Han Laiju, Niu Hongbo. Understandings on Drilling Technology for Long Horizontal Section Wells[J]. Petroleum Drilling Techniques, 2014, 42(2): 7-11. DOI: 10.3969/j.issn.1001-0890.2014.02.002
Citation: Han Laiju, Niu Hongbo. Understandings on Drilling Technology for Long Horizontal Section Wells[J]. Petroleum Drilling Techniques, 2014, 42(2): 7-11. DOI: 10.3969/j.issn.1001-0890.2014.02.002
shu

Understandings on Drilling Technology for Long Horizontal Section Wells

  • 1.

    Sinopec Shengli Oilfield Service Corporation, Dongying, Shandong, 257000, China;

  • 2.

    Drilling Technology Research Institute, Sinopec Shengli Oilfield Service Corporation, Dongying, Shandong, 257017, China

More Information
  • Received Date: September 11, 2013
  • Revised Date: February 16, 2014
    Graphical Abstract
    • Abstract
  • In order to further clarify the differences among long horizontal section wells,extended reach wells and conventional horizontal wells,and explore drilling technologies and relative developing strategy for long horizontal section wells,the technical characteristics of these kinds of wells were analyzed.The analysis and comparison shows the main differences among the three kinds of wells are as follows:the problem of drag and torque in long horizontal section wells is not serious in conventional horizontal wells;long horizontal section wells feature a long horizontal section,which is beyond the range of extended reach well in many cases;the relative technologies have been focused on the drilling ability for the long horizontal section with deviation of more than 86°,it is different from the drilling and completion capability in extended reach wells that aimed at getting a long displacement.Based on the findings above,preliminary definition of long horizontal section wells was presented,and some specific suggestions on basic drilling design theory,drilling technology for improving ROP of long horizontal section and economic drilling model have been proposed.
    • FullText(HTML)
    • References (16)
  • [1]
    郭元恒,何世明,刘忠飞,等.长水平段水平井钻井技术难点分析及对策[J].石油钻采工艺,2013,35(1):14-18. Guo Yuanheng,He Shiming,Liu Zhongfei,et al.Difficulties and countermeasures for drilling long lateral-section horizontal wells[J].Oil Drilling Production Technology,2013,35(1):14-18.
    [2]
    何龙,李文生,刘伟.川西地区长水平段水平井钻井技术[J].钻采工艺,2013,36(5):114-116. He Long,Li Wensheng,Liu Wei.Drilling technology for long horizontal section wells in Western Sichuan[J].Drilling Production Technology,2013,36(5):114-116.
    [3]
    赵恒,罗勇,赵金丰,等.苏里格气田长水平段水平井快速钻井技术[J].钻采工艺,2012,35(6):108-109. Zhao Heng,Luo Yong,Zhao Jinfeng,et al.Fast drilling technology or long horizontal section wells in Sulige Gas Field[J].Drilling Production Technology,2012,35(6):108-109.
    [4]
    陈作,何青,王宝峰,等.大牛地气田长水平段水平井分段压裂优化设计技术[J].石油钻探技术,2013,41(6):82-85. Chen Zuo,He Qing,Wang Baofeng,et al.Design optimization of staged fracturing for long lateral well in Daniudi Gas Field[J].Petroleum Drilling Techniques,2013,41(6):82-85.
    [5]
    韩来聚,牛洪波,窦玉玲.胜利低渗油田长水平段水平井钻井关键技术[J].石油钻探技术,2012,40(3):7-11. Han Laiju,Niu Hongbo,Dou Yuling.Key drilling technologies for long displacement horizontal wells of low permeability reservoirs in Shengli Oilfield[J].Petroleum Drilling Techniques,2012,40(3):7-11.
    [6]
    赵金洲,韩来聚,唐志军.高平1井大位移水平井钻井设计与施工[J].石油钻探技术,2010,38(6):29-32. Zhao Jinzhou,Han Laiju,Tang Zhijun.Design and drilling of Gaoping 1 ERD horizontal well[J].Petroleum Drilling Techniques,2010,38(6):29-32.
    [7]
    冯光通,马凤清,曹向峰,等.高平1井井眼轨道与井身结构设计[J].石油钻探技术,2010,38(6):33-36. Feng Guangtong,Ma Fengqing,Cao Xiangfeng,et al.The trajectory and casing program design of Well Gaoping 1[J].Petroleum Drilling Techniques,2010,38(6):33-36.
    [8]
    牛洪波.大牛地气田长水平段井眼轨迹控制方法[J].天然气工业,2011,31(10):64-67. Niu Hongbo.Trajectory control methods for long sections of horizontal wells at the Daniudi Gas Field[J].Natural Gas Industry,2011,31(10):64-67.
    [9]
    GB/T 28911—2012 石油天然气钻井工程术语[S]. GB/T 28911—2012 Vocabulary of drilling engineering for petroleum and natural gas[S].
    [10]
    李克向,周煜辉,苏义脑,等.国外大位移井钻井技术[M].北京:石油工业出版社,1998:1-2. Li Kexiang,Zhou Yuhui,Su Yinao,et al.Foreign extended well drilling technology[M].Beijing:Petroleum Industry Press,1998:1-2.
    [11]
    苏义脑,窦修荣.大位移井钻井概况、工艺难点和对工具仪器的要求[J].石油钻采工艺,2003,25(1):6-10. Su Yinao,Dou Xiurong.General condition and technical difficulties of extended reach drilling and its requirements on tools and instrument[J].Oil Drilling Production Technology,2003,25(1):6-10.
    [12]
    周延军,曾强渗, 窦玉玲,等.金平1浅层大位移水平井钻井工程设计技术及应用[J].钻采工艺,2008,31(增刊1): 24-27. Zhou Yanjun,Zeng Qiangshen,Dou Yuling,et al.Drilling design and application for shallow extended reach horizontal well in Jinping Well 1[J].Drilling Production Technology,2008,31(supplement 1):24-27.
    [13]
    李淑森,王霞,高含.苏里格气田水平井钻井提速技术分析与对策[J].钻采工艺,2012,35(5):115-117. Li Shusen,Wang Xia,Gao Han.Technical difficulties and measures of improving ROP of horizontal wells in Sulige Gas Field[J].Drilling Production Technology,2012,35(5): 115-117.
    [14]
    谯抗逆,郭世侯,吴凯彬,等.长水平段地质导向技术在磨030-H24井中的应用[J].钻采工艺,2012,35(2):94-96. Qiao Kangni,Guo Shihou,Wu Kaibin,et al.Application of geosteering drilling technology in the long horizontal section of Well Mo 030-H24[J].Drilling Production Technology,2012,35(2):94-96.
    [15]
    韩来聚,周延军,唐志军.胜利油田非常规油气优快钻井技术[J].石油钻采工艺,2012,34(3):11-15. Han Laiju,Zhou Yanjun,Tang Zhijun.High quality and fast drilling techniques for unconventional oil and gas reservoirs in Shengli Oilfield[J].Oil Drilling Production Technology,2012,34(3):11-15.
    [16]
    Colin Gillan,Scott Boone,Greg Kostiuk[R].Applying precision drill pipe rotation and oscillation to slide drilling problems.SPE 118656,2009.
