Drilling and Completion Technologies for of Geothermal Wells with Medium and Low Temperatures
-
摘要: 为了提高中低温地热井工程质量，保障单井产能，优化了地热井钻井完井工艺技术，形成了适用于砂岩热储的二开井身结构和适用于基岩热储的三开井身结构；采用悬挂器连接、连接重叠段固井水泥密封的方式，防止泵室段底部水层窜通；优化了适用于不同地区、不同储层完井的花管、绕丝筛管和割缝衬管的设计参数；针对热储层极易漏失的特点，发展了钻井液正循环钻进、清水正循环钻进、清水充空气正循环钻进和气举反循环钻进等4种钻进工艺；根据生产需求，明确了地热井测井参数要求、固井技术要点及组合洗井工艺。该技术在清丰XBXZ-1井现场应用后，下入多级泵试水24 h，流量120 m3/h，水温68℃，静液面15.50 m，动液面48.00 m。中低温地热井钻井完井工艺成功解决了地热钻井完井过程中存在的钻井液漏失严重、水位衰减快、沉砂严重和开采水层与表层水之间的互窜等问题，具有较好的推广应用价值。Abstract: To enhance the engineering quality of geothermal wells and to obtain desirable single well productivity,geothermal drilling and completion technologies have been optimized,and developed casing program with two sections suitable for geothermal development in sandstone formations and three sections suitable for matrix formations.Hanger connections,together with sealing by cementing slurry in overlapping sections have been developed to eliminate possibility of water channeling in bottom sections of the pumping chamber.In addition,design parameters for perforated PVC pipe,wire-wrapped screens and slotted liners are optimized to satisfy the demand of completion in different formations and different areas.Four drilling techniques,including mud circulation drilling,freshwater circulation drilling,gas-charged water circulation drilling and gas-lifting reverse circulation drilling,have been developed for thermal reservoir susceptible to lost-circulation.According to the requirement of production,logging parameters,cementing and integral flushing technologies in geothermal wells have been specified.The newly developed technologies have been deployed on site of the Well Qingfeng XBXZ-1,with multistage pump testing water for 24 h,flow rate of 120 m3/h,water temperature of 68℃,the static liquid level being 15.50 m,the dynamic liquid level being 48.00 m.Successful drilling and completion technologies for geothermal wells at medium or low temperatures can effectively eliminate severe lost circulation,fast drop in water levels,undesirable settling of cuttings,channeling of water between target formation and surface layer,etc.It has bright prospects in promotionand application.
-
Keywords:
- low medium temperature /
- geothermal well /
- drilling /
- completion
-
-
[1] 曾义金.干热岩热能开发技术进展与思考[J].石油钻探技术,2015,43(2):1-7. ZENG Yijin.Technical progress and thinking for development of hot dry rock (HDR) geothermal resources[J].Petroleum Drilling Techniques,2015,43(2):1-7. [2] 韦雅珍,王凤清,任宝玉.华北油区地热排采技术研究[J].石油钻采工艺,2009,31(增刊1):93-95,100. WEI Yazhen,WANG Fengqing,REN Baoyu.Drainage and production by using geothermal in Huabei oil region[J].Oil Drilling Production Technology,2009,31(supplement 1):93-95,100. [3] 蔡义汉.地热直接利用[M].天津:天津大学出版社,2004:45-68. CAI Yihan.Geothermal direct use[M].Tianjin:Tianjin University Press,2004:45-68. [4] 徐军祥.我国地热资源与可持续开发利用[J].中国人口·资源与环境,2005,4(2):139-141. XU Junxiang.China’s geothermal resources and its sustainable development and utilization[J].China Population,Resources and Environment,2005,4(2):139-141. [5] 王贵玲,张发旺,刘志明.国内外地热能开发利用现状及前景分析[J].地球学报,2000,21(2):134-139. WANG Guiling,ZHANG Fawang,LIU Zhiming.An analysis of present situation and prospects of geothermal energy development and utilization in the world[J].Bulletin of the Chinese Academy of Geological Sciences,2000,21(2):134-139. [6] 吕开河,邱正松,魏慧明,等.自适应防漏堵漏钻井液技术研究[J].石油学报,2008,29(5):757-760,765. LYU Kaihe,QIU Zhengsong,WEI Huiming,et al.Study on techniques of auto-adapting lost circulation resistance and control for drilling fluid[J].Acta Petrolei Sinica,2008,29(5):757-760,765. [7] 宋显民,张立民,李良川,等.水平井和侧钻水平井筛管顶部注水泥完井技术[J].石油学报,2007,28(1):119-121. SONG Xianmin,ZHANG Limin,LI Liangchuan,et al.Top screen pipe cementing technology of casing and liner in horizontal well and sidetracking horizontal well[J].Acta Petrolei Sinica,2007,28(1):119-121. [8] 李国栋.地热钻井技术的若干问题[J].地下水,2008,30(1):85-86,88. LI Guodong.Some problems of geothermal drilling technologies[J].Ground Water,2008,30(1):85-86,88. [9] SAITO S.Recent geothermal well drilling technologies in Kakkonda and Matsukaw[J].Geothermal Resources Council Bulletin,1991,20(6):166-175.
[10] 鲁立强,单正明,邓发兵,等.肯尼亚OLKARIA地热井空气泡沫流体定向钻井综合技术研究[J].科学技术与工程,2009,9(14):4137-4139. LU Liqiang,SHAN Zhengming,DENG Fabing,et al.Study on geothermal well directional drilling with air foam in Kenya Olkaria[J].Science Technology and Engineering,2009,9(14):4137-4139. [11] 程仲,熊继有,程昆.随钻防漏堵漏技术机理的探讨[J].钻采工艺,2008,31(1):36-39. CHENG Zhong,XIONG Jiyou,CHENG Kun.Mechanism analysis about the technology of leak protection and sealing with drilling[J].Drilling Production Technology,2008,31(1):36-39. [12] CAENN R,DARLEY H C H,GRAY G R,et al.Composition and properties of drilling and completion fluids[M].6th ed.USA:Gulf Professional Publishing,2011:298-312.
-
