涪陵页岩气田共建成焦石坝、江东、平桥、白涛和白马等5个生产区块，不同区块、不同生产阶段的气井其产气、产水特征差异较大。受产量递减、井筒积液的影响，气井生产时率逐渐降低。该气田主要采用ϕ73.0 mm×5.51 mm、ϕ60.3 mm×4.83 mm普通油管和ϕ50.8 mm×4.45 mm、ϕ38.1 mm×3.68 mm连续油管等4种规格的采气管柱，其中连续油管具有单井成本低、起下速度快、工序简单和施工时效性高等优点[1]，在涪陵页岩气井中的应用越来越广泛。由于不同气井的连续油管压力损耗、稳产时间、稳产期累计产气量存在差异，笔者基于现场应用情况，分析了连续油管直径、下入深度和下入时机对气井生产效果的影响，明确了连续油管的适用范围，为提高连续油管在涪陵页岩气田的应用效果提供了依据。
1. 涪陵页岩气田连续油管应用情况
目前，涪陵页岩气田42口生产井采用连续油管采气管柱，其中，采用ϕ50.8 mm×4.45 mm连续油管的井有36口，采用ϕ38.1 mm×3.68 mm连续油管的井有6口。连续油管最浅下深为2 220.00 mm（井斜角30°），最深下深为4 400.00 m（井斜角85°），平均下深3 200.00 mm。采用连续油管采气管柱的生产井初期产气量为（1.10 ～7.80）×104 m3/d，产水量为0.55～18.90 m3/d，水气比为0.08 ～10.90 m3/104m3。总体来看，页岩气井产能在一定程度上决定了气井生产效果，但采气管柱的优选更为重要。在无阻流量相同的情况下，水气比高的页岩气井下入连续油管后生产不稳定、产量较低，其中，15口典型井的生产数据见表1。
表 1 涪陵页岩气田采用连续油管采气管柱的15口典型井生产情况统计Table 1. Production statistics of 15 typical wells with coiled tubing gas producing pipe stings in Fuling Shale Gas Field井号 初期产量/（104m3·d–1） 近期产量/（104m3·d–1） 无阻流量/（104m3·d–1） 平均水气比/
（m3·（104m3）–1）连续油管生产阶段产气量/
104m3JY1 1.0 1.1 3.6 10.90 12.1 JY2 2.0 1.8 4.6 0.45 2 260.6 JY3 2.0 0.3 7.6 5.50 284.6 JY4 2.3 1.2 3.8 2.50 251.4 JY5 2.5 1.2 3.3 2.00 762.6 JY6 3.7 2.1 4.2 0.30 3 300.6 JY7 4.2 4.0 5.1 0.30 6 345.0 JY8 5.5 1.8 2.5 0.10 3 383.0 JY9 6.0 1.2 3.0 0.10 3 073.7 JY10 6.0 3.3 1.5 0.20 2 271.4 JY11 6.0 3.2 3.0 0.10 6 748.3 JY12 6.1 3.3 1.5 0.20 2 196.9 JY13 7.5 5.2 6.6 0.10 2 867.2 JY14 7.5 1.5 4.0 0.08 4 292.9 JY15 7.8 4.6 7.9 0.08 8 356.5 2. 连续油管生产效果的影响因素
2.1 连续油管直径
2.1.1 连续油管直径对携液效果的影响
页岩气均采用水平井开发，而水平井的造斜段最易积液，故提高造斜段携液能力是解决水平气井积液和优化采气管柱的重点[2-7]。王琦[8]通过试验证明井斜角在50°左右时临界携液气量最大，并以50°井斜角的临界携液气量为气井的临界携液气量，建立了振荡式冲击携液临界气流量计算模型。采用该临界携液气流量模型，计算了不同直径油管在不同井底压力（井斜角为50°）条件下的临界携液气量，结果如图1所示。从图1可以看出，与ϕ60.3 mm×4.83 mm普通油管相比，ϕ50.8 mm×4.45 mm连续油管的临界携液气量平均降低38%。因此，单从携液能力的角度考虑，采用的油管直径越小，越有利于气井的携液。
![]()
图 1 不同井底压力下不同直径油管的临界携液气量Figure 1. Critical liquid carrying capacity of tubings with different diameters under different bottom hole pressures2.1.2 连续油管直径对井筒压耗的影响
