Manufacture and Properties Analysis of Rubber for Water Swelling Packer
-
摘要: 胶筒是自膨胀封隔器的关键部件,作为胶筒原料的吸水膨胀橡胶其性能对自膨胀封隔器的封隔效果起决定作用,但国内目前缺乏对胶筒专用吸水膨胀橡胶及其合成材料的深入研究。为提高遇水膨胀橡胶的抗盐能力,用丙烯酸钠与丙烯酰胺共聚制备了遇水膨胀橡胶中起吸水作用的吸水树脂,试验分析了吸水树脂吸水性能的影响因素,发现参与反应的各单体的配比、单体总的质量浓度都可影响吸水树脂的吸水能力。将丁腈橡胶、自制吸水树脂及其他原料共混制得了遇水膨胀橡胶,测试了溶液矿物质种类、浓度和pH值,以及温度、吸水时间对橡胶膨胀能力的影响,并进行了遇水膨胀橡胶的抗拉伸试验,试验证明以上各因素对橡胶的膨胀能力都有影响,且制备的遇水自膨胀橡胶抗拉性能良好。对应用自制遇水膨胀橡胶的自膨胀封隔器进行了室内承压能力测试,试验结果表明,自膨胀封隔器承压能力达到14 MPa,可满足浅井现场施工要求。Abstract: Packer rubber element is the critical component of water swelling packer.The packing effect of packer is dependent on the property of water-swelling rubber.domestic in-depth research on rubber of this kind of packer and its synthetic materials is rare.Water absorbent resin is synthesized from sodium acrylate and acrylamide copolymerization in order to raise its resistance to salt.Factors which affect the water-absorption of resin are studied,and it is found that the water absorption of resin can be adjusted through changing monomer mixture rate and concentration.Nitrile butadiene rubber and water-absorbent resin are blended to make water swelling rubber.The influences of concentration and pH value of saline solution on the rubber swelling ability are studied.Tensile strength of the rubber was tested,too.Results of tests indicate that swelling ability of rubber depends on all factors mentioned above.Tensile strength of water swelling rubber made by us is very good.Finally,laboratory tests of isolation ability of the water swelling packer made with our synthesized rubber were conducted,the pressure bearing capacity up to 14 MPa,it can meet the requirement of shallow well opertation.
-
Keywords:
- expansion /
- packer /
- packer rubber /
- synthetic resin /
- synthetic rubber /
- water-absorption capacity /
- laboratory test
-
-
[1] 徐鑫,魏新芳,余金陵.遇油遇水自膨胀封隔器的研究与应用[J].石油钻探技术,2009,37(6):67-69. Xu Xin,Wei Xinfang,Yu Jinling.Researches and applications of oil/water expandable packers[J].Petroleum Drilling Techniques,2009,37(6):67-69. [2] 王兆会,曲从锋.遇油气膨胀封隔器在智能完井系统中的应用[J].石油机械,2009,37(8):96-98. Wang Zhaohui,Qu Congfeng.Application of oil/gas expandable packers in intelligent well completion system[J].China Petroleum Machinery,2009,37(8):96-98. [3] 韩旭,李锐,靳宝军,等.膨胀橡胶封隔器在油气井固井中的应用现状[J].钻采工艺,2011,34(2):15-17. Han Xu,Li Rui,Jin Baojun,et al.Application of swell elastomer packer in well cementation[J].Drilling Production Technology,2011,34(2):15-17. [4] 沈泽俊,高向前,童征,等.遇油自膨胀封隔器的研究与应用[J].石油机械,2010,38(1):39-40,43. Shen Zejun,Gao Xiangqian,Tong Zheng,et al.Research and application of the self-expandable packer[J].China Petroleum Machinery,2010,38(1):39-40,43. [5] 沈泽俊,童征,张国文,等.遇水自膨胀封隔器研制及在水平井中的应用[J].石油矿场机械,2011,40(2):38-41. Shen Zejun,Tong Zheng,Zhang Guowen,et al.RD of water-swelling packer and field application in horizontal well[J].Oil Field Equipment,2011,40(2):38-41. [6] 潘美,郝明芝,张玉玲,等.特种防水材料:遇水膨胀橡胶[J].橡胶工业,1997,44(6):369-372. Pan Mei,Hao Mingzhi,Zhang Yuling,et al.Watertight special material:water swelling rubber[J].China Rubber Industry,1997,44(6):369-372. [7] 张群,王振华,方伟,等.吸水膨胀橡胶的研究进展[J].世界橡胶工业,2010,37(3):19-24. Zhang Qun,Wang Zhenhua,Fang Wei,et al.Research development of water-absorbent rubber[J].World Rubber Industry,2010,37(3):19-24. [8] 李建颖.高吸水和高吸油性树脂[M].北京:化学工业出版社,2005:415. Li Jianying.High water/oil absorbent polymers[M].Beijing: Chemical Industry Press,2005:415. [9] 马斐,程冬炳,王颖,等.聚丙烯酸类高吸水性树脂的合成及吸水机理研究进展[J].武汉工程大学学报,2011,33(1):4-9. Ma Fei,Cheng Dongbing,Wang Ying,et al.Research trend on reaction principle and water absorption mechanism of polyacrylic acid superabsorbent polymers[J].Journal of Wuhan Institute of Technology,2011,33(1):4-9. [10] Miyata N,Yokoyama M,Sakata I.Properties of highly water-absorptive hydroxyethylcellulose graft copolymers:viscoelasticity and moisture sorption[J].Journal of Applied Polymer Science,1995,55(2):201-208.
[11] 李秀辉,吴江渝,杨鹏,等.基于SAP吸水膨胀橡胶的耐温耐盐性能[J].材料工程,2010(4):33-35,41. Li Xiuhui,Wu Jiangyu,Yang Peng,et al.Study on thermal/salty tolerance of SAP-based water swelling rubber[J].Journal of Materials Engineering,2010(4):33-35,41.
