Application of Hoek-Brown Criterion for Tight Sandstone Elastic Parameters in Log Interpretation
-
摘要: 为了解决深层-频繁互层型致密砂岩、泥页岩地层弹性参数测井解释结果可靠性难以保证的问题,以致密砂岩和泥页岩试样为研究对象,分析了岩石应力-应变各阶段的特征及地层应力状态;基于Hoek-Brown准则提出了一种岩石弹性参数测井解释新方法,对该准则中GSI,a,s和mb进行了合理取值;对岩石弹性模量和泊松比进行了最终解释。研究发现,利用波速自洽确定的GSI值与岩石三轴强度具有较好的对应关系;mb和s与岩石三轴强度正相关,a与其负相关,可以利用s对mb进行定量表征(相关系数为0.884);岩石弹性模量及泊松比解释结果的平均相对误差分别为6.50%和5.55%,优于常规解释方法的平均相对误差8.44%和5.78%。研究表明,新方法不需要横波测井资料,岩石弹性模量与Hoek-Brown准则参数间具有指数相关性,岩石泊松比与弹性模量间具有线性相关性;同时,岩石纵波波速与Hoek-Brown准则的定义参数间亦具有较好的线性关系,可以利用纵波波速对弹性模量进行定量表征。Abstract: In order to solve the problem of unreliable elastic parameters in log interpretation results, and for determining the deep-frequent alternating layers of dense sandstone and shale formations, the stress-strain characteristics and formation stress status were researched with the samples of tight sandstone and muddy shale at different stages.A new approach with rock elastic parameters for logging interpretation was established based on H-B criterion, it took a reasonable value of GSI, a, s and mb, and obtained the final interpretation of brittleness by using Young’s Modulus and Poisson’s Ratio.The results showed that GSI and rock triaxial strength were good correlation, there was a positive relation of both mbb and s with rock triaxial strength, and negative relation with a and the triaxial strength.s can be used to quantitatively characterize mb(correlation coefficient R=0.884);the average error of Em and Poisson’s Ratio was 6.4 % and 5.59 % respectively, the result was better than that obtained by conventional method(8.44 % and 5.78 %).The research suggested that the new method did not need shear wave data, and that there was an index correlation of Em and H-B Citerion parameters, and a linear correlation of Poisson’s Ratio and Em.At the same time, there was also a good linear relation of longitudinal wave velocity of rock and H-B criterion parameters, Em can be quantitatively characterized by longitudinal wave velocity.
-
-
[1] 蒋祖军, 肖国益, 李群生.川西深井提高钻井速度配套技术[J].石油钻探技术, 2010, 38(4):30-34. Jiang Zujun, Xiao Guoyi, Li Qunsheng.Technology to increase deep well drilling speed in Western Sichuan[J].Petroleum Drilling Techniques, 2010, 38(4):30-34. [2] Ruiz F, Cheng A.A rock physics model for tight gas sand[J].The Leading Edge, 2010, 29(12):1484-1489.
[3] 陆黄生.测井技术在石油工程中的应用分析与发展思考[J].石油钻探技术, 2012, 40(6):1-7. Lu Huangsheng.Application and development analysis of well logging information in petroleum engineering[J].Petroleum Drilling Techniques, 2012, 40(6):1-7. [4] 曾义金.页岩气开发的地质与工程一体化技术[J].石油钻探技术, 2014, 42(1):1-6. Zeng Yijin.Integration technology of geology engineering for shale gas development[J].Petroleum Drilling Techniques, 2014, 42(1):1-6. [5] 路保平, 鲍洪志.岩石力学参数求取方法进展[J].石油钻探技术, 2005, 33(5):44-47. Lu Baoping, Bao Hongzhi.Advances in calculation methods for rock mechanics parameters[J].Petroleum Drilling Techniques, 2005, 33(5):44-47. [6] Liu Zhiguang, Chen Jianyun, Bai Weifeng, et al.Improved parameter selection method for mesoscopic numerical simulation test of direct tensile failure of rock and concrete[J].Journal of Central South University of Technology, 2010, 17(5):1079-1086.
[7] Hoek E, Marinos P G, Marinos V P.Characterisation and engineering properties of tectonically undisturbed but lithologically varied sedimentary rock masses[J].International Journal of Rock Mechanics and Mining Sciences, 2005, 42(2):277-285.
[8] 申瑞臣, 屈平, 杨恒林.煤层井壁稳定技术研究进展与发展趋势[J].石油钻探技术, 2010, 38(3):1-7. Shen Ruichen, Qu Ping, Yang Henglin.Advancement and development of coal bed wellbore stability technology[J].Petroleum Drilling Techniques, 2010, 38(3):1-7. [9] 张元中, 楚泽涵, 李铭, 等.岩石声频散的实验研究及声波速度的外推[J].地球物理学报, 2001, 44(1):103-111. Zhang Yuanzhong, Chu Zehan, Li Ming, et al.An experimental study of acoustic dispersion of rock and extrapolation of the velocity[J].Chinese Journal of Geophysics, 2001, 44(1):103-111. [10] Marinos V, Marinos P, Hoek E.The geological strength index:applications and limitations[J].Bulletin of Engineering Geology and the Environment, 2005, 64(1):55-65.
[11] 夏开宗, 陈从新, 刘秀敏, 等.基于岩体波速的 Hoek-Brown 准则预测岩体力学参数方法及工程应用[J].岩石力学与工程学报, 2013, 32(7):1458-1466. Xia Kaizong, Chen Congxin, Liu Xiumin, et al.Estimation of rock mass mechanical parameters based on ultrasonic velocity of rock mass and Hoek-Brown Criterion and its application to engineering[J].Chinese Journal of Rock Mechanics and Engineering, 2013, 32(7):1458-1466. [12] 闫长斌, 徐国元.对Hoek-Brown公式的改进及其工程应用[J].岩石力学与工程学报, 2005, 24(22):4030-4035. Yan Changbin, Xu Guoyuan.Modification of Hoek-Brown expressions and its application to engineering[J].Chinese Journal of Rock Mechanics and Engineering, 2005, 24(22):4030-4035. [13] 廖异, 曾祥国, 符文熹, 等.Hoek-Brown岩体非线性强度的线性化方法[J].中南大学学报:自然科学版, 2012, 43(12):4902-4911. Liao Yi, Zeng Xiangguo, Fu Wenxi, et al.Linearization method of non-linear strength of Hoek-Brown rock mass[J].Journal of Central South University:Science and Technology, 2012, 43(12):4902-4911. [14] Alkan H, Cinar Y, Pusch G.Rock salt dilatancy boundary from combined acoustic emission and triaxial compression tests[J].International Journal of Rock Mechanics and Mining Sciences, 2007, 44(1):108-119.
-
