Directional Drilling Reaming Technology in the Shallow Formation of Well A14H in the LD22-1 Gas Field
-
摘要: 为解决南海莺歌海盆地乐东 22-1 气田表层松软地层定向造斜扩眼钻进困难、邻井相碰及易产生新井眼等钻井工程技术难题,提出了一种先钻小尺寸领眼,再用新型三级固定翼扩眼器定向扩眼,然后下入套管的海洋表层钻井技术.结合随钻测量仪和电子陀螺测斜仪钻进乐东 22-1 气田A14H井表层时,先用φ250.8 mm钻具定向造斜、钻小领眼,再用φ254.1 mm×φ349.3 mm×φ444.5 mm新型扩眼器将领眼定向扩眼至φ444.5 mm,下入φ339.7 mm表层套管并固井.现场应用表明,该技术解决了丛式井表层防碰难题,保障了疏松地层的造斜钻进效果,防止了钻井中扩眼钻具对领眼井造斜效果的不利影响,对后续类似井的钻井具有一定的借鉴价值.Abstract: In order to solve problems that occurred when drilling shallow soft formation in the LD22-1Gas Field, in the Yinggehai Basin of the South China Sea,including problems in directional drilling,reaming,building angle, borehole collision of the adjacent wells,a new technology was developed.It involved drilling a small-sized pilot hole at first,and then using special three-stage reamer to directionally reaming it,followed by then running surface casing.Combined MWD with gyro inclinometer,a small pilot hole of φ250.8 mm was drilled with directional drilling tools in Well A14H in LD22-1 Gas Field,and then it was reamed to the φ444.5 mm by the special reamer with three-stage reaming sizes of φ254.1 mm×φ349.3 mm×φ444.5 mm,finally the φ339.7 mm casing was run in hole and cemented.Drilling practices showed that the technology successfully prevented the borehole from colliding in cluster wells in shallow formations successfully.It also ensured the effect of directional drilling and building up,and eliminated the unfavorable effect of reamer on building up in pilot hole.The study concluded that it would be an useful reference for drilling in similar shallow soft formations.
-
Keywords:
- shallow layer /
- horizontal well /
- anti-collision /
- reaming /
- Well A14H /
- LD22-1 Gas Field
-
-
[1] 赵学战,管申,郭希玺,等.崖城 13-1-A16 井表层"一开双眼"定向钻井技术[J].石油钻采工艺,2012,34(增刊1):9-11. Zhao Xuezhan,Guan Shen,Guo Xixi,et al."Twinhole drilled at first spudding" directional drilling technology of 13-1-A16 Well surface in Yacheng[J].Oil Drilling Production Technology,2012,34(supplement 1):9-11. [2] 李凡,赵少伟,张海,等.单筒双井表层预斜技术及其在绥中36-1油田的应用[J].石油钻采工艺,2012,34(增刊1):12-15. Li Fan,Zhao Shaowei,Zhang Hai,et al.Preventive oblique technology of single hole double wells surface and its application in Suizhong 36-1 Oilfield[J].Oil Drilling Production Technology,2012,34(supplement 1):12-15. [3] 魏刚,张春琳,邵明仁.小井距密集丛式定向井防碰技术[J].内蒙古石油化工,2010,36(2):99-101. Wei Gang,Zhang Chunlin,Shao Mingren.The spacing of dense cluster directional wells anti-collision technology[J].Inner Mongulia Petrochemical Industry,2010,36(2):99-101. [4] 祝效华,朱虎军,司念亭,等.扩眼器在定向造斜段的应用可行性研究[J].海洋石油,2008,28(4):96-98. Zhu Xiaohua,Zhu Hujun,Si Nianting,et al.Research on reamer’s applicability in directional kick off intervals[J].Offshore Oil,2008,28(4):96-98. [5] 张晓诚,刘亚军,王昆剑,等.海上丛式井网整体加密井眼轨迹防碰绕障技术应用[J].石油科技论坛,2010(5):13-17. Zhang Xiaocheng,Liu Yajun,Wang Kunjian,et al.Offshore cluster well network integrated encryption well trajectory anti-collision detouring technology[J].Oil Forum,2010(5):13-17. [6] 王万庆,田逢军.长庆马岭油田水平井钻井防碰绕障技术[J].石油钻采工艺,2009,31(2):35-38. Wang Wanqing,Tian Fengjun.The anti-collision and barrier-bypassing technology of horizontal well drilling in Changqing Maling Oilfield[J].Oil Drilling Production Technology,2009,31(2):35-38. [7] 刘刚,孙金,何宝生,等.定向井防碰地面监测系统设计及现场试验[J].石油钻探技术,2012,40(1):7-11. Liu Gang,Sun Jin,He Baosheng,et al.Design and field test of surface monitoring system for directional wells anti-collision[J].Petroleum Drilling Techniques,2012,40(1):7-11. [8] 饶志华,杨超,段泽辉,等.浅层多井防碰相对井间距预测模型的建立与现场验证[J].中国海上油气,2014,26(4):80-83. Rao Zhihua,Yang Chao,Duan Zehui,et al.Establishment and field verification of relative inter-well distance prediction model for anti-collision of shallow multi-wells[J].China Offshore Oil and Gas,2014,26(4):80-83. [9] 何保生,刘华亮,刘刚,等.基于球面波传播理论的钻头趋近邻井防碰预测模型[J].石油钻探技术,2013,41(3):62-66. He Baosheng,Liu Hualiang,Liu Gang,et al.Anti-collision prediction model for drill bit approaching adjacent well based on spherical wave propagation theory[J].Petroleum Drilling Techniques,2013,41(3):62-66. [10] 刘刚,孔得臣,孙金,等.套管头振动信号特征应用于油井防碰监测的可行性分析[J].中国海上油气,2012,24(3):54-57. Liu Gang,Kong Dechen,Sun Jin,et al.Feasibility analysis on application of casing head vibration signal in wellbore anti-collision monitoring[J].China Offshore Oil and Gas,2012,24(3):54-57. -
