Key Technologies for Improving Drilling and Completion Speed in Shunbei Ultra-Deep and Ultra-High-Temperature Oil and Gas Field
-
摘要:
顺北超深超高温断控型油气藏地质条件复杂、埋藏深，地层温度高、强度高，钻完井过程中漏失、坍塌、气侵、井斜和仪器工具失效等井下故障与复杂情况频发，严重制约了该油气藏的高效勘探开发。为此，针对古生界钻速慢的问题，研究了地层可钻性，优选高效钻头和大扭矩长寿命螺杆，推广应用预弯曲防斜打快技术；针对储层温度高、定向难度大的问题，推广应用高温随钻工具，配套井眼轨道设计和井眼控制技术；针对窄间隙漏失问题，采用“随钻封堵+段塞堵漏”和高性能水基钻井液；针对漏溢同层问题，应用控压钻井和平推法压井技术；针对长裸眼固井质量差的问题，采用超高温固井水泥浆体系和配套工艺。综合上述技术，研究形成了顺北超深超高温油气藏钻完井提速关键技术。该技术在顺北不同条带6口井进行了应用，基本解决了超深超高温油气藏钻井提速困难、漏溢同存等问题，钻井周期同比缩短了55.0%，机械钻速提高了184.2%。研究结果为顺北超深超高温断控型油气藏高效勘探开发提供了技术支持。
Abstract:The Shunbei ultra-deep and ultra-high-temperature fault-controlled oil and gas reservoir complex geology, large burial depth, high formation temperature, and high formation strength. During the drilling and completion process, complex situations such as leakage, collapse, gas invasion, wellbore deviation, and instrument tool failure are encountered frequently, seriously restricting the efficient exploration and development of the oil and gas field. Therefore, in order to improve the drilling speed in the Paleozoic, the drillability of the formation was investigated, and high-efficiency drill bits and long-life screws with large torque were selected, meanwhile pre-bending anti-deviation and fast drilling technology were promoted and employed. To address the issues of high reservoir temperature and difficulty in orientation, the application of high-temperature drilling tools was promoted, along with trajectory design and control technology. To avoid narrow gap leakage, “plugging while drilling + slug loss circulation control” and high-performance water-based drilling fluid were adopted. To address the issue of leakage and overflow in the same layer, managed pressure drilling and bull head method were applied to kill the well. In view of poor quality in long open hole cementing, an ultra-high-temperature cementing slurry system and supporting technology were adopted, and key technologies for improving drilling and completion speed in Shunbei ultra-deep and ultra-high-temperature oil and gas oilfield came into being. The technologies were applied in six wells in different zones of Shunbei, basically solving the problems of difficult drilling speed improvement and simultaneous leakage and overflow in ultra-deep and ultra-high-temperature oil and gas reservoirs. The drilling duration was shortened by 55.0% year on year, and the rate of penetration (ROP) was increased by 184.2%. The research results provided technical support for efficient exploration and development of Shunbei ultra-deep and ultra-high-temperature fault-controlled oil and gas reservoirs.
-
-
表 1 顺北油气田预弯曲防斜打快工艺应用效果
Table 1 Application effect of pre-bending anti-deviation and fast drilling technology in Shunbei Oil and Gas Field
井号 井眼直径/
mm却尔却克组井段/
m钻压/
kN机械钻速/
（m·h−1）XB803X 241.3 5 819～7 660 100～130 7.60 XB81X 241.3 5 550～7 476 100～140 7.58 XB82X 241.3 5 710～7 618 80～140 6.65 XB83X 241.3 6 176～7 821 120～140 8.53 XB84X 241.3 6 226～7 846 80～130 8.23 XB8-2H 241.3 6 508～7 710 80～140 7.01
