The Application of Dragged Multistage Hydrojet-Fracturing in Horizontal Well with Screen Pipe Completion
-
摘要: 为实现筛管水平井储层有效压裂改造和降低施工风险,对拖动式水力喷射分段压裂工艺进行了优化改进。根据水力喷射分段压裂工艺技术射流增压、射流密封和降低起裂压力的基本原理,结合筛管水平井的井况及特点,将拖动式水力喷射分段压裂工具与滑套式工具相组合,融合相应的施工工艺,降低了筛管井压裂管柱砂卡风险。成功对筛管水平井SA井实施3段加砂压裂,最高施工砂比达到40%,压裂规模72 m3,压裂管柱成功上提出井。裂缝监测结果表明,在水平段压裂位置产生了3条走向明显的裂缝,裂缝长度均为110~135 m,与设计长度吻合较好,实现了储层分段压裂目的。该井产油量由原来的4.0~5.0 t/d提高到25.9 t/d,压裂增产效果明显。Abstract: In order to stimulate horizontal wells with screen completion and decrease the risk in treatment,the dragged multistage hydrojet-fracturing(DHJF)was improved.Considering the characteristics of hydrojet technique,namely boosting pressure,sealing mechanism and decreasing the initial fracturing pressure,and the characteristic of screen completion,the jetting tool and sliding sleeve tools were combined and assembled at the end of treatment pipes.Then the DHJF was optimized to solve the problem of sanding in the fracturing string.The sanding risk of fracturing string could be greatly decreased.A horizontal well under screen completion was successfully fractured by DHJF.With 72 m3 proppants in total and the highest sand ratio of 40%,the length of three hydraulic fractures reached 110-135 m.Finally,the fracturing string was pulled out of the well.Micro-seismic mapping indicated that three hydraulic fractures were placed at strategically selected locations which improved the formation permeability.Daily oil production of Well SA increasede from 4.0-5.0 t/d to 25.9 t/d,proving good stimulation result in this well.
-
-
[1] Surjaatmadja J B,Grundmann S R,McDaniel B W,et al.Hydrajet fracturing:an effective method for placing many fractures in openhole horizontal wells.SPE 48856,1998.
[2] McDaniel B W,Surjaatmadja J B,East Loyd E Jr,et al.Use of hydrajet perforating to improve fracturing success sees global expansion.SPE 114695,2008.
[3] Divesh C,Nuratas G,Colt A.Pinpoint-fracturing technology improves efficiencies while solving issues with conventional hydraulic-fracturing processes.SPE 151559,2012.
[4] 李宪文,赵文轸.水力射孔射流压裂工艺在长庆油田的应用[J].石油钻采工艺,2008,30(4):67-70. Li Xianwen,Zhao Wenzhen.Application of hydraulic perforation jet fracturing technology in Changqing Oilfield[J].Oil Drilling Production Technology,2008,30(4):67-70. [5] Li Gensheng,Huang Zhongwei,Tian Shouceng,et al.Investigation and application of multistage hydrajet-fracturing in oil and gas well stimulation in China.SPE 131152,2010.
[6] 侯东红,白建文,刘雄明,等.水力喷射压裂改造技术在直井上的应用[J].油气井测试,2009,18(4):42-44. Hou Donghong,Bai Jianwen,Liu Xiongming,et al.Application of hydraulic jet fracturing technology in vertical wells[J].Well Testing,2009,18(4):42-44. [7] Qu Hai,Li Gensheng,Huang Zhongwei,et al.The boosting mechanism and effects in cavity during hydrajet fracturing process[J].Petroleum Science and Technology,2010,28(13):1345-1350.
[8] 曲海,李根生,黄中伟,等.水力喷射压裂孔道内部增压机理研究[J].中国石油大学学报:自然科学版,2010,34(5):73-75. Qu Hai,Li Gensheng,Huang Zhongwei,et al.Boosting mechanism in hydrajet-fracturing cavity[J].Journal of China University of Petroleum:Edition of Natural Science,2010,34(5):73-75. [9] 曲海,李根生,黄中伟,等.水力喷射压裂孔内压力分布研究[J].西南石油大学学报:自然科学版,2011,33(4):85-88. Qu Hai,Li Gensheng,Huang Zhongwei,et al.Jetting pressure field in formation cavities during hydrajet fracturing[J].Journal of Southwest Petroleum University:Science Technology Edition,2011,33(4):85-88. [10] 曲海,李根生,黄中伟,等.水力喷射分段压裂密封机理研究[J].石油学报,2011,32(3):514-517. Qu Hai,Li Gensheng,Huang Zhongwei,et al.Sealing mechanism of the hydrajet stepwise fracturing[J].Acta Petrolei Sinica,2011,32(3):514-517. [11] Li Gensheng,Niu Jilei,Song Jian,et al.Abrasive water jet perforation:an alternative approach to enhance oil production[J].Petroleum Science and Technology,2004,22(5/6):491-504.
[12] Tian Shouceng,Li Gensheng,Huang Zhongwei,et al.Investigation and application for multistage hydrajet-fracturing with coiled tubing[J].Petroleum Science and Technology,2009,27(13):1494-1502.
[13] 李根生,牛继磊,刘泽凯,等.水力喷砂射孔机理试验研究[J].石油大学学报:自然科学版,2002,26(2):31-34. Li Gensheng,Niu Jilei,Liu Zekai,et al.Experimental study on mechanisms of hydraulic sand blasting perforation for improvement of oil production[J].Journal of the University of Petroleum,China:Edition of Natural Science,2002,26(2):31-34. [14] Huang Zhongwei,Niu Jilei,Li Gensheng,et al.Surface experiment of abrasive water jet perforation[J].Petroleum Science and Technology,2008,26(6):726-733.
