超短半径水平井钻井技术在注入井解堵中的应用

王羽曦

王羽曦. 超短半径水平井钻井技术在注入井解堵中的应用[J]. 石油钻探技术, 2013, 41(5): 89-92. DOI: 10.3969/j.issn.1001-0890.2013.05.017
引用本文: 王羽曦. 超短半径水平井钻井技术在注入井解堵中的应用[J]. 石油钻探技术, 2013, 41(5): 89-92. DOI: 10.3969/j.issn.1001-0890.2013.05.017
Wang Yuxi. Application of Ultra-Short Radius Horizontal Well Drilling Technology in Plugging Removal in Injectors[J]. Petroleum Drilling Techniques, 2013, 41(5): 89-92. DOI: 10.3969/j.issn.1001-0890.2013.05.017
Citation: Wang Yuxi. Application of Ultra-Short Radius Horizontal Well Drilling Technology in Plugging Removal in Injectors[J]. Petroleum Drilling Techniques, 2013, 41(5): 89-92. DOI: 10.3969/j.issn.1001-0890.2013.05.017

超短半径水平井钻井技术在注入井解堵中的应用

详细信息
    作者简介:

    王羽曦(1987—),男,山东济南人,2009年毕业于黑龙江科技大学工业工程专业,助理工程师,主要从事钻井和固井工具方面的研究工作。

  • 中图分类号: TE246

Application of Ultra-Short Radius Horizontal Well Drilling Technology in Plugging Removal in Injectors

