A Simulation Study on the Cutter Loads on the End Face of DTH Bits
-
摘要: 为使潜孔钻头布齿更加合理及为钻头结构改进提供理论依据,达到提高潜孔钻头破岩效率、延长其使用寿命的目的,需要了解潜孔钻头端面切削齿的载荷分布。为此,建立了平面、凸面和凹面3种端面形式的潜孔钻头三维模型,以显式动力分析软件ANSYS/LS-DYNA中常用的H-J-C模型为材料模型,并利用H-J-C模型中的等效屈服强度、压力、积累损伤等函数对潜孔钻头的破岩过程进行仿真,分析不同齿圈上切削齿的载荷状态,并将切削齿载荷分解到轴向、径向及切向3个方向,运用控制变量的方法对3种不同端面形式潜孔钻头的切削齿进行力学分析。研究结果表明:凹面潜孔钻头的轴向载荷峰值最大且径向载荷峰值最小;潜孔钻头切削齿载荷的主要差别在边齿及其相邻齿圈的切削齿上,与其余齿圈上的切削齿关系不大;潜孔钻头边齿的载荷最大,易损坏。模拟结果可为切削齿的选择、切削齿的分布及潜孔钻头的结构设计提供依据。Abstract: In order to make the DTH bit tooth arrangement more reasonable and to provide a theoretical basis for the improvement of bit structure, so as to improve the rock breaking efficiency of the DTH bit and to prolong its service life, it is necessary to understand the load distribution on the end face of DTH bit. Therefore, a three-dimensional model for DTH bits has been established, with three kinds of end faces, including plane, convex face and concave face, which taken the H-J-C of explicit dynamic analysis software ANSYS/LS-DYNA as the material model, and used the equivalent yield strength, pressure and accumulated damage of H-J-C to simulate the rock breaking process of DTH bits.The load status of cutting teeth on different tooth rings has been analyzed, and they decomposed the loads into three directions:i.e. axial, radial and tangential. At the same time, the mechanical analysis for cutting teeth of the DTH bit with three kinds of end faces were conducted by controlling variables. Research results showed that DTH bits with concave surfaces had maximum axial loads and minimum radial loads; the main differences of loads on cutting teeth of DTH bits were reflected predominantly by side teeth and neighboring teeth, it has little relation with the cutting teeth on the other rings. With maximum loads, side teeth on DTH bits are susceptible to damage. Simulation results may provide reliable guidance for selecting and arranging the cutting teeth, and for designing the structure of DTH bits.
-
Keywords:
- DTH bit /
- load on cutter /
- rock breaking /
- simulation
-
-
[1] KREUZER E,STEIDL M.Controlling torsional vibrations of drill strings via decomposition of traveling waves[J].Archive of Applied Mechanics,2012,82(4):515-531.
[2] 黄志强,沈岳,卜艳,等.空气冲旋钻头牙齿失效分析与新材料实验研究[J].西南石油大学学报(自然科学版),2010,32(4):175-178. HUANG Zhiqiang,SHEN Yue,BU Yan,et al.Cutter failure analysis and new material experiment research on air impact rotary drill[J].Journal of Southwest Petroleum University (Science Technology Edition),2010,32(4):175-178. [3] CHIANG L E,STAMM E B.Design optimization of valveless DTH pneumatic hammers by a weighted pseudo-gradient search method[J].Journal of Mechanical Design,1998,120(4):687-694.
[4] OKUCHABA B J.Development of a model to calculate mechanical specific energy for air hammer drilling systems[D].Texas:Texas A M University,2008.
