Precise Positioning Technique for Wellbore Trajectories
-
摘要: 现行井眼轨迹定位方法采用网格北作为指北基准，在靶点和井口范围内将参考椭球面近似为水平面来定位靶点相对于井口的空间位置，在实钻井眼轨迹计算中没有考虑各测点处磁偏角随时间和空间的变化，存在固有缺陷和较大误差。为此，采用真北作为指北基准，基于地球椭球及其解算原理来定位靶点与井口间的相对位置，利用国际地磁参考场随时随地求取磁偏角，考虑磁偏角的时空变化并用迭代法计算实钻井眼轨迹。井眼轨迹精准定位技术从根本上解决了现行定位方法存在的问题，保证了井眼轨道设计与轨迹监测的精确性和可靠性。Abstract: To determine the relative spatial position of the target to the wellhead,grid north is currently used as the benchmark for North,which positions the ellipsoid into the horizontal plane as the approximate reference coordinate. Because it does not consider the change of magnetic declination with the change of time and space at the measuring points,the conventional calculation of drilled wellbore trajectory exhibits inherent defects and significant errors. In order to solve the problem,True North can be used as the reference North to determine the relative position between the target and wellhead in terms of earth ellipsoid and its calculation principle. It can also be used to determine the magnetic declinations based on international geomagnetism reference field,which considers the changes of magnetic declinations with time and space to calculate the drilled wellbore trajectory by an iterative method. The innovative method can effectively eliminate drawbacks of existing positioning techniques and ensure accuracy and reliability in design and monitoring of wellbore trajectories.
-
Keywords:
- drilling theory /
- directional drilling /
- wellbore trajectory /
- precise positioning
-
-
[1] 孔祥元,郭际明,刘宗泉.大地测量学基础[M].2版.武汉:武汉大学出版社,2010:99-206. KONG Xiangyuan,GUO Jiming,LIU Zongquan.Foundation of geodesy[M].2nd ed.Wuhan:Wuhan University Press,2010:99-206. [2] 王美玲,付梦印.地图投影与坐标变换[M].北京:电子工业出版社,2014:15-18. WANG Meiling,FU Mengyin.Map projection and coordinate transformation[M].Beijing:Publishing House of Electronics Industry,2014:15-18. [3] GB/T 17159-2009大地测量术语[S]. GB/T 17159-2009 Geodetic term[S]. [4] 徐文耀.地磁学[M].北京:地震出版社,2003:1-121. XU Wenyao.Geomagnetics[M].Beijing:Seismological Press,2003:1-121. [5] IAGA,Working Group V-MOD.International geomagnetic reference field:the eleventh generation[J].Geophysical Journal International,2010,183(3):1216-1230.
[6] 石在虹,滕少臣,刘子恒.国际地磁参考场解算方法及石油工程应用[J].石油钻采工艺,2016,38(4):409-414. SHI Zaihong,Teng Shaochen,Liu Ziheng.Algorithm for international geomagnetic reference field and its application in petroleum engineering[J].Oil Drilling Production Technology,2016,38(4):409-414. [7] 刘修善.基于地球椭球的真三维井眼定位方法[J].石油勘探与开发,2017,44(2):275-280. LIU Xiushan.A true three-dimensional wellbore positioning method based on the earth ellipsoid[J].Petroleum Exploration and Development,2017,44(2):275-280. [8] 刘修善.考虑磁偏角时空变化的实钻轨迹精准定位[J].石油学报,2017,38(6):705-709. LIU Xiushan.Positioning the drilled borehole trajectories considering the magnetic declination change in space-time[J].Acta Petrolei Sinica,2017,38(6):705-709. -