下载: 导出CSV
-
[1] 陈宗琦,刘湘华,白彬珍,等. 顺北油气田特深井钻井完井技术进展与发展思考[J]. 石油钻探技术,2022,50(4):1–10. doi: 10.11911/syztjs.2022069 CHEN Zongqi, LIU Xianghua, BAI Binzhen, et al. Technical progress and development consideration of drilling and completion engineering for ultra-deep wells in the Shunbei Oil & Gas Field[J]. Petroleum Drilling Techniques, 2022, 50(4): 1–10. doi: 10.11911/syztjs.2022069
[2] 陈宗琦,刘景涛,陈修平. 顺北油气田古生界钻井提速技术现状与发展建议[J]. 石油钻探技术,2023,51(2):1–6. doi: 10.11911/syztjs.2023033 CHEN Zongqi, LIU Jingtao, CHEN Xiuping. Up-to-date ROP improvement technologies for drilling in the Paleozoic of Shunbei Oil & Gas Field and suggestions for further improvements[J]. Petroleum Drilling Techniques, 2023, 51(2): 1–6. doi: 10.11911/syztjs.2023033
[3] 李文霞,王居贺,王治国,等. 顺北油气田超深高温水平井井眼轨迹控制技术[J]. 石油钻探技术,2022,50(4):18–24. doi: 10.11911/syztjs.2022073 LI Wenxia, WANG Juhe, WANG Zhiguo, et al. Wellbore trajectory control technologies for ultra-deep and high-temperature horizontal wells in the Shunbei Oil & Gas Field[J]. Petroleum Drilling Techniques, 2022, 50(4): 18–24. doi: 10.11911/syztjs.2022073
[4] 李凡,李大奇,金军斌,等. 顺北油气田辉绿岩地层井壁稳定钻井液技术[J]. 石油钻探技术,2023,51(2):61–67. doi: 10.11911/syztjs.2023041 LI Fan, LI Daqi, JIN Junbin, et al. Drilling fluid technology for wellbore stability of the diabase formation in Shunbei Oil & Gas Field[J]. Petroleum Drilling Techniques, 2023, 51(2): 61–67. doi: 10.11911/syztjs.2023041
[5] 刘湘华,刘彪,杜欢,等. 顺北油气田断裂带超深水平井优快钻井技术[J]. 石油钻探技术,2022,50(4):11–17. doi: 10.11911/syztjs.2022072 BAI Binzhen, ZENG Yijin, GE Hongkui. Key technologies for the drilling of ultra-deep horizontal Well Shunbei 56X[J]. Petroleum Drilling Techniques, 2022, 54(6): 11–17. doi: 10.11911/syztjs.2022072
[6] 陈修平,高雷雨,刘景涛,等. 顺北油气田却尔却克组井壁失稳机理及应对措施[J]. 钻井液与完井液,2021,38(1):35–41. doi: 10.3969/j.issn.1001-5620.2021.01.006 CHEN Xiuping, GAO Leiyu, LIU Jingtao, et al. Mechanisms of borehole wall destabilization in Que’er’Que’ke Formation in Shunbei Oil and Gas Field and measures dealing with the borehole wall collapse[J]. Drilling Fluid & Completion Fluid, 2021, 38(1): 35–41. doi: 10.3969/j.issn.1001-5620.2021.01.006
[7] 赵常举,杨志,林坤. 顺北井区优快钻井提速技术研究与应用[J]. 中国石油和化工标准与质量,2020,40(1):248–250. doi: 10.3969/j.issn.1673-4076.2020.01.124 ZHAO Changju, YANG Zhi, LIN Kun. Research and application of high-speed drilling technology in Shunbei Well Area[J]. China Petroleum and Chemical Standard and Quality, 2020, 40(1): 248–250. doi: 10.3969/j.issn.1673-4076.2020.01.124
[8] 白彬珍,曾义金,葛洪魁. 顺北56X特深水平井钻井关键技术[J]. 石油钻探技术,2022,50(6):49–55. doi: 10.11911/syztjs.2022114 BAI Binzhen, ZENG Yijin, GE Hongkui. Key technologies for the drilling of ultra-deep horizontal Well Shunbei 56X[J]. Petroleum Drilling Techniques, 2022, 50(6): 49–55. doi: 10.11911/syztjs.2022114
[9] 刘湘华,杜欢,刘彪,等. 顺北Ⅳ号条带超深高温定向井钻井关键技术[J]. 石油钻采工艺,2022,44(6):665–670. LIU Xianghua, DU Huan, LIU Biao, et al. Key technology of directional drilling in the ultra-deep high-temperature IV belt, the Shunbei Oilfield[J]. Oil Drilling & Production Technology, 2022, 44(6): 665–670.
