Experimental Study on Drill Pipe Stress-Fatigue Life Curve
-
摘要: 钻杆的疲劳失效是引发钻井井下事故的主要原因,因此有必要对钻杆的应力-疲劳寿命曲线进行试验研究。采用旋转弯曲疲劳试验机,研究了常用的S135和G105钻杆的疲劳性能;采用疲劳寿命对数正态分布模型,得出了任意存活率对应的应力-疲劳寿命曲线;采用直接外推法和2m-1外推法将疲劳曲线延伸到长寿命区域,并将其外推结果与配对升降法试验结果进行了对比。升降法试验得出S135和G105钻杆的疲劳强度(存活率为99%,置信度为95%)分别为550.19 MPa和454.79 MPa;由直接外推存活率99%的曲线得到疲劳寿命为1.0×107时,S135和G105钻杆对应强度分别为510.23 MPa和402.01 MPa;由2m-1外推法外推存活率99%的曲线得到疲劳寿命为1.0×107时,S135和G105钻杆对应强度分别为532.95 MPa和428.98 MPa。试验表明,2种外推方法得到的疲劳强度均低于试验值,2m-1 外推法得到的疲劳强度值更接近升降法试验值,因此推荐使用2m-1外推法对概率-应力-疲劳寿命曲线进行外推来得到完整的疲劳寿命曲线。Abstract: Drill pipe failure due to fatigue is the main cause of the oilfield drilling accidents, so it is necessary to study the stress-fatigue life curves of drill pipes. The fatigue performances of S135 and G105 drill pipe materials were studied by using the rotating bending fatigue testing machine. The logarithmic normal distribution model was adopted to obtain the stress-fatigue life curves corresponding to any survival rates. The direct extrapolation and 2m-1 index method were adopted to extend the fatigue curve into long-life area and the extrapolated fatigue results were compared with the up-and-down method results. The up-and-down method showed that the fatigue strengths of S135 and G105 drill pipes (survival rate was 99% and confidence level was 95%) were 550.19 MPa and 454.79 MPa respectively. The corresponding strengths of drill pipes S135 and G105 were 510.23 MPa and 402.01 MPa respectively when the fatigue life obtained by the curve with direct extrapolation survival rate of 99% was 1.0×107, while the 2m-1 method showed that when the curve of survival rate 99% obtained a fatigue life of 1.0×107, the drill pipe strengths were 532.95 MPa and 428.98 MPa respectively. The tests turned out that the fatigue strengths extrapolated by these two methods were both less than the test values. The fatigue strength value measured by the 2m-1 index method was closer to the test value by up-and-down method, so the 2m-1 index method was recommended to extrapolate the probability-stress-fatigue life curves so that a complete fatigue life curve could be obtained.
-
Keywords:
- drill pipe /
- fatigue test /
- fatigue strength /
- stress /
- fatigue life /
- extrapolation
-
-
[1] 刘志超,冯爽,姚久红,等.钻杆的失效分析和检测现状及其研究进展[J].热加工工艺,2015,44(6):8-11. Liu Zhichao,Feng Shuang,Yao Jiuhong,et al. Reaserch progress and detection current status and progress of drill pipe failure[J].Hot Working Technology,2015,44(6):8-11. [2] 刘永刚,陈绍安,李齐富,等.复杂深井钻具失效研究[J].石油矿场机械,2010,39(9):13-16. Liu Yonggang,Chen Shaoan, Li Qifu,et al. Study on failure drill string in complex deep well[J]. Oil Field Equipment,2010,39(9):13-16. [3] 万里平,孟英峰,杨龙,等.钻柱失效原因及预防措施[J]. 钻采工艺,2006,29(1):57-59. Wan Liping,Meng Yingfeng,Yang Long,et al. Failure cause and preventive measures of drill stem[J].Drilling Production Technology,2006,29(1):57-59. [4] 王文龙,赵勤,李子丰,等.普光气田气体钻井钻具失效原因分析及预防措施[J].石油钻采工艺,2008,30(5):38-43. Wang Wenlong,Zhao Qin,Li Zifeng,et al. Cause analysis and precautions of drilling tools failure during gas drilling in Puguang Gas Field[J]. Oil Drilling Production Technology,2008,30(5):38-43. [5] 林元华,罗宏志,邹波,等.钻柱失效机理及其疲劳寿命预测研究[J].石油钻采工艺,2004,26(1):19-22. Lin Yuanhua,Luo Hongzhi,Zou Bo,et al. Research on the failure mechanism and fatigue life predication of drill pipe[J].Oil Drilling Production Technology,2004,26(1):19-22. [6] 吕拴录,倪渊诠,杨成新,等. 某油田钻具失效统计分析[J]. 理化检验,2012,48(6):414-418. Lv Shuanlu,Ni Yuanquan,Yang Chengxin,et al.Statistic analysis on drilling tools failure in one oil field[J]. Physical Testing and Chenmical Analysis,2012,48(6):414-418. [7] Lv Shuanlu,Feng Yaorong,Luo Faqian,et al. Failure analysis of IEU drill pipe wash out[J]. International Journal of Fatigue,2005,27(10/11/12):1360-1365.
[8] Ziomek-Moroz M. Environmentally assisted cracking of drill pipes in deep drilling oil and natural gas wells[J]. Journal of Materials Engineering and Performance,2012,21(6):1061-1069.
[9] Kohout J,Vechet S. A new function for fatigue curves characterization and its multiple merits[J]. International Journal of Fatigue,2001,23(2):175-183.
[10] GB/T 4337—2008 金属材料 疲劳试验 旋转弯曲方法[S]. GB/T 4337—2008 Metallic materials-fatigue testing-rotating bar bending method[S]. [11] 陈传尧.疲劳与断裂[M]. 武汉:华中科技大学出版社,2001:47-54. Chen Chuanyao. Fatigue and fracture[M]. Wuhan: Huazhong University of Science Technology Press,2001:47-54. [12] 王强,赵永翔,王欢.铁路D1车轮钢的疲劳可靠性寿命与强度的试验及表征[J].机械工程学报,2014,50(14):50-55. Wang Qiang,Zhao Yongxiang,Wang Huan. Experiments and characterization on the probabilistic fatigue lives and strengths of D1 railway wheel steel[J]. Journal of Mechanical Engineering,2014,50(14):50-55. [13] 杨冰,赵永翔,邬平波,等.16MnR钢焊接头的延拓概率疲劳S-N曲线[J].交通运输工程学报,2004,4(4):25-29. Yang Bing,Zhao Yongxiang,Wu Pingbo,et al. Extrapolation of probabilistic fatigue S-N curves on 16MnR steel weld joint[J]. Journal of Traffic and Transportation Engineering,2004,4(4):25-29. -
