Design and Test of Down-Hole Micro-Flow Device for Monitoring Overflow
-
摘要: 为了能够准确判断井下复杂情况,基于节流压差原理,以稳定器结构为基础,研制了一种井下压差式环空微流量测量装置,精确测量从钻杆进入井底和环空返回流体流量的微小变化,并通过MWD将井下数据实时传输至地面上,提高了微流量装置对井底复杂情况的判断能力和监测精度,实现了对井底溢流的实时监测。根据建立的微流量测量短节的理论模型,推导出溢流时流量变化与压差的关系式,采用ANSYS有限元模拟软件进行了不同工况模拟,并与现场采集的试验数据进行了分析对比。现场试验表明,微流量测量装置运行稳定、无故障,经受住了现场多种工况的考验,实际测量灵敏度达到了0.5 L/s,对监测井底溢流、特别是气侵具有明显的优势。Abstract: In order to monitor down-hole complex conditions,a new micro-flow rate measurement device,based on the structure of stabilizer and choke pressure difference theory,had been developed.It monitors the micro-flow rate changes of drilling fluid from inside drill pipe to annulus space accurately,and transmitts the data or information to the surface by MWD,improving the ability of monitoring complicated downhole conditions,and realizing real time monitoring of overflow.This article introduced the theoretical model of micro-flow rate nipple,derived mathematical formulas of flow rate change and pressure difference when oil and gas kicking,used ANSYS to simulate different working conditions,analyzed and compared theoretical calculation result with experimental data collected in the field.The field test showed that the device ran stablely for a long time,and endured every kind of trial in different conditions,the actual sensitivity had reached 0.5 L/s,with obvious superiority for monitoring bottomhole kicks,especially for gas kick.
-
Keywords:
- overflow /
- micro-flow /
- pressure difference /
- monitoring
-
-
[1] 李兴杰,何成山,马红,等.随钻测量井底压力、温度和钻井液密度的方法探讨[J].录井工程,2008,19(4):38-41. Li Xingjie,He Chengshan,Ma Hong, et al.Method of bottom hole pressure,temperature and drilling fluid density measurement while drilling[J].Mud Logging Engineering,2008,19 (4):38-41. [2] 李群生,朱礼平,李果,等.基于井下流量测量的微流量控制系统[J].石油钻探技术,2012,40(3):23-27. Li Qunsheng,Zhu Liping,Li Guo,et al.Micro-flow control system based on downhole flow measurement[J].Petroleum Drilling Techniques,2012,40(3):23-27. [3] 史玉胜,何世明,林文秀,等.微流量控压钻井技术研究现状[J].钻采工艺,2011,34(3):12-14. Shi Yusheng,He Shiming,Lin Wenxiu,et al.Research on micro-flux control pressure drilling technology[J].Drilling Production Technology,2011,34(3):12-14. [4] Salant Richard F.The use of modeling to understand malfunction and failure in mechanical seals[J].Sealing Technology,2003, 203(12):22-28
[5] 姜建胜,李奔,林立,等.国外钻井液微流量控制系统的开发与应用[J].石油机械,2008,36(2):71-74. Jiang Jiansheng,Li Ben,Lin Li,et al.Foreign drilling fluid micro flow control system and its application[J].China Petroleum Machinery,2008,36(2):71-74. [6] 石磊,陈平,胡泽,等.井下微流量控制方法[J].天然气工业,2011,31(2):79-81,84. Shi Lei,Chen Ping,Hu Ze,et al.A method of bottom-hole micro-flux control[J].Natural Gas Industry,2011,31(2):79-81,84. [7] Santos H,Catak E,Kinder J,et al.First field applications of microflux control show very positive surprises.IADC/SPE 108333,2007.
[8] 胡志坤,柳贡慧,李军,等.利用微流量控制系统实现控制压力管理钻井技术[J].特种油气藏,2009,16(2):81-84. Hu Zhikun,Liu Gonghui,Li Jun,et al.Pressure management drilling by using micro-flow control system[J].Special Oil Gas Reservoirs,2009,16(2):81-84. [9] Santos H,Reid P,McCaskill J,et al.Deepwater drilling made more efficient and cost-effective using the microflux control method and an ultralow-invasion fluid to open the mud weight window[J].SPE Drilling Completion,2007,22(3):189-196.
[10] Santos H,Catak E,Kinder J,et al.Kick detection and control in oil-based mud:real well test results using micro-flux equipment.SPE/IADC 105454,2007.
[11] Angelo Calderoni,Giorgio Giorla,Helio Santos,et al.Microflux control and E-CD continuous-circulation valves allow operator to reach HP/HT reservoirs for the first time.SPE 122270,2009.
[12] Yu X Q,He S,Cai R L.Frictional characteristics of mechanical seals with a laser-textured seal face[J].Journal of Materials Processing Technology,2002,129(1/2/3):463-466.
[13] Anonymous.GD:a new generation of gas lubricated mechanical seals for vessels in the chemical industry[J].World Pumps,2001,2001(421):40-42.
[14] 曾凌翔,李黔,梁海波,等.控制压力钻井技术与微流量控制钻井技术的对比[J].天然气工业,2011,31(2):82-84. Zeng Lingxiang,Li Qian,Liang Haibo,et al.Comparison between managed pressure drilling(MPD) and micro-flux control(MFC) drilling[J].Natural Gas Industry,2011,31(2):82-84.
