Development and Field Application of a New High-Temperature Cement Suspension Agent
-
摘要: 针对深井井下温度高、水泥浆沉降稳定性难以保证的问题,研制了共聚物水泥悬浮剂。选用2-丙烯酰胺基-2-甲基丙磺酸(AMPS)、丙烯酰胺(AM)和N-乙烯基吡咯烷酮(NVP)为共聚单体,采用自由基水溶液聚合法,合成了三元共聚物(AMPS/AM/NVP)水泥悬浮剂,并根据正交试验结果,确定了其最佳合成条件。利用红外光谱和核磁共振谱分析验证了其结构,热分析结果表明其具有较好的热稳定性。性能评价试验表明,合成的共聚物悬浮剂在200℃下能够控制水泥石上下密度差小于0.01 g/cm3、游离液为0,且抗饱和盐水,稠化性能、滤失性、流变性、强度等性能均满足现场要求。3口井的现场试验表明,新型抗高温水泥悬浮剂可以提高深井固井施工安全和固井质量。Abstract: In this paper, a copolymer cement suspension agent was developed in order to solve problems found in deep wells, such as high temperature and settlement stability of cementing slurry. The terpolymer (AMPS/AM/NVP) cement suspension agent was synthesized with 2-acrylamido-2-methylpropane sulfonic acid (AMPS), acrylamide (AM) and N-vinyl-2-pyrrolidone (NVP) as comonomers by means of free-radical aqueous solution polymerization. And its optimum synthesis conditions were confirmed on the basis of orthogonal test results. Its structure was analyzed by means of infrared spectrum analysis and nuclear magnetic resonance spectroscopy. Based on thermal analysis, it was thermally stable. Further, it was demonstrated by performance test results that based on this copolymer suspension agent, that the settlement stability of cement slurry at 200℃ could be kept below 0.01 g/cm3, with free fluid 0. Further, there was enhanced saturated brine tolerance. The new copolymer suspension agent could meet field requirements comprehensively in terms of thickening, filtration, rheological behavior and strength. It was demonstrated by field tests of three wells that this kind of new high-temperature cement suspension agent played an effective role in improving the safety and quality of cementing operations in deep wells.
-
Keywords:
- high temperature /
- cementing /
- suspending agent /
- copolymer
-
-
[1] 宋元洪,杨远光,张玉平,等.高密度水泥浆沉降稳定性评价方法探讨[J].钻井液与完井液,2015,32(6):54-56. SONG Yuanhong,YANG Yuanguang,ZHANG Yuping,et al.Determination of parameters controlling sedimentation stability of high density cement slurries[J].Drilling Fluid Completion Fluid,2015,32(6):54-56. [2] 秦国宏,覃毅,尤凤堂,等.水泥浆失重对高压油气井固井质量的影响分析及工艺对策[J].探矿工程(岩土钻掘工程),2015,42(3):33-36. QIN Guohong,QIN Yi,YOU Fengtang,et al.Analysis on the impact of weight loss of cement slurry on cementing quality for high-pressure oil and gas well and the technical countermeasures[J].Exploration Engineering (Rock Soil Drilling and Tunneling),2015,42(3):33-36. [3] 赵喜政,周思雅,姜宇.压裂液中增稠剂的研究[J].广州化工,2014,42(9):108-110. ZHAO Xizheng,ZHOU Siya,JIANG Yu.Study of fracturing thickening agent[J].Guangzhou Chemical Industry,2014,42(9):108-110. [4] 卢海川,朱海金,李宗要,等.水泥浆悬浮剂研究进展[J].油田化学,2014,31(2):307-310. LU Haichuan,ZHU Haijin,LI Zongyao,et al.Review on suspending agents for cement slurry[J].Oilfield Chemistry,2014,31(2):307-310. [5] BROTHERS L E.Composition and method for inhibiting thermal thinning of cement:5135577[P].1992-08-04.
[6] REDDY B R,RILEY W D.High temperature viscosifying and fluid loss controlling additives for well cements,well cement composition and methods:6770604[P].2004-08-03.
[7] 张清,徐明,钟福海,等.高温悬浮稳定剂DRY-S2的研究与应用[J].钻井液与完井液,2013,30(3):61-63. ZHANG Qing,XU Ming,ZHONG Fuhai,et al.Research and application of high temperature suspension stabilizer DRY-S2[J].Drilling Fluid Completion Fluid,2013,30(3):61-63. [8] 卢海川,邢秀萍,谢承斌,等.新型固井悬浮剂的开发[J].钻井液与完井液,2014,31(1):60-63. LU Haichuan,XING Xiuping,XIE Chengbin,et al.Research on a new type of suspending agent on cementing[J].Drilling Fluid Completion Fluid,2014,31(1):60-63. [9] 张浩,李厚铭,符军放,等.固井用悬浮稳定剂SS-10L的研究应用[J].科学技术与工程,2015,15(3):212-215. ZHANG Hao,LI Houming,FU Junfang,et al.Research and application of cementing suspension stabilizer SS-10L[J].Science Technology and Engineering,2015,15(3):212-215. [10] 郭锦棠,夏修建,刘硕琼,等.适用于长封固段固井的新型高温缓凝剂HTR-300L[J].石油勘探与开发,2013,40(5):611-615. GUO Jintang,XIA Xiujian,LIU Shuoqiong,et al.A high temperature retarder HTR-300L used in long cementing interval[J].Petroleum Exploration and Development,2013,40(5):611-615. [11] 朱兵,聂育志,邱在磊,等.AMPS/DMAN/AA共聚物固井降滤失剂的研究[J].石油钻探技术,2014,42(6):40-44. ZHU Bing,NIE Yuzhi,QIU Zailei,et al.Research on fluid loss additives of AMPS/DMAN/AA in well cementing[J].Petroleum Drilling Techniques,2014,42(6):40-44. [12] 李炎.耐高温聚合物降滤失剂AAS的研制与性能评价[J].石油钻探技术,2015,43(4):96-101. LI Yan.Development and performance evaluation of the high temperature resistant polymer fluid loss agent AAS[J].Petroleum Drilling Techniques,2015,43(4):96-101. [13] 何曼君,张红东,陈维孝,等.高分子物理[M].3版.上海:复旦大学出版社,2008:26-44. HE Manjun,ZHANG Hongdong,CHEN Weixiao,et al.Polymer physics[M].3rd ed.Shanghai:Fudan University Press,2008:26-44. [14] 潘祖仁.高分子化学[M].4版.北京:化学工业出版社,2009:127-133. PAN Zuren.High polymer chemistry[M].4th ed.Beijing:Chemical Industry Press,2009:127-133. [15] 肖诗唐,王毓芳,郝凤.新产品开发设计与技术统计[M].北京:中国计量出版社,2001:75-89. XIAO Shitang,WANG Yufang,HAO Feng.New product development design and technical statistics[M].Beijing:China Metrology Press,2001:75-89. [16] 赵藻藩,周性尧,张悟铭,等.仪器分析[M].北京:高等教育出版社,1997:81-132. ZHAO Zaofan,ZHOU Xingyao,ZHANG Wuming,et al.Instrument analysis[M].Beijing:Higher Education Press,1997:81-132. -
