Developing and Testing XPJQ Series Floating Friction Reducers for Running Casing
-
摘要: 为有效减小大位移井、长水平段水平井的套管下入阻力,保证套管的安全下入,研制开发了新型XPJQ系列下套管漂浮减阻器。基本的技术思路是,依据套管在下入过程中的受力大小、状态及影响因素,利用漂浮接箍或漂浮减阻器实现对水平段套管内部全掏空,以有效降低套管正压力、减小套管下入摩擦阻力。根据漂浮下套管技术及固井技术的要求,研制开发的新型下套管漂浮减阻器由1个主部件(漂浮减阻器)和4个辅助部件(可钻式防落物浮箍、高承压漂浮旋流鞋、剪销式套管清理器、防转碰压塞)组成。下套管漂浮减阻器地面试验表明,各功能都运行平稳,各项技术参数均达到设计要求。在胜利油田胜2-平17井的现场试验也表明,各部件工作正常,可实现漂浮功能。研究认为,新型XPJQ系列下套管漂浮减阻器性能可靠,可在大位移井、长水平段水平井推广应用。Abstract: In order to effectively reduce the friction which occurs when running casing in extended-reach wells,and in long sections of horizontal wells,to ensure casing is run into the planed formation,a new casing floating friction reducer was developed.It can effectively reduce the friction generated when running casing,and ensure safer operations.The concept and the procedures were based on the principle that keeps the inside of casing empty by a floating friction reducer,so as to reduce the weight of casing and friction caused by running casing.According to the casing floating technology and requirements of cementing,a main part and four auxiliary components of floating system were developed,which include the floating friction reducer and a drillable float collar used for isolating falling articles,a high pressure whirling float shoe,a shear-pin type casing cleaner and an anti-rotation bump plug.The floating friction reducer was tested at both surface and the Well Sheng 2-Ping 17,Shengli Oilfield,and it showed that each component worked properly and that floating founction was achieved.The successful development of a floating friction reducer for casing can result in successful applications in extended reach wells and in the long section of horizontal wells.
-
Keywords:
- casing /
- floating friction reducer /
- horizontal well /
- extended reach well /
- friction /
- well cementing
-
-
[1] 刘春全,史海涛,梅宇光,等.大位移井套管可下入深度预测[J].石油矿场机械,2008,37(7):53-56. Liu Chunquan,Shi Haitao,Mei Yuguang,et al.Forecast depth for casing running in extended reach well[J].Oil Field Equipment,2008,37(7):53-56. [2] Rae G,Williams H,Hamilton J.Selective flotation of casing from a floating vessel[R].SPE 88841,2004.
[3] 陈述,张文华,王雷,等.委内瑞拉浅层高水垂比三维水平井下套管工艺[J].石油钻探技术,2013,41(1):56-60. Chen Shu,Zhang Wenhua,Wang Lei,et al.Casing running technology for high horizontal-displacement to vertical-depth ratio 3D shallow layer horizontal well in Venezuela[J].Petroleum Drilling Techniques,2013,41(1):56-60. [4] 雷齐松,李振,王海红,等.快速下套管配套技术研究[J].化学工程与装备,2012(7):105-107. Lei Qisong,Li Zhen,Wang Haihong,et al.Matching technology research of casing running[J].Chemical Engineering Equipment,2012(7):105-107. [5] 李维,李黔.大位移水平井下套管漂浮接箍安放位置优化分析[J].石油钻探技术,2009,37(3):53-56. Li Wei,Li Qian.Optimization of float collar position in extended reach wells[J].Petroleum Drilling Techniques,2009,37(3):53-56. [6] 刘善祯.大位移水平井下套管受力分析及漂浮接箍设计[D].青岛:中国石油大学(华东)机电工程学院,2007. Liu Shanzhen.Casing running force analysis and float coupling design for extended reach well[D].Qingdao:China University of Petroleum(Huadong),College of Mechanical Electronic Engineering,2007. [7] 刘伟,陶谦,丁士东.页岩气水平井固井技术难点分析与对策[J].石油钻采工艺,2012,34(3):40-43. Liu Wei,Tao Qian,Ding Shidong.Difficulties and countermeasures for cementing technology of salle gas horizontal well[J].Oil Drilling Production Technology,2012,34(3):40-43. -