涪陵页岩气田不同规格连续油管生产井的产气量每增加1×104 m3时的单位长度井筒压耗统计结果如图2所示。从图2可以看出，虽然采用更小直径的连续油管能够降低气井的临界携液气量，但连续油管的直径越小，单位长度井筒压耗越大。由图2还可以看出，水气比对单位长度井筒压耗的影响较大，当采用ϕ50.8 mm×4.45 mm连续油管生产且水气比大于1.5 m3/104m3时，产气量每增加1×104 m3的单位长度井筒压耗开始有所增大；当采用ϕ38.1 mm×3.68 mm连续油管生产且水气比大于1.0 m3/104m3时，产气量每增加1×104m3的单位长度井筒压耗明显增大。
![]()
图 2 ϕ50.8 mm×4.45 mm与ϕ38.1 mm×3.68 mm连续油管单位长度井筒压耗对比Figure 2. Comparison on wellbore pressure losses per unit lenghth of ϕ50.8 mm×4.45 mm and ϕ38.1 mm×3.68 mmcoiled tubing2.1.3 连续油管直径对气井稳产期的影响
计算不同直径连续油管在临界携液气量下的井底流压，作为气井稳产期末的停喷井底流压，用以评价连续油管生产气井的稳产期。目前，工程上常用的各种气液两相管流压降计算模型的建立基础不同，其适用条件也不相同[9]。田云等人[10]对8个常用气液两相管流压降模型进行了评价，发现Gray模型的计算结果与连续油管实际生产情况最吻合。故笔者采用Gray模型，计算垂深3 000.00 m气井、外输压力为4.5 MPa条件下采用不同直径油管生产时的停喷井底流压，结果如图3所示。
![]()
图 3 不同直径油管停喷井底流压随水气比的变化Figure 3. Variation of bottomhole flowing pressure with watergas ratio for coiled tubing with different diameters when unflowing从图3可以看出：水气比越高，油管直径对气井稳产期末停喷井底流压的影响越显著；水气比在0～1.5 m3/104m3时，与采用ϕ60.3 mm×4.83 mm普通油管生产相比，采用ϕ50.8 mm×4.45 mm连续油管生产时气井的停喷井底流压差别不大且均较低，但ϕ50.8 mm×4.45 mm连续油管的临界携液气量更低，因此水气比在0～1.5 m3/104m3时，能够将气井废弃产量和地层废弃压力降至最低；ϕ38.1 mm×3.68 mm连续油管的停喷井底流压相对较高，适用范围较窄。
统计涪陵页岩气田ϕ60.3 mm×4.83 mm、ϕ50.8 mm×4.45 mm、ϕ38.1 mm×3.68 mm等3种油管在不同水气比条件下的稳产时间和稳产期累计产气量，结果如图4、图5所示。从图4、图5可以看出，水气比在0～1.5 m3/104m3时，采用ϕ50.8 mm×4.45 mm连续油管生产能够获得更长的稳产期和更高的稳产期累计产气量。综合考虑连续油管直径对气井携液、井筒压耗、气井稳产时间的影响，水气比在0～1.5 m3/104m3的页岩气井，采用ϕ50.8 mm×4.45 mm连续油管采气管柱，生产效果更佳。
![]()
图 4 不同直径油管稳产时间随水气比的变化Figure 4. Variation of stable production time with water gas ratio of tubings with different diameters![]()
图 5 不同直径油管稳产期累计产气量随水气比的变化Figure 5. Variation of cumulative gas production with water gas ratio in stable production period of tubings with different diameters2.2 连续油管下深
2.2.1 连续油管下深对携液效果的影响
由于井斜角50°左右井段携液最难，因此连续油管应下到井斜角大于50°的井段。表2为3口连续油管不同下深页岩气井生产效果的对比情况；图6为3口连续油管不同下深页岩气井的生产曲线。
