Monte Carlo Simulation-Based Uncertainty Analysis on Extreme Water Injection Pressure
-
摘要: 海上油田注水过程中,为防止由于注水压力不合理而导致盖层完整性被破坏,需要对极限注水压力的不确定性及敏感因素对其的影响规律进行分析。以PL19-3油田某注水井为研究对象,利用FLAC3D软件建立了储盖层模型,模拟计算了盖层开始发生破坏时的注水压力即极限注水压力,分析了渗透率、内聚力和内摩擦角等参数对极限注水压力的影响,并采用蒙特卡洛模拟方法分析了极限注水压力的不确定性。结果表明:当注水压力达到极限注水压力时,盖层开始发生破坏;随着渗透率增大,极限注水压力呈现出先增大后减小再缓慢增大的趋势;随着内聚力和内摩擦角的增大,极限注水压力分别呈现线性增大和二次函数增大的趋势。确定性极限注水压力只是不确定性分析结果的一部分,而通过不确定性分析可以得到盖层发生破坏可能性较大的极限注水压力区间,能够对极限注水压力进行全面评估,可以为现场注水安全管理提供理论指导。Abstract: In order to avoid caprock integrity failure caused by unreasonable water injection pressure during water injection in offshore oil fields, it is necessary to conduct an uncertainty analysis on extreme injection pressure and the controlling influences of sensitive factors on extreme injection pressure. In this paper, a water injector in the PL19-3 Oilfield was taken as a research object and a caprock model was established by using FLAC3D software. Based on this model, the extreme water injection pressure (i.e. the water injection pressure when the caprock is initially broken) was calculated. Then, the effect of sensitive parameters (e.g. permeability, cohesive force and internal friction angle) on extreme injection pressure was analyzed. Furthermore, the uncertainty of extreme water injection pressure was studied by means of Monte Carlo simulation (MCS). It is shown that cap rocks begin to break when the extreme injection pressure is reached. As the permeability increases, extreme injection pressure varies, first in the trend of increasing, decreasing then increasing slowly. The extreme injection pressure increases linearly as the cohesive force increases, but in the form of quadratic function with the increasing of the internal friction angle. A deterministic result of extreme injection pressure is only a part of the uncertainty analysis. Through uncertainty analysis, the range of extreme injection pressure with higher probability of caprock failure can be revealed and extreme injection pressure can be evaluated comprehensively so as to provide the theoretical guidance in the secure management of water injection.
-
Keywords:
- injection pressure /
- Monte Carlo simulation /
- uncertainty /
- permeability /
- cohesive force /
- internal friction angle
-
-
[1] WEI Lai,HU Zhuowei,DONG Lin,et al.A damage assessment model of oil spill accident combining historical data and satellite remote sensing information:a case study in Penglai 19-3 oil spill accident of China[J].Marine Pollution Bulletin,2015,91(1):258-271.
[2] JIN Zhijun,YUAN Yusong,SUN Dongsheng.Models for dynamic evaluation of mudstone/shale cap rocks and their applications in the Lower Paleozoic sequences,Sichuan Basin,SW China[J].Marine and Petroleum Geology,2014,49:121-128.
[3] 黄学,付广,赖勇,等.断裂对盖层封闭性破坏程度定量研究[J].大庆石油地质与开发,2008,27(6):5-9. HUANG Xue,FU Guang,LAI Yong,et al.Quantitative research on destroy degree of caprock seal by faults[J].Petroleum Geology Oilfield Development in Daqing,2008,27(6):5-9. [4] 曹广胜,谭畅,宋福昌,等.低渗透油田强化注水压力界限研究[J].科学技术与工程,2012,12(13):3107-3110,3115. CAO Guangsheng,TAN Chang,SONG Fuchang,et al.Pressure limit of enhanced water injection in low permeability oilfield[J].Science Technology and Engineering,2012,12(13):3107-3110,3115. [5] 赵永胜,陆蔚刚,兰玉波,等.多层砂岩油田水驱开发的合理注水压力[J].大庆石油地质与开发,2000,19(6):21-24. ZHAO Yongsheng,LU Weigang,LAN Yubo,et al.Reasonable water injection pressure of water flooding of multi-layer sandstone oil fields[J].Petroleum Geology Oilfield Development inDaqing,2000,19(6):21-24. [6] 刘洪杰,陈鸿,王海更,等.海上复杂断块油田合理注水压力研究[J].断块油气田,2015,22(2):228-233. LIU Hongjie,CHEN Hong,WANG Haigeng,et al.Study on reasonable water injection pressure of offshore complex fault-block oilfield[J].Fault-Block Oil and Gas Field,2015,22(2):228-233. [7] 张书伟,林杭,任连伟.FLAC3D在岩土工程中的应用[M].北京:中国水利水电出版社,2011:83-107. ZHANG Shuwei,LIN Hang,REN Lianwei.The application of FLAC3D to geotechnical engineering[M].Beijing:China Waterpower Press,2011:83-107. [8] 孙国权,李娟,胡杏保.基于FLAC3D程序的采空区稳定性分析[J].金属矿山,2007(2):29-32. SUN Guoquan,LI Juan,HU Xingbao.FLAC3D-based stability analysis of mined-out area[J].Metal Mine,2007(2):29-32. [9] 李春艳.利用蒙特卡洛模拟与风险分析优选水平井完井方式[J].石油钻探技术,2009,37(5):52-57. LI Chunyan.Applications of Monte Carlo simulation method and risk analysis in horizontal well completion optimization[J].Petroleum Drilling Techniques,2009,37(5):52-57. [10] 董玉亮,顾煜炯,杨昆.基于蒙特卡洛模拟的发电厂设备重要度分析[J].中国电机工程学报,2003,23(8):201-205. DONG Yuliang,GU Yujiong,YANG Kun.Criticality analysis on equipment in power plant based on Monte Carlo simulation[J].Proceedings of the Chinese Society for Electrical Engineering,2003,23(8):201-205. [11] 李帅芳,肖果平.Crystal Ball在项目管理风险分析中的应用[J].项目管理技术,2013,11(4):40-44. LI Shuaifang,XIAO Guoping.Application of Crystal Ball in project management risk analysis[J].Project Management Technology,2013,11(4):40-44. [12] HENLEY H,LUCIA A.Constant pressure Gibbs ensemble Monte Carlo simulations for the prediction of structure I gas hydrate occupancy[J].Journal of Natural Gas Science and Engineering,2015,26:446-452.
-
