Cable Conveying and Releasing Logging Meter in Complicated Horizontal Wells in Western Sichuan
-
摘要: 川西地区水平井在进行常规泵出式测井时,若钻杆不能下到位会造成漏测水平段油气层,针对这一问题,对常规泵出式测井工艺进行了改良,研制了特制引鞋、电缆旁通短节、熔断式马笼头和抓捞器等测井工具,形成了泵送电缆释放测井工艺。该测井工艺将钻杆下至预定位置后,从钻杆内用电缆将测井仪输送至遇阻位置,利用高压钻井液将测井仪推送至预定位置,然后供电分离电缆与测井仪,回收电缆后起钻测井,测井结束后,将测井仪打捞出,读取测井数据。泵送电缆释放测井工艺在川西地区复杂井眼轨迹水平井测井中应用了13井次,测井一次成功率100%,获取了全部水平段自然伽马、双侧向、补偿声波时差、补偿中子等测井曲线,且质量满足行业标准,合格率100%。现场应用表明,泵送电缆释放测井工艺能满足复杂井眼轨迹水平井测井需要。Abstract: Due to conventional pump-out logging methods in horizontal-well it was not possible to run drill pipe or logs to the expected position in Western Sichuan, resulting in the loss of oil and gas data measurement. To solve the problem, conventional logging technology was improved by specially designing a guide shoe, cable bypass pup joint, fusing cable head and catch tools, and a technology of pumping down cables for conveying and releasing logging meter was developed, i.e. the drill pipe was lowered to the bottom hole, conveying the logging tools to the sticking point, and then pushing it to the predetermined position by pumping drilling fluids, where the cables were separated with logging tools, and the logging operation was conducted after the cables were recovered, Finally, the drill pipes were pulled out of the hole, so that the logging data could be read after logging tools were taken out of the hole. In western Sichuan, the pumping cable technology for conveying and releasing logging meter has been applied 13 times in complicated-trajectory horizontal wells, with one-time logging success rate of 100%, resulting in successful logging curves for natural gamma ray, dual lateral logging, compensation interval transit time, compensated neutron logs being obtained, with all the curves meeting the SY/T 5132-2003 Industrial Standard. Field application showed that pumping cable technology for conveying and releasing logging meter was applicable to the horizontal wells with complicated well trajectory.
-
Keywords:
- logging /
- horizontal well /
- logging meter /
- logging curve /
- Western Sichuan
-
-
[1] 韩来聚,牛洪波.对长水平段水平井钻井技术的几点认识[J].石油钻探技术,2014,42(2):7-11. Han Laiju,Niu Hongbo.Understandings on drilling technology for long horizontal section wells[J].Petroleum Drilling Techniques,2014,42(2):7-11. [2] 徐进,胡大梁,任茂,等.川西深井井下复杂情况及故障预防与处理[J].石油钻探技术,2010,38(4):22-25. Xu Jin,Hu Daliang,Ren Mao,et al.Prevention and treatment of complicated downhole conditions and accidents of deep wells in Western Sichuan[J].Petroleum Drilling Techniques,2010,38(4):22-25. [3] 陆黄生.测井技术在石油工程中的应用分析与发展思考[J].石油钻探技术,2012,40(6):1-7. Lu Huangsheng.Application and development analysis of well logging information in petroleum engineering[J].Petroleum Drilling Techniques,2012,40(6):1-7. [4] 卢世春,王爱英,雷真田,等.湿接头式水平井测井原理和仪器改进[J].石油仪器,2012,26(6):44-45,48. Lu Shichun,Wang Aiying,Lei Zhentian,et al.Wet-connector horizontal well logging principle and improvement of instruments[J].Petroleum Instruments,2012,26(6):44-45,48. [5] 徐俊博,信毅,吴兴能,等.SL6000 LWF钻杆输送无电缆测井在塔里木油田的应用[J].国外测井技术,2013,34(2):14-17. Xu Junbo,Xin Yi,Wu Xingneng,et al.Application of LWF drill pipe conveying without wireline logging in Tarim Oilfield[J].World Well Logging Technology,2013,34(2):14-17. [6] 任中豪,张文昌.LWF存储式测井在冀东油田的应用[J].石油天然气学报,2012,34(9):222-225. Ren Zhonghao,Zhang Wenchang.Drill-pipe conveying no-cable logging in Jidong Oilfield[J].Journal of Oil and Gas Technology,2012,34(9):222-225. [7] 黎泽刚,葛祥,徐炳高,等.存储式测井技术在川西水平井中的应用[J].工程地球物理学报,2015,12(4):544-548. Li Zegang,Ge Xiang,Xu Binggao,et al.The application of the memory logging technology in horizontal well in Western Sichuan[J].Chinese Journal of Engineering Geophysics,2015,12(4):544-548. [8] 张正玉.泵出式测井系统在四川地区复杂井中的应用[J].测井技术,2012,36(4):426-430. Zhang Zhengyu.Application of pump-out logging system to complex wells in Sichuan Oilfield[J].Well Logging Technology,2012,36(4):426-430. [9] 王冬冬,张传举,申小虎.LWF测井在碳酸盐岩地层的应用[J].国外测井技术,2013,34(6):64-66. Wang Dongdong,Zhang Chuanju,Shen Xiaohu.Application of LWF-logging in carbonate rock[J].World Well Logging Technology,2013,34(6):64-66. [10] 张辛耘,王敬农,郭彦军.随钻测井技术进展和发展趋势[J].测井技术,2006,30(1):10-15. Zhang Xinyun,Wang Jingnong,Guo Yanjun.Advances and trends in logging while drilling technology[J].Well Logging Technology,2006,30(1):10-15. -