表 2 连续油管不同下深页岩气井生产效果对比Table 2. Production effect comparison of shale gas wells with different setting depths of coiled tubing井号 连续油管下深/m 井斜角/（°） 初期套压/MPa 平均水气比/（m3·（104m3）–1） 初期配产/（104m3·d–1） 自喷稳产期/d 自喷累计产气量/104m3 JY20 2 220 30 13.7 0.11 6 556 2 191 JY21 2 250 45 13.8 0.24 6 976 1 730 JY22 2 900 55 12.5 0.79 6 1 037 4 389 注：JY20井、JY21井和JY22井均采用ϕ50.8 mm×4.45 mm连续油管生产。 ![]()
图 6 JY20井、JY21井和JY22井的生产曲线Figure 6. Production curves of Well JY20, Well JY21 and Well JY22从表2和图6可以看出，在连续油管下入初期井口套压和配产相同的条件下，即使JY22井的水气比略高于JY20井和JY21井，且连续油管下入初期该井的井口套压略低于JY20井和JY21井，JY22井也能维持较长的稳产期和较大的稳产期累计产气量。其原因是，JY22井连续油管下到了井斜角大于50°的井段，JY20井和JY21井连续油管都下到了井斜角小于50°的井段，而井斜角50°的井段携液最难，易积液，导致JY20井和JY21井生产连续性较差。
2.2.2 连续油管下深对井筒压耗的影响
统计涪陵页岩气井不同水气比区间下入ϕ50.8 mm×4.45 mm连续油管生产1×104 m3气的井筒压耗，结果如图7所示。从图7可以看出：井筒压耗与连续油管下深正相关；水气比高于1.5 m3/104m3后，连续油管下深对井筒压耗的影响增大；水气比越高，井筒压耗随连续油管下深增大的幅度越大。
![]()
图 7 不同水气比下井筒压耗与连续油管下深的关系Figure 7. Relationship between wellbore pressure loss and coiled tubing setting depth under different water gas ratios2.3 连续油管下入时机对气井稳产效果的影响
选取下入ϕ50.8 mm×4.45 mm连续油管、生产时间较长、已进入间歇生产的页岩气井进行统计分析，结果见表3。由表3可知：在相同水气比条件下，下入连续油管前页岩气井生产时间越短，页岩气井自喷稳产期越长，自喷期累计产气量越高；下连续油管前页岩气井生产时间相同，水气比越大，连续油管的生产效果越差。因此，在较低水气比条件下，越早下入ϕ50.8 mm×4.45 mm连续油管，生产过程中携液稳产效果越好，自喷稳产期越长，连续油管自喷生产阶段累计产气量越高。
表 3 连续油管下入时机对气井生产效果的影响情况Table 3. Statistics on the influence of coiled tubing setting timing on gas well production水气比/
（m3·（104m3）–1）生产时间/d 自喷累计产气量/
104m3下入前 自喷稳产 2.50 596 4 12.1 2.00 364 230 762.6 2.50 500 141 251.3 2.00 501 108 284.5 0.30 202 691 3300.5 0.30 10 1 344 4292.9 0.10 212 833 3073.7 0.10 101 956 3382.9 0.10 10 1 411 6344.9 3. 结论与建议
1）研究表明，油管直径越小，越有利于气井携液，但同时会增大井筒压耗。综合考虑连续油管直径对气井携液、井筒压耗、气井稳产时间的影响，对于水气比小于1.5 m3/104m3的气井，采用ϕ50.8 mm×4.45 mm连续油管生产效果较好。
2）涪陵页岩气田的页岩气井需要压裂后投产，产出水均为返排压裂液。因此，对于水气比在0～1.5 m3/104m3的气井，建议尽早下入ϕ50.8 mm×4.45 mm连续油管，这样既有助于压裂液连续返排，也能使页岩气井获得更长的自喷稳产时间和更大的自喷累计产气量。
-
