Horizontal Bedding Shale in-Situ Stress Calculation Inverted from Adjacent Beds
-
摘要: 水平层理页岩垂直和平行层理方向岩石力学特性的强差异及岩石的破碎性,造成现有地应力计算方法精度不够及地应力室内岩心试验困难。为了有效地指导钻井和压裂设计,开展了页岩地应力评价方法研究。利用单轴压缩试验,获得了不同层理面方向的页岩弹性参数,岩石呈现明显的横观各向同性特征。基于横观各向同性材料的本构关系、并假设在沉积和后期地质构造运动过程中地层和地层之间不发生相对位移,建立了利用邻层砂泥岩地应力反演水平层理页岩地应力的模型,并分析了地应力的敏感性因素及其影响规律。结果表明,页岩地应力受控于邻层砂泥岩的弹性模量、泊松比、地应力值和页岩自身的弹性参数,利用该方法计算的最大和最小水平主应力值比Terzaghi和Newberry模式高,处于黄荣樽模式的上、下限范围内。研究结果为评价水平层理页岩地应力提供了新的方法。Abstract: Due to rock friability and the strong difference of rock mechanical characteristics between parallel and vertical bedding directions of the horizontal bedding shale, existing in-situ stress calculation methods could not meet the accuracy requirements and it is difficult to perform laboratory in-situ tests on the cores. Therefore, shale in-situ stress evaluation methods were studied in this paper so as to provide the effective guidance for well drilling and fracturing design. The shale elasticity parameters in different bedding directions were obtained by means of uniaxial compression tests, and the transversely isotropic characteristics were presented obviously. Based on the constitutive relation of transversely isotropic materials, the model for horizontal bedding shale in-situ stress inverted from its adjacent sand-shale in-situ stress was established, after it was assumed that there was no relative displacement between the formations in the process of the deposition and later tectonic movement. An analysis was conducted on sensitivity factors and influence laws. It is shown that the shale in-situ stress was controlled by its own elastic parameters and the elastic modulus, Poisson’s ratio and in-situ stress value of its adjacent sand-shale beds. The two horizontal in-situ stresses calculated with this method were higher than those obtained with the Terzaghi and Newberry models, and they were between the upper and lower limits of Huang Rongzun model.The research results in this paper provided a new method for evaluating the in-situ stress of horizontal bedding shale.
-
Keywords:
- in-situ stress /
- horizontal bedding /
- shale /
- transversely isotropic
-
-
[1] 邹才能,董大忠,王社教,等.中国页岩气形成机制,地质特征及资源潜力[J].石油勘探与开发,2010,37(6):641-653. Zou Caineng,Dong Dazhong,Wang Shejiao,et al.Geological characteristics,formation mechanism and resource potential of shale gas in China[J].Petroleum Exploration and Development,2010,37(6):641-653. [2] 袁俊亮,邓金根,蔚宝华,等.页岩气藏水平井井壁稳定性研究[J].天然气工业,2012,32(9):66-70. Yuan Junliang,Deng Jingen,Yu Baohua,et al.Wellbore stability of horizontal wells in shale gas reservoirs[J].Natural Gas Industry,2012,32(9):66-70. [3] 张斌,杨佳玲,解琪,等.地应力分析在鄂西渝东地区页岩气开发中的应用[J].天然气勘探与开发,2012,35(12):33-37. Zhang Bin,Yang Jialing,Xie Qi,et al.Application of ground stress analysis to shale gas development in Western Hubei and Eastern Chongqing Region[J].Natural Gas Exploration Development,2012,35(12):33-37. [4] Matthews W R,Kelly J.How to predict formation pressure and fracture gradient[J].Oil and Gas,1967,65(8):92-106.
[5] Anderson R A,Ingram D S,Zanier A M.Determining fracture pressure gradient from well logs[J].JPT,1973,25(11):1259-1268.
[6] 黄荣樽.地层破裂压力预测模式的探讨[J].华东石油学院学报,1984,8(4):335-347. Huang Rongzun.A model for prediction formation fracture pressure[J].Journal of Huadong Petroleum Institute,1984,8(4):335-347. [7] 王倩,王鹏,项德贵,等.页岩力学参数各向异性研究[J].天然气工业,2012,32(12):62-66. Wang Qian,Wang Peng,Xiang Degui,et al.Anisotropic property of mechanical parameters of shales[J].Natural Gas Industry,2012,32(12):62-66. [8] Sayers C M.Seismic anisotropy of shales[J].Geophysical Prospecting,2005,53(5):667-676.
[9] 李庆辉,陈勉,金衍,等.页岩气储层岩石力学特性及脆性评价[J].石油钻探技术,2012,40(4):17-22. Li Qinghui,Chen Mian,Jin Yan,et al.Rock mechanical properties and brittleness evaluation of shale gas reservoir[J].Petroleum Drilling Techniques,2012,40(4):17-22. [10] 邓金根,陈峥嵘,耿亚楠,等.页岩储层地应力预测模型的建立和求解[J].中国石油大学学报:自然科学版,2013,37(6):59-64. Deng Jingen,Chen Zhengrong,Geng Yanan,et al.Prediction model for in-situ formation stress in shale reservoirs[J].Journal of China University of Petroleum:Edition of Natural Science,2013,37(6):59-64. [11] 马天寿,陈平.层理页岩水平井井周剪切失稳区域预测方法[J].石油钻探技术,2014,42(5):27-36. Ma Tianshou,Chen Ping.Prediction method of shear instability region around the bore hole for horizontal wells in bedding shale[J].Petroleum Drilling Techniques,2014,42(5): 27-36. [12] 陈强,朱宝龙,胡厚田.岩石Kaiser 效应测定地应力场的试验研究[J].岩石力学与工程学报,2006,25(7):1370-1376. Chen Qiang,Zhu Baolong,Hu Houtian.Experimental research on measurement of in-situ stress field by Kaiser effect[J].Chinese Journal of Rock Mechanics and Engineering,2006,25(7):1370-1376. -
