Development and Application of a Casing Annulus Pressure Relief Device for Better Wellbore Integrity in Deepwater Wells
-
摘要: 针对深水油气开发中因密闭环空压力升高而导致的套管挤毁、破裂等问题，研制了一种深水井套管环空泄压装置，并对其进行了性能测试和现场应用。该泄压装置以高精度破裂盘为核心部件，利用爆破片材料能瞬时泄压的特性，释放环空高压膨胀流体，消除套管环空压力升高带来的危害。破裂盘阀体选用SS316不锈钢，爆破片选用NS312镍铬合金，采用普通正拱形结构，最高设计破裂压力36.6 MPa；破裂盘套管短节采用双孔泄压设计，以防破裂失效。室内性能测试结果显示，破裂盘结构完整，耐温性能、时效稳定性好，能满足工程中0.80倍设计破裂压力条件下的稳压要求；实测破裂压力符合制造范围偏差±3.0%的设计要求；同时，随着流体介质温度升高，破裂压力降低，降低幅度不超过5.0%，小于破裂压力允值，满足现场应用需求。深水井套管环空泄压装置在南海东部某区块3口深水井进行了应用，均取得良好的应用效果，投产至今未出现由于环空压力升高导致的井下故障。研究表明，深水井套管环空泄压装置达到了预期的环空压力控制和管理的目的，可保障井筒安全。Abstract: A kind of casing annulus pressure relief device with high precision rupture disk as the core part was developed to solve the problem of annular pressure buildup problems which can cause casing collapse and rupture during deepwater oil and gas production.It makes use of the characteristics of rupture disk material to release the annulus expansion fluid instantaneous and eliminate the potential risk caused by the increase of the annulus pressure.The rupture disk assembly body is manufactured with stainless steel SS316,and burst disk is manufactured from nicochrome NS312,which incorporate a conventional domed inward type structure design with a maximum design rupture pressure level of 36.6 MPa.The rupture disk casing sub design has a double hole pressure relief to prevent failure.Laboratory tests demonstrate that the rupture disk maintains structure integrity,has high temperature resistance and good aging stability with 0.80 times of designed rupture pressure for the engineering requirement.The actual test rupture pressure complies with the design requirement of manufacturing deviation of ±3.0%.With the increasing of test fluid temperature,the test rupture pressure would slightly decrease,with the total change volume less than 5.0% and lower than rupture pressure tolerance,meeting field application requirements.The casing annulus pressure relief device achieved success in field applications in 3 deepwater wells in one eastern block of the South China Sea,and no downhole accidents have occurred up to now that were caused by annular pressure buildup problems.The research showed that the casing annular pressure relief device achieved the anticipated annular pressure management objectives and could ensure the wellbore safety.
-
Keywords:
- deepwater well /
- pressure buildup /
- pressure relief device /
- rupture disk /
- performance test
-
-
[1] PATTILLO P D,COCALES B W,MOREY S C.Analysis of an annular pressure buildup failure during drilling ahead[R].SPE 89775,2004.
[2] HU Zhiqiang,YANG Jin,LI Wenlong,et al.Research and development of compressible foam for pressure management in casing annulus of deepwater wells[J].Journal of Petroleum Science and Engineering,2018,166:546-560.
[3] BRADFORD D W,FRITCHIE D G,GIBSON D H,et al.Marlin failure analysis and redesign:part 1:description of failure[R].SPE 88814,2004.
