Drilling Technologies for Horizontal Well Wei 68-FP1 in Shale Reservoir
-
摘要: 为了解决卫68-FP1 井水平段井眼尺寸小、井下摩阻大、井眼轨迹不易控制等问题,在计算不同井眼曲率下摩阻、扭矩的基础上,结合邻井实钻资料,优化了井眼轨道设计,以降低摩阻和扭矩;根据非常规水平井的实钻经验,选用"小角度螺杆+欠尺寸双稳定器"钻具组合,并对螺杆钻具的弯角和稳定器外径进行了优化,以提高井眼轨迹控制精度;选用合理密度的油基钻井液,以保证水平段的井壁稳定性;采用C1+伽马地质导向技术,以提高油层钻遇率;制定了安全钻进技术措施,以确保钻井安全。实钻结果表明:合理的井眼轨道设计能够有效降低钻进摩阻;"小角度螺杆+欠尺寸双稳定器"钻具组合能精确控制井眼轨迹,并能提高旋转钻进比例;C1+伽马地质导向技术能确保水平段始终在油层穿行。卫 68-FP1 井的顺利完成,可为泥页岩油藏水平井的钻井施工提供借鉴。Abstract: In order to overcome technical difficulties in Well Wei 68-FP1,such as slim-hole drilling in horizontal section,high friction and drag,difficult to control well trajectory,etc.,drilling technology for horizontal wells has been studied.The well path was optimized to reduce torque and drag by analyzing the data of torque and drag with different curvatures collected from adjacent wells.Combined with the early practice of horizontal wells for unconventional oil and gas reservoir,small angle PDM and undergauge bi-stabilizer assembly had been used,and optimized PDM angle and the size of stabilizers to improve precision of well trajectory control.Oil-based drilling fluids were applied and reasonable density was determined to maintain hole stabilization at horizontal section."C1+GAMMA" geo-steering technique was employed to ensure the horizontal section inside reservoir.The measures of safe drilling were adopted to ensure downhole safety.The technical application showed that reasonable well path could reduce drag in drilling,small angle PDM and undergauge bi-stabilizer" assembly were the key factors in controlling trajectory,and it could also improve the ratio of rotary drilling."C1+GAMMA" geo-steering technique could keep the well trajectory inside the reservoir.The success of Well Wei68-FP1 will provide the reference for horizontal drilling in shale reservoirs.
-
Keywords:
- shale reservoir /
- horizontal well /
- casing program /
- hole trajectory /
- Well Wei 68-FP1
-
-
[1] 闫存章,黄玉珍,葛春梅,等.页岩气是潜力巨大的非常规天然气资源[J].天然气工业,2009,29(5):1-6. Yan Cunzhang,Huang Yuzhen,Ge Chunmei,et al.Shale gas:enormous potential of unconventional natural gas resources[J].Natural Gas Industry,2009,29(5):1-6. [2] Grieser Bill,Bray Jim.Identification of production potential in unconventional reservoirs.SPE 106623,2007.
[3] 刘洪林,王红岩,刘人和,等.非常规油气资源发展现状及关键问题[J].天然气工业,2009,29(9):113-116. Liu Honglin,Wang Hongyan,Liu Renhe,et al.The present status and essential points of developing the unconventional hydrocarbon resources in China[J].Natural Gas Industry,2009,29(9):113-116. [4] 韩来聚,牛洪波,窦玉玲.胜利低渗油田长水平段水平井钻井关键技术[J].石油钻探技术,2012,40(3):7-12. Han Laiju,Niu Hongbo,Dou Yuling.Key drilling technologies for long displacement horizontal wells of low permeability reservoirs in Shengli Oilfield[J].Petroleum Drilling Techniques,2012,40(3):7-12. [5] 赵金洲,韩来聚,唐志军.高平1井大位移水平井钻井设计与施工[J].石油钻探技术,2010,38(6):29-32. Zhao Jinzhou,Han Laiju,Tang Zhijun.Design and drilling of Gaopin 1 ERD horizontal well[J].Petroleum Drilling Techniques,2010,38(6):31-34. [6] 崔海林,陈建隆,牛洪波,等.胜利油田首口小井眼长水平段水平井钻井技术[J].石油钻探技术,2011,39(5):14-18. Cui Hailin,Chen Jianlong,Niu Hongbo,et al.The first slim hole long horizontal-section horizontal well drilling technique in Shengli Oilfield[J].Petroleum Drilling Techniques,2011,39(5):14-18. [7] 裴建忠,刘天科,周飞,等.金平1浅层大位移水平井钻井技术[J].石油钻探技术,2009,37(1):87-90. Pei Jianzhong,Liu Tianke,Zhou Fei,et al.Horizontal drilling techniques to penetrate shallow formations in Well Jinping-1[J].Petroleum Drilling Techniques,2009,37(1):87-90. [8] 窦玉玲.长水平段大位移井井眼轨道优化设计[J].探矿工程:岩土钻掘工程,2011,38(7):50-52. Dou Yuling.Optimizing design of well trajectory for extended reach well with long horizontal section[J].Exploration Engineering:Rock Soil Drilling and Tunneling,2011,38(7):50-52. [9] Al-Balushi H M,Al-Rashdi M H,AL-Shandoodi M H,et al.World longest expandable open hole clad open hole liner with swelling elastomer deployed in Yibal horizontal Well.IADC/SPE 88026,2004.
[10] 刘修善.井眼轨道几何学[M].北京:石油工业出版社,2006:170-176. Liu Xiushan.Geometry of wellbore trajectory[M].Beijing:Petroleum Industry Press,2006:170-176. [11] 张炜,刘振东,刘宝峰,等.油基钻井液的推广及循环利用[J].石油钻探技术,2008,36(6):34-38. Zhang Wei,Liu Zhendong,Liu Baofeng,et al.Popularization and recycling of oil-based drilling fluid[J].Petroleum Drilling Techniques,2008,36(6):34-38. [12] 陈天成.坍塌压力与井身结构设计和井壁稳定技术关系初探[J].钻采工艺,2006,29(1):21-23. Chen Tiancheng.Relation of caving pressure with casing program and hole stability technique[J].Drilling Production Technology,2006,29(1):21-23. [13] 姚永辉,李庆铎,张永成.腰英台地区井壁稳定技术研究与应用[J].石油钻采工艺,2010,32(6):128-131. Yao Yonghui,Li Qingduo,Zhang Yongcheng.Study and application of wellbore stability techniques in Yaoyingtai Region[J].Oil Drilling Production Technology,2010,32(6):128-131. [14] 曹泽甫,张敏,刘明国,等.卫360-平1井C1+ GAMMA地质导向钻井技术[J].石油钻采工艺,2009,31(3):18-20. Cao Zefu,Zhang Min,Liu Mingguo,et al.C1+GAMMA geosteering drilling technology for Wei361-H1 Well[J].Oil Drilling Production Technology,2009,31(3):18-20. [15] 祁宏军,闫振来,唐志军,等.金平1井长水平段水平井的设计与施工[J].中外能源,2010,15(1):56-59. Qi Hongjun,Yan Zhenlai,Tang Zhijun,et al.Design and drilling of long horizontal-section well of Jinping 1 Well[J].Sino-Global Energy,2010,15(1):56-59.