[10] 李双贵,罗江,于洋,等. 顺北5号断裂带南部压力剖面建立及井身结构优化[J]. 石油钻探技术,2023,51(1):9–15. doi: 10.11911/syztjs.2022037 LI Shuanggui, LUO Jiang, YU Yang, et al. Establishing pressure profiles and casing program optimization in the Southern Shunbei No. 5 fault zone[J]. Petroleum Drilling Techniques, 2023, 51(1): 9–15. doi: 10.11911/syztjs.2022037
[11] 马永生,蔡勋育,云露,等. 塔里木盆地顺北超深层碳酸盐岩油气田勘探开发实践与理论技术进展[J]. 石油勘探与开发,2022,49(1):1–17. doi: 10.11698/PED.2022.01.01 MA Yongsheng, CAI Xunyu, YUN Lu, et al. Practice and theoretical and technical progress in exploration and development of Shunbei ultra-deep carbonate oil and gas field, Tarim Basin, NW China[J]. Petroleum Exploration and Development, 2022, 49(1): 1–17. doi: 10.11698/PED.2022.01.01
[12] 刘景涛,黄勇,李文霞. 顺北二叠系火成岩地层抗钻特性预测及应用研究[J]. 钻采工艺,2022,45(1):47–52. doi: 10.3969/J.ISSN.1006-768X.2022.01.007 LIU Jingtao, HUANG Yong, LI Wenxia. Prediction of anti-drilling characteristics of Permian igneous rock strata and its application in Shunbei Block[J]. Drilling & Production Technology, 2022, 45(1): 47–52. doi: 10.3969/J.ISSN.1006-768X.2022.01.007
[13] 刘维,高德利. 大齿快切PDC钻头提速研究与现场试验[J]. 天然气工业,2022,42(9):102–110. doi: 10.3787/j.issn.1000-0976.2022.09.010 LIU Wei, GAO Deli. Research and field test of large-tooth and rapid-cutting PDC bit for ROP enhancement[J]. Natural Gas Industry, 2022, 42(9): 102–110. doi: 10.3787/j.issn.1000-0976.2022.09.010
[14] 邓虎,贾利春. 四川盆地深井超深井钻井关键技术与展望[J]. 天然气工业,2022,42(12):82–94. DENG Hu, JIA Lichun. Key technologies for drilling deep and ultra-deep wells in the Sichuan Basin: current status, challenges and prospects[J]. Natural Gas Industry, 2022, 42(12): 82–94.
[15] 史今雄,赵向原,潘仁芳,等. 川中地区震旦系灯影组碳酸盐岩天然裂缝特征及其对气井产能影响[J]. 石油与天然气地质,2023,44(2):393–405. doi: 10.11743/ogg20230211 SHI Jinxiong, ZHAO Xiangyuan, PAN Renfang, et al. Characteristics of natural fractures in carbonate reservoirs and their impacts on well productivity in the Sinian Dengying Formation, central Sichuan Basin[J]. Oil & Gas Geology, 2023, 44(2): 393–405. doi: 10.11743/ogg20230211
[16] 于得水,汪露,刘仕银,等. 顺北16X井二次侧钻超高温钻井液技术[J]. 钻井液与完井液,2024,41(1):53–59. doi: 10.12358/j.issn.1001-5620.2024.01.005 YU Deshui, WANG Lu, LIU Shiyin, et al. Ultra-high temperature drilling fluid technology for second sidetracking of the Well Shunbei-16X[J]. Drilling Fluid & Completion Fluid, 2024, 41(1): 53–59. doi: 10.12358/j.issn.1001-5620.2024.01.005
[17] 张亚云,李大奇,高书阳,等. 顺北油气田奥陶系破碎性地层井壁失稳影响因素分析[J]. 断块油气田,2022,29(2):256–260. doi: 10.6056/dkyqt202202020 ZHANG Yayun, LI Daqi, GAO Shuyang, et al. Analysis on influencing factors of wellbore instability of Ordovician fractured formation in Shunbei Oil and Gas Field[J]. Fault-Block Oil & Gas Field, 2022, 29(2): 256–260. doi: 10.6056/dkyqt202202020
[18] 孙金声,李锐,王韧,等. 准噶尔盆地南缘井壁失稳机理及对策研究[J]. 西南石油大学学报(自然科学版),2022,41(1):1–12. doi: 10.11885/j.issn.16745086.2021.09.10.02 SUN Jinsheng, LI Rui, WANG Ren, et al. Research on the mechanism and countermeasures of shaft instability in the southern margin of Junggar Basin[J]. Journal of Southwest Petroleum University (Science & Technology Edition), 2022, 41(1): 1–12. doi: 10.11885/j.issn.16745086.2021.09.10.02
[19] 董晓强,方俊伟,李雄,等. 顺北4XH井抗高温高密度钻井液技术研究及应用[J]. 石油钻采工艺,2022,44(2):161–167. doi: 10.13639/j.odpt.2022.02.004 DONG Xiaoqiang, FANG Junwei, LI Xiong, et al. Research and application of a high-temperature high-density drilling fluid system in Well Shunbei-4XH[J]. Oil Drilling & Production Technology, 2022, 44(2): 161–167. doi: 10.13639/j.odpt.2022.02.004
[20] 赵海洋,范胜,连世鑫,等. 顺北油气田用抗高温弱凝胶防气侵钻井液体系[J]. 钻井液与完井液,2023,40(3):332–339. doi: 10.12358/j.issn.1001-5620.2023.03.008 ZHAO Haiyang, FAN Sheng, LIAN Shixin, et al. Study on high temperature gas-cut resistant weak gel drilling fluid in Shunbei Oil and Gas Field[J]. Drilling Fluid & Completion Fluid, 2023, 40(3): 332–339. doi: 10.12358/j.issn.1001-5620.2023.03.008
[21] 方俊伟, 贾晓斌, 刘文堂, 等. ZYSD高失水固结堵漏技术在顺北5-9井中的应用[J]. 钻井液与完井液,2021,38(1):74–78. FANG Junwei, JIA Xiaobin, LIU Wentang, et al. Control mud losses in Well Shunbei-5-9 with ZYSD high fluid loss solidifying slurry[J]. Drilling Fluid & Completion Fluid, 2021, 38(1): 74–78.