[4] 胡志强,杨进,李中,等.高温高压井双封隔器管柱安全评估[J].石油钻采工艺,2017,39(3):288-292. HU Zhiqiang,YANG Jin,LI Zhong,et al.Safety assessment on twin-packer string of HTHP well[J].Oil Drilling Production Technology,2017,39(3):288-292. [5] 胡伟杰,王建龙,张卫东.深水钻井密闭环空圈闭压力预测及释放技术[J].中外能源,2012,17(8):41-45. HU Weijie,WANG Jianlong,ZHANG Weidong.Confined annular trap pressure prediction and release technology for deep water drilling[J].Sino-Global Energy,2012,17(8):41-45. [6] 黄小龙,严德,田瑞瑞,等.深水套管环空圈闭压力计算及控制技术分析[J].中国海上油气,2014,26(6):61-65. HUANG Xiaolong,YAN De,TIAN Ruirui,et al.Research on calculation of casing annulus trapped pressure and its control techniques for deep water well[J].China Offshore Oil and Gas,2014,26(6):61-65. [7] 杨进,唐海雄,刘正礼,等.深水油气井套管环空压力预测模型[J].石油勘探与开发,2013,40(5):616-619. YANG Jin,TANG Haixiong,LIU Zhengli,et al.Prediction model of casing annulus pressure for deepwater well drilling and completion operation[J].Petroleum Exploration and Development,2013,40(5):616-619. [8] 王素环,韩晓辉,赵延强,等.冷作硬化不锈钢对接接头组织与性能分析[J].电焊机,2014,44(2):63-66. WANG Suhuan,HAN Xiaohui,ZHAO Yanqiang,et al.Analysis of structures and properties of cold rolling stainless steel butt welding joints[J].Electric Welding Machine,2014,44(2):63-66. [9] 孙士雷,赵杰,袁玮骏,等.GH4169镍基高温合金表面加工硬化研究[J].工具技术,2016,50(10):24-27. SUN Shilei,ZHAO Jie,YUAN Weijun,et al.Study on surface hardening in high speed milling super alloy GH4169[J].Tool Engineering,2016,50(10):24-27. [10] 王路逸.正拱型爆破片的疲劳寿命及其影响因素研究[D].上海:华东理工大学,2015. WANG Luyi.Material property measurement of common pressure vessel steel using hydraulic bursting test[D].Shanghai:East China University of Science and Technology,2015. [11] 顾雪铭,吴全龙,杨秀霞.正拱环向开缝型爆破片的爆破性能[J].华东理工大学学报(自然科学版),2004,30(1):99-102. GU Xueming,WU Quanlong,YANG Xiuxia.Bursting mechanism of domed annular-slotted bursting discs[J].Journal of East China University of Science and Technology(Natural Science Edition),2004,30(1):99-102. [12] 那福利.反拱开缝型爆破片性能研究[D].上海:华东理工大学,1998. NA Fuli.Analysis of reverse domed bursting disc with knife blades[D].Shanghai:East China University of Science and Technology,1998. [13] 王东方.爆破片爆破压力可靠性研究[J].导弹与航天运载技术,2007(3):43-45. WANG Dongfang.Research on bursting pressure reliability of bursting disc[J].Missiles and Space Vehicles,2007(3):43-45. [14] 李志义,初春利,张凤玉,等.关于爆破片的制造范围[J].化工装备技术,1996(5):47-52. LI Zhiyi,CHU Chunli,ZHANG Fengyu,et al.About the scope of the manufacturing deviation[J].Chemical Equipment Technology,1996(5):47-52. [15] 吴全龙.爆破片装置国内外标准对比分析[J].压力容器,2011,28(5):48-54,40. WU Quanlong.Comparative analysis on the domestic and overseas standard of the bursting disc devices[J].Pressure Vessel Technology,2011,28(5):48-54,40. [16] 马源,喻建良.金属爆破片的时效性能研究[J].石油化工设备,1996(4):16-20. MA Yuan,YU Jianliang.Study on the aging properties of metal bursting disc[J].Petro-Chemical Equipment,1996(4):16-20. [17] GB 567.1-2012爆破片安全装置:第1部分:基本要求[S]. GB 567.1-2012 Bursting disc safety devices:part 1:basic requirement[S]. [18] GB 567.2-2012爆破片安全装置:第2部分:应用、选择与安装[S]. GB 567.2-2012 Bursting disc safety devices:part 2:application,selection and installation[S]. [19] GB 567.3-2012爆破片安全装置:第3部分:分类及安装尺寸[S]. GB 567.3-2012 Bursting disc safety devices:part 3:classification and mounting dimensions[S]. [20] GB 567.4-2012爆破片安全装置:第4部分:型式试验[S]. GB 567.4-2012 Bursting disc safety devices:part 4:type test[S]. -
