Optimal Design of Hydraulic Parameters for Conductor Jetting in Deepwater Drilling
-
摘要: 针对目前现有深水钻井喷射下导管水力参数设计方法没有较强理论支撑的问题,以射流和岩土力学理论为基础,推导出了导管喷射下入临界出口速度及临界排量的计算公式,并据此提出了深水钻井喷射下导管水力参数的优化设计方法,给出了设计原则和设计步骤.分析了深水钻井喷射下导管常用钻头与导管组合采用不同直径喷嘴时的临界排量,对于φ660.4 mm钻头和φ762.0 mm导管的组合,喷嘴当量直径为24.0 mm时,临界排量为69.5 L/s;喷嘴当量直径为26.0~30.0 mm时,破土直径最大为762.0 mm.在排量一定的情况下,喷嘴当量直径越小,能够破碎地层的强度也越高.对西非深水JDZ区块深水钻井喷射下导管的水力参数进行设计,选用φ14.3 mm喷嘴时,设计排量与实钻排量对比,误差不超过10%,证明该优化设计方法的设计结果合理,可用于深水钻井喷射下导管水力参数设计,指导现场施工.Abstract: Considering that there is no strong theory support to the design of hydraulic parameters in conductor jetting in deep water drilling, the calculation formulas of critical jet outlet velocity and flow rate in jetting were derived based on the water jetting theory and rock mechanics, by which an optimal design methods, criteria and procedures were presented, and investigated. The combination patterns of different bits and conductors used in jetting, showing that the critical jet flow rate was 69.5 L/s for the combination of φ660.4 mm bit and φ762.0 mm conductor, with 24.0 mm equivalent nozzle diameter, and the maximum breaking diameter was 762.0 mm when the nozzle diameter was 26.0-30.0 mm. Given constant jet flow rate, the smaller the equivalent nozzle diameter, the greater the breaking strength is. Taking the design of hydraulic parameters in deep water jetting drilling in JDZ Block, West Africa, as example, the error between designed and actual jet flow rates was less than 10% if φ14.3 mm nozzle was used. It proved that this optimal design method was reasonable and it could be effectively used in design of hydraulic parameters in deepwater conductor jetting operations.
-
-
[1] 徐荣强,陈建兵,刘正礼,等.喷射导管技术在深水钻井作业中的应用[J].石油钻探技术,2007,35(3):19-22. Xu Rongqiang,Chen Jianbing Liu Zhengli,et al.The appliation of jetting technology in deepwater drilling[J].Petroleum Drilling Techniques,2007,35(3):19-22. [2] 刘正礼,叶吉华,田瑞瑞,等.南海深水表层导管水下打桩安装 技术适应性分析[J].石油钻探技术,2014,42(1):41-45. Liu Zhengli,Ye Jihua,Tian Ruirui,et al.Adaptability of underwater tamping for deepwater drilling conductor installation in South China Sea[J].Petroleum Drilling Techniques,2014,42(1):41-45. [3] Jeanjean P.Re-assessment of p-y curves for soft clays from centrifuge testing and finite element modeling[R].OTC 20158,2009.
[4] Templeton J S.Finite element analysis of conductor seafloor interaction[R].OTC 20197,2009.
[5] Evans T G,Feyereisen S,Rheaume G.Axial capacities of jetted well conductors in Angola[R].OSIG-02-325,2002.
[6] Akers T J.Jetting of structural casing in deepwater environments:job design and operational practices[R].SPE 102378,2008.
[7] John D H,Rod A C,Robert P H,et al.Batch drilling and positioning of subsea wells in the South China Sea[R].SPE 29909,1995.
[8] Robert P H,Rod A C,John D H,et al.Liuhua 11-1 development-subsea conductor installation in the South China Sea[R].OTC 8174,1996.
[9] 刘书杰,杨进,周建良,等.深水海底浅层喷射钻进过程中钻压与钻速关系[J].石油钻采工艺,2011,33(1):12-15. Liu Shujie,Yang Jin,Zhou Jianliang,et al.Research on relationship between weight-on-bit and drilling rate during jetting drilling in sub-bottom deepwater[J].Oil Drilling Production Technology,2011,33(1):12-15. [10] 付英军,姜伟,朱荣东.深水表层导管安装方法及风险控制技术研究[J].石油天然气学报,2011,33(6):153-157. Fu Yingjun,Jiang Wei,Zhu Rongdong.Installation method and risk control technology of surface conductors[J].Journal of Oil and Gas Technology,2011,33(6):153-157. [11] 汪顺文,杨进,严德,等.深水表层导管喷射钻进机理研究[J].石油天然气学报,2012, 34(8):157-160. Wang Shunwen,Yang Jin,Yan De,et al.Research of jetting drilling mechanism of surface conductor in deepwater[J].Journal of Oil and Gas Technology,2012,34(8):157-160. [12] Luke F E,Stephen C A,Roger N W,et al.Deepwater batchset operations through the magnolia shallow water flow sand[R].SPE 92289,2005.
[13] 路保平,李国华.西非深水钻井完井关键技术[J].石油钻探技术,2013, 41(3):1-6. Lu Baoping,Li Guohua.Key technologies for deepwater drilling completion in West Africa[J].Petroleum Drilling Techniques,2013,41(3):1-6. -