[22] 费中明,刘鑫,张晔,等. 准噶尔盆地南缘超深井天 X 井尾管精细控压固井技术[J]. 钻井液与完井液,2023,40(3):391–396. FEI Zhongming, LIU Xin, ZHANG Ye, et al. Liner cementing through precise pressure control in the ultra-deep Well Tian-X located at the southern margin of the Junggar Basin[J]. Drilling Fluid & Completion Fluid, 2023, 40(3): 391–396.
[23] 张煜,李海英,陈修平,等. 塔里木盆地顺北地区超深断控缝洞型油气藏地质−工程一体化实践与成效[J]. 石油与天然气地质,2022,43(6):1466–1480. doi: 10.11743/ogg20220615 ZHANG Yu, LI Haiying, CHEN Xiuping, et al. Practice and effect of geology-engineering integration in the development of ultra-deep fault-controlled fractured-vuggy oil/gas reservoirs, Shunbei Area, Tarim Basin[J]. Oil & Gas Geology, 2022, 43(6): 1466–1480. doi: 10.11743/ogg20220615
[24] 李海英,刘军,龚伟,等. 顺北地区走滑断裂与断溶体圈闭识别描述技术[J]. 中国石油勘探,2020,25(3):107–120. doi: 10.3969/j.issn.1672-7703.2020.03.010 LI Haiying, LIU Jun, GONG Wei, et al. Identification and characterization of strike-slip faults and traps of fault-karst reservoir in Shunbei area[J]. China Petroleum Exploration, 2020, 25(3): 107–120. doi: 10.3969/j.issn.1672-7703.2020.03.010
[25] 刘雨晴,邓尚,张荣,等. 深层火成岩侵入体和相关构造发育特征及其石油地质意义:以塔里木盆地顺北地区为例[J]. 石油与天然气地质,2022,43(1):105–117. doi: 10.11743/ogg20220109 LIU Yuqing, DENG Shang, ZHANG Rong, et al. Characterization and petroleum geological significance of deep igneous intrusions and related structures in the Shunbei Area, Tarim Basin[J]. Oil & Gas Geology, 2022, 43(1): 105–117. doi: 10.11743/ogg20220109
[26] 桂亚倩,朱光有,阮壮,等. 塔里木盆地塔北隆起寒武系地层水化学特征、成因及矿物溶解−沉淀模拟[J]. 石油与天然气地质,2022,43(1):196–206. doi: 10.11743/ogg20220116 GUI Yaqian, ZHU Guangyou, RUAN Zhuang, et al. Geochemical features and origin of the Cambrian formation water in Tabei Uplift, Tarim Basin and its mineral dissolution-precipitation simulation[J]. Oil & Gas Geology, 2022, 43(1): 196–206. doi: 10.11743/ogg20220116
[27] 范翔宇,蒙承,张千贵,等. 超深地层井壁失稳理论与控制技术研究进展[J]. 天然气工业,2024,44(1):159–176. FAN Xiangyu, MENG Cheng, ZHANG Qiangui, et al. Research progress in the evaluation theory and control technology of wellbore instability in ultra-deep strata[J]. Natural Gas Industry, 2024, 44(1): 159–176.
-
