A Study and Field Test for Solid-Free High Temperature Resistance Hydrophobic Association Polymer Drilling Fluid
-
摘要: 针对现有无固相钻井液抗温能力弱、无法满足高温水平井钻井需要的问题，以两性离子型疏水缔合聚合物PL-5为主剂配制了抗高温疏水缔合聚合物无固相钻井液。对该钻井液的流变性、滤失性、悬浮稳定性、抑制性和储层保护性能进行了室内试验评价，并应用原子力显微镜（AFM）和环境扫描电镜（ESEM）对构建该钻井液液相的聚合物的微观结构进行了观测。室内试验结果表明：该钻井液在160℃下老化后，仍可保持良好的流变性、滤失性和悬浮稳定性；上部地层钻屑的一次滚动回收率达60.1%，下部地层钻屑的一次滚动回收率达87.2%，抑制泥页岩水化分散效果显著；油层岩心的渗透率恢复率可达82.0%以上。抗高温疏水缔合聚合物无固相钻井液在DF1-1气田3口井的水平段钻井中进行了现场试验，结果表明，该钻井液不仅具有良好的流变性、滤失性和悬浮稳定性，而且具有良好的储层保护效果，提速效果显著，能够满足高温水平井钻井需要。Abstract: Existing solid-free drilling fluids may have low temperature resistant performance, but can not satisfy the demands for drilling of horizontal wells in a high temperature regime. To solve this problem, a solid-free high temperature resistant drilling fluid has been developed, taking a zwitterionic hydrophobic associated polymer (PL-5) as the main treatment agent. Its rheological property, filtration loss, suspension stability, inhibition and reservoir protection effectiveness were indoor tested and evaluated, and the microstructure of polymer in liquid drilling fluid was observed by means of atomic force microscopy (AFM) and environmental scanning electron microscopy (ESEM). Test results showed that the newly developed drilling fluid could maintain the desirable rheological property, filtration property and suspension stability after aging at the temperature of 160℃. The first cuttings rolling recovery rate at an upper formation was 60.1%, and later 87.2% at a lower formation. The new drilling fluid can effectively inhibit the hydration of mud shale, and the permeability recovery rate of reservoir core is up to 82.0%. The application effect in three high-temperature horizontal wells of DF1-1 Gas Field showed that the solid-free drilling fluid not only exhibited desirable property of rheology and filtration as well as suspension stability, but also had a good effect for reservoir protection and raising the drilling rate, which can meet the demands of drilling horizontal wells at high temperatures.
-
-
[1] 乌效鸣,胡郁乐,贺冰新,等.钻井液与岩土工程浆液[M].武汉:中国地质大学出版社,2002:122-139. WU Xiaoming,HU Yule,HE Bingxin,et al.Drilling fluid and mud in geotechnical engineering[M].Wuhan:China University of Geosciences Press,2002:122-139. [2] MARTINS A L,WALDMANN A T A,RIBERIRO D D C,et al.Conceptual design of a non-invasive solids free drill in fluid[R].SPE 94287,2005.
[3] XIE S X,CHEN M,JIANG G C,et al.Study and application of weakly gelled shear strength-improving agent (GEL-30) for solids-free drilling fluid[J].Petroleum Science Technology,2012,30(3):316-326.
[4] 甄剑武,王中华,雷祖猛,等.水平井钻井液及储层保护[J].油田化学,2010,27(4):457-461,456. ZHEN Jianwu,WANG Zhonghua,LEI Zumeng,et al.Reservoir protection and fluids technology of horizontal drilling[J].Oilfield Chemistry,2010,27(4):457-461,456. [5] 张丹阳,耿晓光,周大宇,等.无固相钻井液的室内实验研究[J].钻井液与完井液,2009,26(3):38-40. ZHANG Danyang,GENG Xiaoguang,ZHOU Dayu,et al.Laboratory study on solids-free drilling fluids[J].Drilling Fluid Completion Fluid,2009,26(3):38-40. [6] GAMAGE P,DEVILLE J P,SHERMAN J.Solids-free fluid-loss pill for high-temperature reservoirs[J].SPE Drilling Completion,2014,29(1):125-130.