[5] 王明和.球齿钻头齿数的确定及其布置[J].有色金属(矿山部分),1981(2):22-25,19. WANG Minghe.The determination of the number of button bit teeth and its layout[J].Nonferrous Metals(Mining),1981(2):22-25,19. [6] 谭卓英,赖海辉.球齿钻(钎)头边齿失效问题分析[J].凿岩机械气动工具,1990(3):17-24. TAN Zhuoying,LAI Haihui.Failure problem analysis of sides tooth on button bit[J].Rock Drilling Machinery Pneumatic Tools,1990(3):17-24. [7] 李华,孙友宏.球齿钻头布齿的优化方法探讨[J].探矿工程(岩土钻掘工程),2001,28(2):39-40,43. LI Hua,SUN Youhong.Optimization method of teeth arrangement on button bit[J].Exploration Engineering(Rock Soil Drilling and Tunneling),2001,28(2):39-40,43. [8] 周晔.硬质合金复合片齿钎头破岩机理探讨[J].矿山机械,2003(3):11-12. ZHOU Ye.Rock fragmentation mechanism of cemented carbide composite cutter bit[J].Mining Processing Equipment,2003(3):11-12. [9] 范永涛,黄志强,高德利,等.物探冲旋钻头破岩机理仿真研究[J].石油钻探技术,2011,39(3):110-113. FAN Yongtao,HUANG Zhiqiang,GAO Deli,et al.Research on rock breaking mechanism of geophysical prospecting hammer bit[J].Petroleum Drilling Techniques,2011,39(3):110-113. [10] 李宏利,于庆增,王绍丽,等.金刚石复合齿潜孔钻头的研究与应用[J].超硬材料工程,2013,25(1):16-19. LI Hongli,YU Qingzeng,WANG Shaoli,et al.Research and application of PDC drilling down-the-hole bit[J].Superhard Material Engineering,2013,25(1):16-19. [11] FRANQUET J A,KRISADASIMA S,JOC H V,et al.Critically-stressed fracture analysis contributes to determining the optimal drilling trajectory in naturally fractured reservoirs[R].ITPC 12669,2008.
[12] 祝效华,罗衡,贾彦杰.考虑岩石疲劳损伤的空气冲旋钻井破岩数值模拟研究[J].岩石力学与工程学报,2012,31(4):754-761. ZHU Xiaohua,LUO Heng,JIA Yanjie.Numerical analysis of air hammer bit drilling based on rock fatigue model[J].Chinese Journal of Rock Mechanics and Engineering,2012,31(4):754-761. [13] REINSVOLD C H,CLEMENT J,OLIVER M,et al.Diamond-enhanced hammer bits reduce cost per foot in the Arkoma and Appalachian basins[R].SPE 17185,2011.
[14] 林元华,施太和,李润方,等.空气冲旋钻井冲击力和机械钻速仿真研究[J].岩石力学与工程学报,2005,24(18):3337-3341. LIN Yuanhua,SHI Taihe,LI Runfang,et al.Simulation of impact force and penetration rate of air hammer bit drilling[J].Chinese Journal of Rock Mechanics and Engineering,2005,24(18):3337-3341. [15] ZHAO Zhiqiang,LI Lijia,HUAN Xiangtian,et al.Numerical optimization of structural parameters on GQ-108C air reverse circulation DTH hammer bit[J].Communications in Computer and Information Science,2014,405:589-601.
[16] 朱海燕,刘清友,邓金根,等.冲旋钻井条件下的岩石破碎机理[J].应用基础与工程科学学报,2012,20(4):622-631. ZHU Haiyan,LIU Qingyou,DENG Jingen,et al.Rock breaking mechanism on the conditions of percussion-rotary drilling[J].Journal of Basic Science and Engineering,2012,20(4):622-631. [17] 王泽鹏,胡仁喜,康士延,等.ANSYS13.0/LS-DYNA非线性有限元分析实例指导教程[M].北京:机械工业出版社,2011. WANG Zepeng,HU Renxi,KANG Shiyan,et al.Tutorial on nonlinear finite element analysis[M].Beijing:China Machine Press,2011. [18] BU Changgen,QU Yegao,CHENG Zhiqiang,et al.Numerical simulation of impact on pneumatic DTH hammer percussive drilling[J].Journal of Earth Science,2009,20(5):868-878.
-
