Design and Test of a New PDC Bit with Tapered Auxiliary Cutter for Heterogeneous Formations
-
摘要: 为了提高PDC钻头在非均质地层中的机械钻速和延长钻头使用寿命，研制了带有锥形辅助切削齿的PDC钻头。该钻头以PDC齿为主切削元件，锥形齿和PDC齿为副切削元件，开始工作时以PDC切削齿剪切破岩为主，当PDC切削齿吃入地层到一定程度后，锥形齿开始犁削岩石形成裂纹，有助于PDC齿以较小切削力破碎岩石；相邻2个刀翼的后排齿分别布置锥形齿与PDC齿，用于钻头钻进后期的提速提效，既具有常规PDC钻头破岩效率稳定的特点，又具有锥形齿在非均质地层破岩效率高的特点。现场试验表明，与常规PDC钻头相比，锥形辅助切削齿PDC钻头在非均质地层中使用寿命长、机械钻速高。锥形辅助切削齿PDC钻头的成功研制，为钻进非均质地层提供了一种新的高效破岩工具。Abstract: In order to improve the penetration rate of PDC bits for drilling through heterogeneous formations and to extend the life of drill bits,a new type of PDC bit with a tapered auxiliary cutter has been developed.The bit uses a PDC cutter as the main cutting element,with the conical cutter and PDC cutter as auxiliary cutting elements.When the bit starts to work,the PDC cutter will break rocks in "shearing" mode.After the PDC cutter drills into the formation to some extent,the conical cutter starts to plow and cut the rock to generate cracks and induce local fractures,which helps the PDC cutter break the rock at a relatively low cutting force.The rear cutter of two adjacent blades are arranged with the conical cutter and the PDC cutter respectively,which is used for the rate of penetration to increase and efficiency improvement of the bit in the later stage.It incorporates the characteristics of stable rock breaking efficiency of conventional PDC bits as well as the advantages of high rock breaking efficiency of the conical cutter in heterogeneous formations.The bit has been through field testing in different regions.Testing results show that the new bit has longer drilling life and higher penetration rate than conventional PDC bits in drilling through heterogeneous formations.The successful development of the new type of PDC bit provided a new and efficient rock breaking tool for drilling through heterogeneous formations.
-
-
[1] 邹德永,郭玉龙,赵建,等.锥形PDC单齿破岩试验研究[J].石油钻探技术,2015,43(1):122-125. ZOU Deyong,GUO Yulong,ZHAO Jian,et al.Experimental study on rock breaking of conical PDC cutter[J].Petroleum Drilling Techniques,2015,43(1):122-125. [2] 杨顺辉.锥形PDC齿钻头的研制及室内试验评价[J].石油机械,2015,43(2):14-17. YANG Shunhui.Development and laboratory tests evaluation of PDC bit with conical cutter[J].China Petroleum Machinery,2015,43(2):14-17. [3] 闫炎,管志川,玄令超,等.复合冲击条件下PDC钻头破岩效率试验研究[J].石油钻探技术,2017,45(6):24-30. YAN Yan,GUAN Zhichuan,XUAN Lingchao,et al.Experimental study on rock breaking efficiency with a PDC bit under conditions of composite percussion[J].Petroleum Drilling Techniques,2017,45(6):24-30. [4] 孙源秀,邹德永,徐城凯,等.锥形聚晶金刚石复合片(PDC)齿与常规PDC齿破岩效果对比试验[J].科学技术与工程,2015,36(4):159-162. SUN Yuanxiu,ZOU Deyong,XU Chengkai,et al.Contrast experiment on conical PDC cutter and conventional PDC cutter[J].Science Technology and Engineering,2015,36(4):159-162. [5] 孙明光,张云联.新型PDC钻头设计[J].石油钻采工艺,2000,22(2):31-34. SUN Mingguang,ZHANG Yunlian.Novel PDC bit design to optimize its performance in multi-interbeded formation[J].Oil Drilling Production Technology,2000,22(2):31-34. [6] 邹德永,孙源秀,徐城凯,等.锥形齿PDC钻头台架试验研究[J].中国石油大学学报(自然科学版),2015,39(2):48-52. ZOU Deyong,SUN Yuanxiu,XU Chengkai,et al.Experimental study on bench test of stinger PDC bit[J].Journal of China University of Petroleum(Edition of Natural Science),2015,39(2):48-52. [7] 王福修,田京燕.PDC钻头稳定性技术研究[J].石油矿场机械,2002,31(2):7-10. WANG Fuxiu,TIAN Jingyan.The technology study on PDC bit stability[J].Oil Field Equipment, 2002,31(2):7-10. [8] 朱宽亮,周岩,胡中志.PDC-牙轮复合钻头在南堡油田大斜度井的应用[J].石油钻探技术,2017,45(6):60-64. ZHU Kuanliang,ZHOU Yan,HU Zhongzhi.Application of a PDC-roller hybrid bit in highly-deviated wells of the Nanpu Oilfield[J].Petroleum Drilling Techniques,2017,45(6):60-64. [9] 豆宁辉,杨顺辉.锥形PDC齿破岩机理仿真研究[J].石油矿场机械,2015,44(11):12-17. DOU Ninghui,YANG Shunhui.Simulation research of conical PDC cutter rock-breaking mechanism[J].Oil Field Equipment,2015,44(11):12-17. [10] 查春青,柳贡慧,李军,等.复合冲击破岩钻井新技术提速机理研究[J].石油钻探技术,2017,45(2):20-24. ZHA Chunqing,LIU Gonghui,LI Jun,et al.The rock breaking mechanism of the compound percussive-rotary drilling method with a PDC bit[J].Petroleum Drilling Techniques,2017,45(2):20-24. [11] 孙源秀,邹德永,郭玉龙,等.切削-犁削混合钻头设计及现场应用[J].石油钻采工艺,2016,38(1):53-56. SUN Yuanxiu,ZOU Deyong,GUO Yulong,et al.Design and field application of plow-cutting PDC bit[J].Oil Drilling Production Technology,2016,38(1):53-56. [12] 柳贡慧,李玉梅,李军,等.复合冲击破岩钻井新技术[J].石油钻探技术,2016,44(5):10-15. LIU Gonghui,LI Yumei,LI Jun,et al.New technology with composite percussion drilling and rock breaking[J].Petroleum Drilling Techniques,2016,44(5):10-15. [13] 邓勇,陈勉,金衍,等.冲击作用下岩石破碎的动力学特性及能耗特征研究[J].石油钻探技术,2016,44(3):27-32. DENG Yong,CHEN Mian,JIN Yan,et al.Investigation of the dynamic characteristics and energy consumption for breaking rocks using the impact load[J].Petroleum Drilling Techniques,2016,44(3):27-32. [14] 刘亚军,王晓鹏,王昆剑,等.绥中36-1油田新型钻头的优化设计及应用[J].断块油气田,2011,18(5):669-671. LIU Yajun,WANG Xiaopeng,WANG Kunjian,et al.Optimization design and application of new drill bit in SZ 36-1 Oilfield[J].Fault-Block Oil Gas Field,2011,18(5):669-671. [15] 关舒伟.新型孕镶金刚石钻头研制及试验[J].石油钻探技术,2015,43(4):129-132. GUAN Shuwei.Development and testing of a new type of diamond-impregnated bits[J].Petroleum Drilling Techniques,2015,43(4):129-132. -
