The Development and Application of a High Efficiency Hydraulic Casing Restoration Tool
-
摘要: 针对辽河油田变形套管整形修复率低、施工周期长及成本高的问题,根据液力增压和滚珠挤压整形原理,研制了高效液压套管整形工具。该整形工具由整形头、增压液缸、泄压装置和液压锚定装置构成。室内试验表明:液压套管整形工具的整形效率高,与常规整形工具相比,整形效率提高约40%,且对套管损伤小,能尽可能恢复套管内径。该整形工具在辽河油田13口套损井进行了现场应用,顺利完成了12口井的套管修复,成功率92.3%。研究与应用表明,液压套管整形工具适用于套管缩径井的修复作业,能基本满足辽河油田套损井套管整形的需要。
-
关键词:
- 套管损坏 /
- 套管整形 /
- 杜80-30-58井 /
- 辽河油田
Abstract: At present, operations related to the restoration of deformed casing in the Liaohe Oilfield can be characterized by low success rates, long operation duration and high costs. Based on the principles of hydraulic boosting and rolling ball squeezing, a high efficiency hydraulic casing restoration tool has been developed, which is composed of a shaping head, pressure cylinder, pressure relief device and hydraulic anchoring device. Experimental results showed that the hydraulic casing shaping tool possessed high shaping efficiency, the average single well restoration duration was reduced by 40% from the original state. With less damage to the casing, the newly developed tool could be used to achieve maximum restoration of inner size of the casing. This tool has been used in the casing restoration of 13 wells in the Liaohe Oilfield and experienced success in 12 wells, resulting in a success rate of 92.3%. Both research results and application performances showed that the hydraulic casing restoration tool could be used for casing restoration of wells with deformed casing to meet the demands for casing re-shaping in the Liaohe Oilfield.-
Keywords:
- casing damage /
- hydraulic casing restoration /
- Well Du-80-30-58 /
- Liaohe Oilfield
-
-
[1] 李海军.辽河油田套损机理及防治建议[J].内蒙古石油化工,2012,22(3):57-59. LI Haijun.The mechanism and prevention of casing damage in Liaohe Oilfield[J].Inner Mongulia Petrochemical Industry,2012,22(3):57-59. [2] 翟晓鹏,楼一珊,周建良,等.套管径向变形可修复界限研究[J].石油钻探技术,2012,40(1):28-31. ZHAI Xiaopeng,LOU Yishan,ZHOU Jianliang,et al.Study of minimum repair limit for reduced casing deformation[J].Petroleum Drilling Techniques,2012,40(1):28-31. [3] 王小增,杨久红,窦益华.套管磨损后剩余壁厚及剩余强度分析[J].石油钻探技术,2008,36(2):14-17. WANG Xiaozeng,YANG Jiuhong,DOU Yihua.Analysis of casing remaining thickness and residual strength after wearing[J].Petroleum Drilling Techniques,2008,36(2):14-17. [4] 阚庆山,刘汝东,苏娟.套损井修复技术在中原油田的应用[J].断块油气田,2009,16(3):121-122. KAN Qingshan,LIU Rudong,SU Juan.Application of repairing technology for casing damage well in Zhongyuan Oilfield[J].Fault-Block Oil Gas Field,2009,16(3):121-122. [5] 窦益华,张福祥,王维君,等.井下套管磨损深度及剩余强度分析[J].石油钻采工艺,2007,29(4):36-39. DOU Yihua,ZHANG Fuxiang,WANG Weijun,et al.Analysis on wear depth and residual strength of downhole casing[J].Oil Drilling Production Technology,2007,29(4):36-39. [6] 梁尔国,李子丰,赵金海.磨损套管抗挤强度计算模型[J].石油钻探技术,2012,40(2):41-45. LIANG Erguo,LI Zifeng,ZHAO Jinhai.Model for collapsing strength calculation of worn casing[J].Petroleum Drilling Techniques,2012,40(2):41-45. [7] 王维星,武瑞霞,李在训,等.液压变径滚压套管整形技术[J].石油机械,2010,38(7):86-87. WANG Weixing,WU Ruixia,LI Zaixun,et al.Hydraulic variable diameter rolling sleeve shaping technique[J].China Petroleum Machinery,2010,38(7):86-87. [8] 房育金,郭伟锋,张云杰,等.低渗透油田套管损坏机理分析及防治措施[J].特种油气藏,2006,13(4):78-80. FANG Yujin,GUO Weifeng,ZHANG Yunjie,et al.Casing failure mechanism analysis and prevention measures[J].Special Oil Gas Reservoirs,2006,13(4):78-80. [9] 田玉刚,皇甫洁,李华彬.套变井液压整形技术研究[J].胜利油田职工大学学报,2009,23(3):45-46,48. TIAN Yugang,HUANGFU Jie,LI Huabin.Study on the hydraulic shaping technology of the casing damage well[J].Journal of Shengli Oil Field Staff University,2009,23(3):45-46,48. [10] 何育荣,朱海波.膨胀筛管的研制及现场试验[J].石油钻探技术,2011,39(3):106-109. HE Yurong,ZHU Haibo.Expansion sand screen development and field test[J].Petroleum Drilling Techniques,2011,39(3):106-109. [11] 关舒伟,李春福,李学艺,等.非均匀外挤压力作用下内径偏磨套管的应力分析[J].石油钻探技术,2009,37(2):38-40. GUAN Shuwei,LI Chunfu,LI Xueyi,et al.Stress analysis of worn casing under heterogeneous external pressure[J].Petroleum Drilling Techniques,2009,37(2):38-40. [12] 宋根才.复杂井况水平井套管损坏机理及预防技术研究[D].东营:中国石油大学(华东)机电工程学院,2010. SONG Gencai.Study on casing damage mechanism and prevention[D].Dongying:China University of Petroleum(Huadong),College of Mechanical and Electronic Engineering,2010. -
