Development and Performance Evaluation of an Organic Silicon Water-Absorbing Expansion Selective Water Shutoff Agent
-
摘要: 油井出水后会造成油井出砂、井底流压增大、自喷井停喷、井下设备被腐蚀,甚至造成严重的油井故障。国内外已研制开发的选择性堵水剂存在选择性不够理想、成本较高等不足,推广应用受到限制。采用水溶液聚合反应,在阳离子、阴离子及非离子单体的三元共聚物中引入有机硅活性官能团,合成了一种新型有机硅吸水膨胀型选择性堵水剂,其配方为:40 mL水+6.2 g丙烯酰胺+5.0 g甲基硅酸+4.2 g 2-丙烯酰胺-2-甲基丙磺酸+1.0 g四甲基氯化铵+0.03 g硅偶联剂GL-1+0.10 g硅偶联剂GL-2+0.025 g K2S2O8+0.05 g NaHSO3;合成条件是在60 ℃下反应8 h。性能评价试验结果表明:新型选择性堵水剂对油水具有很好的选堵性,堵水率在95%以上,堵油率低于10%;可选择封堵高渗透大孔道及出水层位,对低渗透油层损害小;具有较高的封堵强度,水的突破压力梯度大于10 MPa/m,满足油井现场堵水作业的工程要求。Abstract: Water production from oil wells would result in sand production,bottom-hole flowing pressure increase,flowing stop of the natural flowing well,underground equipments corrosion, and even more serious accidents of oil wells.The application of selective water shutoff agent developed worldwide is limited due to their undesirable selectivity and high cost.Organic silicon active functional groups were introduced into anionic,cationic and non-ionic monomer terpolymer through water solution polymerization reaction,a new organic silicon water-absorbing expansion selective water shutoff agent was developed.In the synthetic formula,it contains water 40 mL,acrylamide 6.2 g,methanesiliconic acid 5.0 g,2-acrylamide-2-methyl propane sulfonic acid 4.2 g,tetramethylammonium chloride 1.0 g,organosilicon coupler GL-1 0.03 g,organosilicon coupler GL-2 0.10 g,K2S2O8 0.025 g,and NaHSO3 0.05 g.The synthetic condition was to reacte for 8 h under 60 ℃.Test results of the performance evaluation showed that:new selective water shutoff agent has good selective plugging ability for oil and water,water shutoff rate is more than 95% while oil shutoff rate is lower than 10%.It can selectively seal high penetration throats and water layers while have little damages to low permeability reservoirs.It also has high sealing strength,and its water breakthrough pressure gradient is more than 10 MPa/m,which meets the engineering requirements of water shutoff for oil well on-site.
-
-
[1] 严曦,岳湘安,万新安.有机—无机复合-1凝胶调剖剂的研制[J].内蒙古石油化工,2009,20(8):20-23. Yan Xi,Yue Xiang’an,Wan Xin’an.Preparation for organic-inorganic composite gel profile control agent[J].Inner Mongolia Petrochemical Industry,2009,20(8):20-23. [2] 王显光,苏长明,于培志,等.钻井用高分子冻胶堵水剂的室内研究[J].石油钻探技术,2005,37(3):26-29. Wang Xianguang,Su Changming,Yu Peizhi,et al.Laboratory study of macromolecule gelatin:an oil well water-plugging agent[J].Petroleum Drilling Techniques,2005,37(3):26-29. [3] 罗宪波,蒲万芬,武海燕,等.新型裂缝性低渗透油藏堵水剂性能评价[J].石油钻采工艺,2005,27(2):64-66. Luo Xianbo,Pu Wanfen,Wu Haiyan.Performance evaluation of new water blocking agent in low permeability reservoir with fractures[J].Oil Drilling Production Technology,2005,27(2):64-66. [4] Bruton J R,Ivan C D,Heinz T J.Lost circulation control:evolving techniques and strategies to reduce downhole mud losses.SPE 67735,2001.
[5] Summers L E,Allison J D.Method for plugging subterranean formations with siliceous gels:US,4901797.1990-02-20.
[6] Eoff.L S,Szymanski M J.Well treatment fluid and methods for blocking permeability of a subterranean zone:US,7128148.2006-10-31.
[7] 何龙.南海西部油田堵水技术研究.东营:中国石油大学石油工程学院,2009. He Long.Research on water shutoff technology in the western zone of South China Sea oil field.Dongying:China University of Petroluem,College of Petroluem Engineering,2009. [8] 姜维东.Cr3+聚合物凝胶性能特征及其应用效果研究.大庆:大庆石油学院石油工程学院,2009. Jiang Weidong.The property characteristics and its application effect study of Cr3+ polymer gel.Daqing:Daqing Petroleum Institute,College of Petroleum Engineering,2009. [9] Stavland A,Andersen K I,Sandy A B,et al.How to blocking a plugging gel system for bullhead selective water shutoff:from laboratory to field.SPE 99729,2006.
[10] Eoff Larry S,Keener Krista L.Methods and compositions for cementing wells:US,7063153.2006-06-20.
[11] Horton R L,Prasek B,Growcock F B,et al.Prevention and treatment of lost circulation with cross-linked polymer material:US,7098172.2006-08-29.
[12] 冯兵,赵仁宝,李文魁,等.气井凝胶堵水剂配方优化及性能评价[J].石油钻探技术,2010,38(2):67-71. Feng Bing,Zhao Renbao,Li Wenkui,et al.Formulation optimization and performance evaluation of water plugging reagent in gas wells[J].Petroleum Drilling Techniques,2010,38(2):67-71. [13] 穆海朋.钻井中封堵漏层和水层的理论研究及新型堵剂的研制.东营:中国石油大学石油工程学院,2009. Mu Haipeng.Theoretical study on plugging leakage zone water zone in drilling and preparation of new plugging agent.Dongying:China University of Petroluem,College of Petroluem Engineering,2009.