  • 摘要: 为解决聚合物注入井的堵塞问题,研究应用了超短半径水平井钻井技术进行解堵。采用大角度锚定斜向器、复合式开修(窗)系统、高强度柔性钻杆与常规钻井设备相结合的技术方法,在设计层位实现曲率半径为3.2 m的高曲率造斜,完成造斜后运用柔性钻杆与多功能导向管进行水平段钻进,钻至设计长度,在堵塞层形成了一个长度为30 m、直径为117.5 mm的井眼,为堵塞区域重新打开注入通道。研究表明,利用超短半径水平井钻井技术来实现解堵增效是可行的,为堵塞区域重新打开注入通道、降低注入压力提供了新的技术支持。
    Abstract: To effectively solve polymer plugging problem in injectors,the application of ultra short radius horizontal well drilling was tested to remove plugging.With the combined use of large angle anchor whipstock,composite windowing system,high strength flexible drill pipes and conventional drilling equipment,high curvature build up section with a curvature radius of only 3.2 m was realized in the designed horizon.After the build-up,flexible pipe and multifunctional guiding pipe were used to finish horizontal section drilling to the target.So a 30 m long and 117.5 mm diameter hole was finished in the plugging layer and it opened up a new injection channel in the plugging zone.The study shows it is feasible to use ultra-short radius horizontal well to remove plugging,open new injection channels and lower injection pressure in polymer plugged injectors.
  • [1] 宫华,郑瑞强,范存,等.大庆油田超短半径水平井钻井技术[J].石油钻探技术,2011,39(5):19-22. Gong Hua,Zheng Ruiqiang,Fan Cun,et al.Ultra-short radius horizontal well drilling technology in Daqing Oilfield[J].Petroleum Drilling Techniques,2011,39(5):19-22.
    [2] 陈香凯,任荣权,李延琴,等.国内外短半径水平井钻井工具发展状况[J].钻采工艺,1998,21(5):48-50. Chen Xiangkai,Ren Rongquan,Li Yanqin,et al.The developmen situation of domestic and international short radius horizontal well drilling tool[J].Drilling Production Technology,1998,21(5):48-50.
    [3] 倪益民,袁永嵩,赵金海,等.胜利油田两口超短半径侧钻水平井的设计与施工[J].石油钻探技术,2007,35(6):57-59. Ni Yimin,Yuan Yongsong,Zhao Jinhai,et al.Design and implementation of two ultra-short radius side-tracking horizontal wells in Shengli Oilfield[J].Petroleum Drilling Techniques,2007,35(6):57-59.
    [4] 张义,鲜保安,赵庆波,等.超短半径径向水平井新技术及其在煤层气开采中的应用[J].中国煤层气,2008,5(3):20-24. Zhang Yi,Xian Baoan,Zhao Qingbo,et al.Study on new technologies of ultra short radius radial horizontal wells and application in coal-bed methane development[J].China Coalbed Methane,2008,5(3):20-24.
    [5] 赵峰.超短半径侧钻分支水平井曙123-0370CH井设计与施工[J].石油钻采工艺,2009,31(6):37-39. Zhao Feng.Design and application of super-short radius side-tracking technology in Shu 1-23-0370CH multilateral horizontal well[J].Oil Drilling Production Technology,2009,31(6):37-39.
    [6] 李欢欢.超短半径水平井的优化设计[J].探矿工程:岩土钻掘工程,2012,39(4):27-30. Li Huanhuan.Optimized design of ultra-short radius of horizontal well[J].Exploration Engineering:Rock Soil Drilling and Tunneling,2012,39(4):27-30.
    [7] 罗敏,赵夏.超短半径水平井柔性壳力学分析及强度评价[J].石油矿场机械,2013,42(6):31-35. Luo Min,Zhao Xia.Mechanical analysis and strength assessment of flexible shell in ultra-short radius horizontal well[J].Oil Field Equipment,2013,42(6):31-35.
    [8] 杨二龙,王景翠,高玉鑫.超短半径侧钻水平井选层技术界限研究[J].石油钻采工艺,2012,34(5):33-36. Yang Erlong,Wang Jingcui,Gao Yuxin.Layer selection technology threshold study for sidetracked horizontal wells with ultra small radius[J].Oil Drilling Production Technology,2012,34(5):33-36.
    [9] 许孝顺.TP2CX超深开窗侧钻中短半径水平井钻井技术[J].石油钻探技术,2012,40(3):126-130. Xu Xiaoshun.Drilling technology of ultra-deep sidetracking in medium/short radius horizontal Well TP2CX[J].Petroleum Drilling Techniques, 2012,40(3):126-130.
    [10] 毕刚,李根生,沈忠厚,等.超临界二氧化碳径向水平井钻井技术应用前景分析[J].石油机械,2013,41(6):14-19. Bi Gang,Li Gensheng,Shen Zhonghou,et al.Analysis of the application prospect of supercritical CO2 radial horizontal drilling technology[J].China Petroleum Machinery,2013,41(6):14-19.
    [11] 王智锋,管志川,李文飞.超短半径水平井钻头喷嘴多相流规律分析[J].煤炭学报,2011,36(7):1098-1101. Wang Zhifeng,Guan Zhichuan,Li Wenfei.Analysis on the multiphase flow rules of bit nozzle of ultra-short radius horizontal well[J].Journal of China Coal Society,2011,36(7):1098-1101.
    [12] 朱健军.侧钻超短半径水平井J37-26-P14井钻井设计与施工[J].石油钻探技术,2011,39(5):106-109. Zhu Jianjun.Drilling design and implementation of sidetracking ultra-short radius horizontal Well J37-26-P14[J].Petroleum Drilling Techniques,2011,39(5):106-109.
    [13] 史学东,吴修国,刘俊方.短半径水平井侧钻技术在沙特 HRDH-128 井中的应用[J].断块油气田,2011,18(5):672-674. Shi Xuedong,Wu Xiuguo,Liu Junfang.Application of short radius horizontal sidetracking technology in Well HRDH-128 of Saudi Arabia[J].Fault-Block Oil Gas Field,2011,18(5):672-674.
    [14] 陈香凯.国内外短半径水平井钻井工具发展状况[J].钻采工艺,1998,21(5):48-50. Chen Xiangkai.The development situation of domestic and international short radius horizontal well drilling tool[J].Drilling Production Technology,1998,21(5):48-50.
    [15] 杨立军,钱峰,南文泽,等.针对哈国侧钻超短半径水平井的工艺技术[J].吐哈油气,2006,11(2):184-189. Yang Lijun,Qian Feng,Nan Wenze,et al.Technologies of sidetracking horizontal well with ultra-short radius in Kazakstan[J].Tuha Oil Gas,2006,11(2):184-189.
    [16] 侯玉品,张永利,章梦涛.超短半径水平井开采煤层气的探讨[J].矿山机械,2005,33(6):10-11. Hou Yupin,Zhang Yongli,Zhang Mengtao.Study of ultra short radius horizontal well of coalbed gas[J].Mining Machinery,2005,33(6):10-11.
