature.And higher the pressure,the smaller the initial expansion rate is.Besides,the changes of water content in clay mineral,particle morphology,capillary force and inter-particle interactions are the important factors that the clay mineral has strong water swelling characteristics.The adhesive force between the clay particles changed greatly while the water content in clay mineral increases.The clay mineral has strong uneven water swelling characteristic and big swelling pressure which is led by the uneven changes of particle morphology.
-
Keywords:
- temperature /
- pressure /
- clay mineral /
- hydration /
- swelling /
- shale /
- laboratory testing
-
-
[1] Yu M, Chen G, Chenevert M E, et al.Chemical and thermal effects on wellbore stability of shale formations[R].SPE 71366, 2001.
[2] Mody F K, Hale A H.Borehole-stability model to couple the mechanics and chemistry of drilling-fluid/shale interactions[J].Journal of Petroleum Technology, 1993, 45(11):1093-1101.
[3] 李天太, 高德利.页岩在水溶液中膨胀规律的实验研究[J].石油钻探技术, 2002, 30(3):1-3. Li Tiantai, Gao Deli.Experimental study on shale swelling in various solutions[J].Petroleum Drilling Techniques, 2002, 30(3):1-3. [4] 徐同台, 李家库, 卢淑芹.影响砂泥岩在清水中分散性能因素的探讨[J].钻井液与完井液, 2004, 21(1):1-4. Xu Tongtai, Li Jiaku, Lu Shuqin.Investigation on influencing factors of sandstone/shale dispersing in fresh water[J].Drilling Fluid Completion Fluid, 2004, 21(1):1-4. [5] 李雄威, 孔令伟, 郭爱国, 等.考虑水化状态影响的膨胀土强度特性[J].岩土力学, 2008, 29(12):3193-3198. Li Xiongwei, Kong Lingwei, Guo Aiguo, et al.Strength characteristics of expansive soil considering effect of hydrous state[J].Rock and Soil Mechanics, 2008, 29(12):3193-3198. [6] 谭罗荣.蒙脱石晶体膨胀和收缩机理研究[J].岩土力学, 1997, 18(3):13-18. Tan Luorong.Study on mechanism of expansion and shrinkage of the montmorillonite crystal[J].Rock and Soil Mechanics, 1997, 18(3):13-18. [7] 杨振杰.泥页岩构成及泥页岩井壁表面和岩屑表面特征对井壁稳定性的影响:文献综述[J].油田化学, 2000, 17(1): 73-77, 96. Yang Zhenjie.Effects of shale composition and surface properties on borehole stability:a review[J].Oilfield Chemistry, 2000, 17(1):73-77, 96. [8] 和冰.泥页岩水化试验研究[J].断块油气田, 2008, 15(4): 105-108. He Bing.Experimental study on clay shale while under hydration[J].Fault-Block Oil Gas Field, 2008, 15(4):105-108. [9] 曾义金, 刘建立.深井超深井钻井技术现状和发展趋势[J].石油钻探技术, 2005, 33(5):1-5. Zeng Yijin, Liu Jianli.Technical status and developmental trend of drilling techniques in deep and ultra-deep wells[J].Petroleum Drilling Techniques, 2005, 33(5):1-5. [10] 刘光法, 苗锡庆.黏土矿物水化膨胀影响因素分析[J].石油钻探技术, 2009, 37(5):81-84. Liu Guangfa, Miao Xiqing.Influence factor analysis on hydration swelling of clay minerals[J].Petroleum Drilling Techniques, 2009, 37(5):81-84. [11] 冒海军, 郭印同, 王光进, 等.黏土矿物组构对水化作用影响评价[J].岩土力学, 2010, 31(9):2723-2728. Mao Haijun, Guo Yintong, Wang Guangjin, et al.Evaluation of impact of clay mineral fabrics on hydration process[J].Rock and Soil Mechanics, 2010, 31(9):2723-2728. [12] 冒海军, 杨春和, 黄小兰, 等.不同含水条件下板岩力学实验研究与理论分析[J].岩土力学, 2006, 27(9):1637-1642. Mao Haijun, Yang Chunhe, Huang Xiaolan, et al.Experimental study and theoretical analysis of slates under different saturated conditions[J].Rock and Soil Mechanics, 2006, 27(9):1637-1642.
