基于机械比能理论的钻头磨损监测新方法

樊洪海, 冯广庆, 肖伟, 马金良, 叶志, 赵聪

樊洪海, 冯广庆, 肖伟, 马金良, 叶志, 赵聪. 基于机械比能理论的钻头磨损监测新方法[J]. 石油钻探技术, 2012, 40(3): 116-120. DOI: 10.3969/j.issn.1001-0890.2012.03.024
引用本文: 樊洪海, 冯广庆, 肖伟, 马金良, 叶志, 赵聪. 基于机械比能理论的钻头磨损监测新方法[J]. 石油钻探技术, 2012, 40(3): 116-120. DOI: 10.3969/j.issn.1001-0890.2012.03.024
Fan Honghai, Feng Guangqing, Xiao Wei, Ma Jinliang, Ye Zhi, Zhao Cong. New Approach for Real-Time Bit Wear Monitoring Based on the Theory of MSE[J]. Petroleum Drilling Techniques, 2012, 40(3): 116-120. DOI: 10.3969/j.issn.1001-0890.2012.03.024
Citation: Fan Honghai, Feng Guangqing, Xiao Wei, Ma Jinliang, Ye Zhi, Zhao Cong. New Approach for Real-Time Bit Wear Monitoring Based on the Theory of MSE[J]. Petroleum Drilling Techniques, 2012, 40(3): 116-120. DOI: 10.3969/j.issn.1001-0890.2012.03.024

基于机械比能理论的钻头磨损监测新方法

详细信息
    作者简介:

    樊洪海(1962-),男,1984年毕业于华东石油学院钻井工程专业,2001年获石油大学(北京)油气井工程专业博士学位,教授,博士生导师,主要从事地层压力确定、油气井信息工程及油气井流体力学等方面的教学与研究工作.

  • 中图分类号: TE921+.1

New Approach for Real-Time Bit Wear Monitoring Based on the Theory of MSE

  • 摘要: 现有基于机械比能理论的钻头磨损监测方法,都是通过机械比能趋势线对钻头钝化趋势作定性分析,没有一种定量计算钻头磨损等级的有效方法。在前人研究成果的基础上,选取合理机械比能模型,通过优化钻头扭矩回归数据对其进行了优化;综合考虑钻头设计参数、切削结构、钻井参数及钻头磨损等的影响,选取了合适的牙轮钻头和PDC钻头钻速方程,提出了一种定量计算与定性分析相结合的钻头磨损监测新方法。该方法充分考虑了钻速、钻压、转速、扭矩以及钻头设计参数等因素,采用钻速方程和测录井数据计算机械比能、岩石抗压强度和钻头磨损等级分级系数。该方法在南海油田宝岛区块A井、准噶尔盆地风城区块B井、吐哈油田某区块C井等的多个井段进行了PDC钻头和牙轮钻头的磨损监测,结果表明,较之钻头磨损实测数据,PDC钻头的平均相对误差为9.87%,牙轮钻头为21.15%,即新方法能有效监测钻头磨损情况且更适用于PDC钻头。
    Abstract: Previous bit wear monitoring methods which based on theory of MSE analyzed the normal trend line of MSE,which is qualitative analysis method.There was not a quantitative calculation method for bit wear.This paper chooses a reasonable torque calculation model to optimize the MSE calculation model and chooses appropriate ROP equation of PDC and cone bits which consider bit design parameter,cutting structure,drilling parameters and bit wear fully.This paper proposes a new method that combines the qualitative analysis and considering such factors as ROP,WOB,RPM,torque and bit design parameters etc,the new approach uses ROP models and some logging data to calculate MSE,Cs and bit wear grade factor.It has been applied in several bits wear monitoring,such as Well B in Junggar Basin,Well A in South China Sea Basin and Well C in Tuha Basin.Compared with measured data,the relative error of accuracy of calculated results of PDC bits is 9.87%,and that of cone bits is 21.15%,therefore,this new method has great accuracy and is more suitable for PDC bits.
  • [1]

    Pessier R C,Fear M J.Quantifying common drilling problems with mechanical specific energy and a bit-specific coefficient of sliding friction.SPE 24584,1992.

    [2]

    Waughman R J,Kenner J V,Moore R A,et al.Real-time specific energy monitoring reveals drilling inefficiency and enhances the understanding of when to pull worn PDC bits.SPE/IADC 74520,2002.

    [3]

    Rafatian N,Miska S,Ledgerwood Ⅲ L W,et al.Experimental study of MSE of a single PDC cutter under simulated pressurized conditions.SPE/IADC 119302,2009.

    [4]

    Waughman R J,Kenner J V,Moore R A.Real-time specific energy monitoring enhances the understanding of when to pull worn PDC bits[J].SPE Drilling Completion,2003,18(1):59-67.

    [5]

    Teale R.The concept of specific energy in rock drilling[J].International Journal of Rock Mechanics and Mining Sciences Geomechanics Abstracts,1965,2(1):57-73.

    [6]

    Rabia H.Specific energy as a criterion for bit selection[J].Journal of Petroleum Technology,1985,37(7):1225-1229.

    [7]

    Pessier R C.Different shales dictate fundamentally different strategies in hydraulics,bit selection,and operating practices.SPE 28322,1994.

    [8] 徐济银,王吉东,蒋杰.比能在钻头选型中的应用[J].钻采工艺,1996,19(6):86-89. Xu Jiyin,Wang Jidong,Jiang Jie.The application of specific energy in bits selection[J].Drilling Production Technology,1996,19(6):86-89.
    [9] 樊顺利,郭学增.用比能法评判钻头[J].石油钻采工艺,1993,15(2):20-24. Fan Shunli,Guo Xuezeng.Specific energy as a criterion for bit evaluation[J].Oil Drilling Production Technology,1993,15(2):20-24.
    [10] 景宁,樊洪海,翟应虎,等.基于比能理论的钻头工作状态监测方法[J].断块油气田,2011,18(4):538-540. Jing Ning,Fan Honghai,Zhai Yinghu,et al.Monitoring method of drilling bit working status with mechanical specific energy theory[J].Fault-Block Oil Gas Field,2011,18(4): 538-540.
    [11]

    Hareland G,Wu A,Rashidi B.New drilling rate models for tricone bits and its application to rock confined compressive strength:proceeclings of the 44th US Rock Mechanics Symposiun and 5th US-Canadia Rock Mechanics Syposium,Salt Lake City,June 27-30,2010.

    [12]

    Motahari H R,Hareland G,James J A.Improved drilling efficiency technique using integrated PDM and PDC bit paremeters[J].Journal of Canadian Petroleum Technology,2010,49(10):45-52.

    [13]

    Rashidi B,Hareland G,Wu Z.New approach in real-time bit wear prediction.SPE 136008,2010.

    [14]

    Mohan K,Adil F,Samuel R.Tracking drilling efficiency using hydro-mechanical specific energy.SPE/IADC 119421,2009.

    [15]

    Armenta M.Identifying inefficient drilling conditions using drilling-specific energy.SPE 116667,2008.

    [16]

    Bailey J R,Gupta V,Ertas D,et al.Drilling vibrations modeling and field validation.IADC/SPE 112650,2008.
