Experimental Study on Hydraulic Pulsed and Cavitating Jet Drilling Technique in Deep Wells of Tahe Oilfield
-
摘要: 塔河油田深井钻井水力能量利用效率低、机械钻速低、钻井成本高,严重制约了勘探开发速度。针对该油田钻井实际情况,结合二开φ241.3 mm井眼地层、钻具组合和水力参数,利用水力脉冲空化射流钻井技术提高机械钻速。该技术配合常规钻具和复合钻井钻具组合使用,脉冲空化射流发生器耦合脉冲射流和自振空化射流,改善井底流场及岩面应力状态,提高钻速。该技术在塔河油田进行了4口井5井次的现场试验,在常规泵压、排量、钻井液密度等参数条件下试验井深达6 162 m,试验井段与邻井相近井段在相近工况下机械钻速平均提高33.3%~74.3%,单套钻具纯钻时间超过260.0 h。试验结果表明,塔河油田二开井段砂岩、泥岩等地层配合PDC钻头应用水力脉冲空化射流钻井技术,能够很好地提高机械钻速。Abstract: Factors such as low hydraulic energy utilization efficiency and ROP,high drilling cost,etc.severely hindered the speed of petroleum exploration and development in Tahe Oilfield.In view of the real conditions of Tahe Oilfield,and drilling formation,BHA,and drilling parameters of the second drilling section φ241.3 mm wellbore,hydraulic pulsed and cavitating jet drilling were employed to increase ROP.Using conventional drilling tools and composite drilling tools,hydraulic pulsed and cavitating jet drilling technique modulates pulsed jet and cavitating jet to change flow field and rock stress state at the bottom of hole,and raise ROP.The technique had been applied 5 times in 4 wells in Tahe Oilfield.Under normal pumping pressure,flow rate and drilling fluid density,applied well depth reaches up to 6 162 m.The net drilling time of single set of drilling tool exceeded 260 h,the ROP in the applied well intervals was 33.3%-74.3% higher than adjacent wells which were similar in conditions.Field tests indicated that hydraulic pulsed and cavitating jet technique had a good adaptability to sandstone and mudstone formation of Cenozoic,Mesozoic and Palaeozoic group and different,together with PDC bit,it could enhance ROP by a large margin.
-
Keywords:
- pulsed jet /
- cavitating jet /
- penetration rate /
- field test
-
-
[1] 沈忠厚.现代钻井技术发展趋势[J].石油勘探与开发,2005,32(1):89-91. Shen Zhonghou.Development trend of the modern drilling technology[J].Petroleum Exploration and Development,2005,32(1):89-91. [2] 曲洪娜,黄中伟,李根生,等.水平井旋转射流冲砂洗井水力参数设计方法[J].石油钻探技术,2011,39(6):39-43. Qu Hongna,Huang Zhongwei,Li Gensheng,et al.Hydraulic parameters of sand-flushing with rotating jets in horizontal wells[J].Petroleum Drilling Techniques,2011,39(6):39-43. [3] 汪海阁,郑新权.中石油深井钻井技术现状与面邻的挑战[J].石油钻采工艺,2005,27(2):4-8. Wang Haige,Zheng Xinquan.Status and faced challenges of deep well drilling techniques of petrochina[J].Oil Drilling Production Technology,2005,27(2):4-8. [4] 闫光庆,张金成.中国石化超深井钻井技术现状与发展建议[J].石油钻探技术,2013,41(2):1-6. Yan Guangqing,Zhang Jincheng.Status and proposal of the Sinopec ultra-deep drilling technology[J].Petroleum Drilling Techniques,2013,41(2):1-6. [5] 周玉仓,宋勇.塔河油田大尺寸井眼提高钻井速度初探[J].石油钻探技术,2004,32(6):62-63. Zhou Yucang,Song Yong.How to increase the ROP in a large wellbore in the Tahe Oilfield[J].Petroleum Drilling Techniques,2004,32(6):62-63. [6] 王智锋.负压脉冲钻井技术理论及方法[J].石油钻采工艺,2005,27(6):13-15. Wang Zhifeng.Discussion on theory and methodology of suction-pulse drilling technique[J].Oil Drilling Production Technology,2005,27(6):13-15. [7] 王甲昌,张金成,赵国顺,等.35 MPa高压喷射钻井技术实践[J].石油钻探技术,2012,40(6):22-26. Wang Jiachang,Zhang Jincheng,Zhao Guoshun,et al.Practice of 35 MPa high pressure jet drilling[J].Petroleum Drilling Techniques,2012,40(6):22-26. [8] 李根生,沈忠厚,周长山,等.自振空化射流研究与应用进展[J].中国工程科学,2005,7(1):27-32. Li Gensheng,Shen Zhonghou,Zhou Changshan,et al.Advances in investigation and application of self-resonating cavitating water jet[J].Engineering Science,2005,7(1):27-32. [9] Fu Jiasheng,Li Gensheng,Shi Huaizhong,et al.A novel tool to improve the rate of penetration-hydraulic pulsed cavitating-jet generator[J].SPE Drilling and Completion,2012,27(3):354-361.
[10] Li Gensheng,Shi Huaizhong,Niu Jilei,et al.Hydraulic pulsed cavitating jet assisted deep drilling:an approach to improve rate of penetration.SPE 130829,2010.
[11] 史怀忠,李根生,沈忠厚,等.水力脉冲空化射流发生器配合Power V防斜打快技术[J].石油钻探技术,2009,37(1):14-17. Shi Huaizhong,Li Gensheng,Shen Zhonghou,et al.Application of hydraulic pulsation cavitating generator with Power V System in Well Fengcheng-1[J].Petroleum Drilling Techniques,2009,37(1):14-17. [12] 杨永印,沈忠厚,王瑞和.低压脉冲射流井底欠平衡钻井提高钻速机理分析[J].石油钻探技术,2002,30(5):15-16. Yang Yongyin,Shen Zhouhou,Wang Ruihe.Analysis of the mechanisms of improving ROP using low pressure pulse jetting techniques in under-balanced drilling[J].Petroleum Drilling Techniques,2002,30(5):15-16. [13] 王立锋,王杰东,冯纪成,等.塔河油田超深定向井KCl阳离子乳液聚磺钻井液技术[J].石油钻探技术,2012,40(3):73-77. Wang Lifeng,Wang Jiedong,Feng Jicheng,et al.Cationic emulsion polymer-sulfonate drilling fluid for ultra-deep directional well in Tahe Oilfield[J].Petroleum Drilling Techniques,2012,40(3):73-77. [14] 张志云,李根生,史怀忠,等.超深井水力脉冲空化射流钻井试验研究[J].石油钻探技术,2009,37(4):11-14. Zhang Zhiyun,Li Gensheng,Shi Huaizhong,et al.Experiment study on ultra-deep well hydraulic pulsating-cavitating water jet drilling[J].Petroleum Drilling Techniques,2009,37(4):11-14.