[7] 北京奥凯立科技发展股份有限公司.一种无固相钻井液:201010172378.1[P].2011-01-26. Beijing Oilchemleader Science Technology Development Co.,Ltd.A solid free drilling fluid:201010172378.1[P].2011-01-26. [8] 陈刚,邓强,张洁.无固相钻井液体系的室内研究(Ⅱ)[J].石油化工应用,2010,29(2):22-26. CHEN Gang,DENG Qiang,ZHANG Jie.The indoor research of solid free drilling fluids (Ⅱ)[J].Petrochemical Industry Application,2010,29(2):22-26. [9] 史凯娇,徐同台,甲酸铯/钾无固相钻井液和完井液研究[J].石油钻探技术,2011,39(2):73-76. SHI Kaijiao,XU Tongtai.Reasearh on Cesium/Potassium soild-free drilling and completion fluids[J].Petroleum Drilling Techniques,2011,39(2):73-76. [10] 武学芹,李公让,李斌,等.胜利油田无固相抗高温钻井液体系的研究与应用[J].钻井液与完井液,2005,22(5):41-43. WU Xueqin,LI Gongrang,LI Bin,et al.Study and application of the solids free and high temperature tolerant drilling fluid in Shengli Oilfield[J].Drilling Fluid Completion Fluid,2005,22(5):41-43. [11] 张洁,孙金声,杨枝,等.抗高温无固相钻井液研究[J].石油钻采工艺,2011,33(4):45-47. ZHANG Jie,SUN Jinsheng,YANG Zhi,et al.A solid free drilling fluid with high temperature resistance[J].Oil Drilling Production Technology,2011,33(4):45-47. [12] 刘程,李锐,张光华,等.新型无固相钻井液体系研究新进展[J].天然气工业,2009,29(11):64-66. LIU Cheng,LI Rui,ZHANG Guanghua,et al.New progress in the research into a new type of solid-free drilling fluid system[J].Natural Gas Industry,2009,29(11):64-66. [13] 许明标,马双政,韩金芳,等.抗高温无固相弱凝胶钻井液体系研究[J].油田化学,2012, 29(2):142-145. XU Mingbiao,MA Shuangzheng,HAN Jinfang,et al.Study on high temperature tolerant and solids free weak gelling drilling fluid[J].Oilfield Chemistry,2012,29(2):142-145. [14] 刘建军,刘晓栋,马学勤,等.抗高温耐盐增黏剂及其无固相钻井液体系研究[J].钻井液与完井液,2016,33(2):5-11. LIU Jianjun,LIU Xiaodong,MA Xueqin,et al.Study on high temperature salt-resistant viscosifier and the formulated solids-free drilling fluid[J].Drilling Fluid Completion Fluid,2016,33(2):5-11. [15] 万芬,王昌军.抗高温无黏土相钻井液体系研究[J].石油天然气学报,2014,36(4):140-142. WAN Fen,WANG Changjun.Study on a high-temperature resistant and clay free drilling fluid[J].Journal of Oil and Gas Technology,2014,36(4):140-142. [16] 戴姗姗,蔡馨.一种疏水缔合型阳离子聚合物酸液稠化剂的合成及性能[J].精细化工,2013,30(5):575-579. DAI Shanshan,CAI Xin.Synthesis and evaluation of a hydrophobically associating cationic polymer as acid thickener[J].Fine Chemicals,2013,30(5):575-579. [17] 张德富,卢祥国,李强,等.缔合程度对疏水缔合聚合物增黏性和抗剪切性影响研究[J].西安石油大学学报(自然科学版),2015,30(2):93-97. ZHANG Defu,LU Xiangguo,LI Qiang,et al.Effects of association degree on viscosity increasing and shearing resistance performance of hydrophobic associated polymer[J].Journal of Xi’an Shiyou University(Natural Science Edition),2015,30(2):93-97. [18] 谢彬强,郑力会.基于疏水缔合聚合物的新型钻井液封堵剂[J].石油钻采工艺,2015,37(5):41-45. XIE Binqiang,ZHENG Lihui.A new type plugging agent for drilling fluid based on hydrophobic associative polymer[J].Drilling Production Technology,2015,37(5):41-45. [19] 蒋玲玲,罗平亚,陈馥,等.疏水缔合聚合物在高密度钻井液中的应用研究[J].钻井液与完井液,2005,22(4):5-7. JIANG Lingling,LUO Pingya,CHEN Fu,et al.Application and research of a novel polymer in high density drilling fluid[J].Drilling Fluid Completion Fluld,2005,22(4):5-7. [20] 鄢捷年.钻井液工艺学[M].东营:石油大学出版社,2001:63-104. YAN Jienian.Drilling fluid technology[M].Dongying:Petroleum University Press,2001:63-104. -
