Key Technology of Water Detection by Dragging the Pipe String in Multi-Stage Fractured Horizontal Well
-
摘要: 长庆油田长水平段水平井应用拖动管柱找水工艺时，存在配套的皮碗封隔器胶筒密封性变差和起钻时皮碗脱落的问题，为此对其进行了针对性研究。通过室内模拟井下环境，利用滚珠丝杠控制皮碗封隔器在套管内往复运动，得到每摩擦500.00 m时的皮碗磨损量，根据承压试验确定其最大下深为2 500.00 m；通过改进Y211型拖动压裂封隔器结构、优选胶筒材料，研制了分别应用于单封和双封拖动管柱找水工艺的Y211-1型和Y211-2型封隔器；同时，研制了可在水平段重复坐封的新Y111型封隔器，以确保能够实施双封拖动管柱找水工艺。研究的新型封隔器和拖动管柱找水工艺已在长庆油田6口水平井应用，应用结果显示，1套封隔器可以完成2口井的找水作业，测试成功率由之前的91.3%提高至100.0%，单井测试费用仅为皮碗封隔器拖动管柱找水的一半。研究结果表明，新型封隔器使拖动管柱找水工艺更简便、费用更低，在长水平段水平井中的应用效果良好。Abstract: In the application of water detection technology by dragging the pipe string in the long reach horizontal wells in the Changqing Oilfield,problems such as sealing property deterioration of the matched cup packer and cup dropping while POOH occurred.Therefore,the targeted studies were carried out.Through lab simulation of the downhole environment,ball screw was used to make the cup packer reciprocatingly move inside the casing to obtain the wear amount of each 500.0 m of friction.The maximum packer bearing setting depth of 2 500.0 m was also determined through bearing tests.By improving the structure of the Y211 dragging fracturing packer and by optimizing its rubber material,Y211-1 and Y211-2 packers suitable for single-packer and dual-packer water detection technology by dragging the pipe string were developed respectively.Besides,a new Y111 packer that can be set repeatedly in the horizontal section was developed to guarantee the implementation of dual-packer string dragging water detection technology.The new type packers and string dragging water detection technology were used in six horizontal wells of the Changqing Oilfield.The application results indicated that one set of packers was able to achieve water detection in two wells,and the testing success rate increased from 91.3% to 100.0%,while the cost of a single well test was only half of that with previous cup packer string dragging water detection.The research results show that the new packers make the water detection technology more convenient and economical,and they can obtain satisfying effect when applied in long horizontal wells.
-
Keywords:
- long horizontal section /
- horizontal well /
- water detection /
- dragging pipe string /
- packer /
- Changqing Oilfield
-
-
[1] 郭洪志,李冬梅.Flagship在中高含水期水平井中的应用研究[J].西南石油大学学报(自然科学版),2009,31(1):107-110. GUO Hongzhi,LI Dongmei.Flagship application in high water cut horizontal well[J].Journal of Southwest Petroleum University(Science Technology Edition),2009,31(1):107-110. [2] 郑希科,刘兴斌,朴玉琴,等.水平井油水两相管流流量和含水率测量方法实验研究[J].测井技术,2010,34(4):323-326. ZHENG Xike,LIU Xingbin,PIAO Yuqin,et al.Experimental study on measurements of flow-rate and water-cut in horizontal pipes[J].Well Logging Technology,2010,34(4):323-326. [3] 聂飞朋,石琼,郭林园,等.水平井找水技术现状及发展趋势[J].油气井测试,2011,20(3):32-34. NIE Feipeng,SHI Qiong,GUO Linyuan,et al.Present situation and development trend of water detection technology in horizontal well[J].Well Testing,2011,20(3):32-34. [4] 徐昊洋,王燕声,牛润海,等.水平井连续油管输送存储式产液剖面测试技术应用[J].油气井测试,2014,23(3):46-48. XU Haoyang,WANG Yansheng,NIU Runhai,et al.Application of memory fluid production profile testing technology conveyed by coiled tubing to horizontal well[J].Well Testing,2014,23(3):46-48. [5] 慕立俊,朱洪征,吕亿明,等.低产液量水平井找堵水管柱的设计与应用[J].石油钻探技术,2014,42(1):91-94. MU Lijun,ZHU Hongzheng,LYU Yiming,et al.Design and application of water detecting and plugging pipe string for low production horizontal wells[J].Petroleum Drilling Techniques,2014,42(1):91-94. [6] 王百,黄伟,李凡书,等.小流量水平井机械分段找水技术研究与应用[J].钻采工艺,2014,37(2):54-56,74. WANG Bai,HUANG Wei,LI Fanshu,et al.Research and application of mechanical segmentation water testing technology in horizontal well with small flow[J].Drilling Production Technology,2014,37(2):54-56,74. [7] 慕立俊,王百,崔文昊,等.套返水平井单封拖动管柱快速找水方法研究与应用[J].石油矿场机械,2014,43(6):53-58. MU Lijun,WANG Bai,CUI Wenhao,et al.Study and application of fast-water detection in set return horizontal well using single packing drag pipe[J].Oil Field Equipment,2014,43(6):53-58. [8] 朱洪征,王百,吕亿明,等.水平井快速找水管柱的研制与应用[J].大庆石油地质与开发,2015,34(1):87-90. ZHU Hongzheng,WANG Bai,LYU Yiming,et al.Development and application of the quick water-detecting string for horizontal well[J].Petroleum Geology Oilfield Development in Daqing,2015,34(1):87-90. [9] 崔文昊,高榕,陈柯,等.低渗透油田水平井快速找水技术研究与应用[J].长江大学学报(自科版),2015,12(5):76-78. CUI Wenhao,GAO Rong,CHEN Ke,et al.Research of fast water detection technology in horizontal wells of low permeability oilfields and its application[J].Journal of Yangtze University (Natural Science Edition),2015,12(5):76-78. [10] 任国富,徐自强,王在强,等.Y211型拖动压裂封隔器研制与应用[J].石油矿场机械,2015,44(9):60-61. REN Guofu,XU Ziqiang,WANG Zaiqiang,et al.Development and application of Y211 dragging fracturing packer[J].Oil Field Equipment,2015,44(9):60-61. [11] 任勇,冯长青,胡相君,等.长庆油田水平井体积压裂工具发展浅析[J].中国石油勘探,2015,20(2):75-81. REN Yong,FENG Changqing,HU Xiangjun,et al.Analysis of volume-fracturing tools developed for horizontal wells in Changqing Oilfield[J].China Petroleum Exploration,2015,20(2):75-81. [12] 王金友,许国文,李琳,等.连续油管拖动底封水力喷射环空加砂分段压裂技术[J].石油矿场机械,2016,45(5):69-72. WANG Jinyou,XU Guowen,LI Lin,et al.Technology of coiled tubing abrasive perforating and annulus fracturing[J].Oil Field Equipment,2016,45(5):69-72. -
