SHU Xiaobo, MENG Yingfeng, LI Gao. Bionic Technique-Based Treatment Fluid for Wellbore Stability in Drilling through Shale Formations[J]. Petroleum Drilling Techniques, 2017, 45(3): 15-20. DOI: 10.11911/syztjs.201703003
Citation: SHU Xiaobo, MENG Yingfeng, LI Gao. Bionic Technique-Based Treatment Fluid for Wellbore Stability in Drilling through Shale Formations[J]. Petroleum Drilling Techniques, 2017, 45(3): 15-20. DOI: 10.11911/syztjs.201703003
shu

Bionic Technique-Based Treatment Fluid for Wellbore Stability in Drilling through Shale Formations

  • 1.

    Oil & Gas Field Applied Chemistry Key Laboratory of Sichuan Province, Guanghan, Sichuan, 618300, China;

  • 2.

    CCDC Drilling & Production Engineering Technology Research Institute, Guanghan, Sichuan, 618300, China;

  • 3.

    State Key Laboratory of Oil & Gas Reservoir Geology and Exploitation(Southwest Petroleum University), Chengdu, Sichuan, 610500, China

More Information
  • Received Date: November 29, 2016
  • Revised Date: March 06, 2017
    Graphical Abstract
    • Abstract
  • Using bionic treatment fluid while drilling through shale formations was developed by optimization of bionic treatment agents based on the "lotus effect" of plant leaves. The goal was to solve wellbore instability issues due to water production while drilling through shale gas formations. Experimental tests were used to evaluate the performance of such bionic treatment fluid. The tests results showed that the bionic treatment fluid could effectively reduce surface energy of shales and form bump structures at a micro or nano scale in the same way that those on lotus or taro leaves convert the shale surface from hydrophilic to hydrophobic (the contact angle of fresh water is larger than 120°) which prevents shales from absorbing water and to enhance shale strength while in water solution. In addition,hydrophobic surfaces generated by the bionic treatment fluid have certain abrasion resistance and thermal stability,and are not affected by the salinity of formation water. The bionic treatment fluid is applicable to neutral or alkaline formations with temperatures under 80 ℃. In summary,it is an effective measure for solving wellbore instability issues in drilling through shale gas formations because,based on the bionic theory,it is possible to prevent clay hydration through water adsorption.
    • FullText(HTML)
    • References (15)
  • [1]
    魏武,邓虎,李皋,等.气体钻井井壁稳定处理剂评价方法探讨[J].天然气工业,2010,30(9):51-54. WEI Wu,DENG Hu,LI Gao,et al.A discussion on the evaluation methods of the additives for wellbore stability in gas drilling[J].Natural Gas Industry,2010,30(9):51-54.
    [2]
    陈烨,闫铁,孙晓峰,等.气体钻井地层出水量与钻具黏卡风险预测模型[J].断块油气田,2015,22(6):807-811. CHEN Ye,YAN Tie,SUN Xiaofeng,et al.Formation water production and risk prediction model of stuck pipe during gas drilling[J].Fault-Block Oil Gas Field,2015,22(6):807-811.
    [3]
    卓云,胡显智,郑霞,等.气体钻井遇地层出水时的充气钻井技术[J].天然气工业,2011,31(8):73-75. ZHUO Yun,HU Xianzhi,ZHENG Xia,et al.Aerated drilling used during gas drilling when encountering the formation water invasion[J].Natural Gas Industry,2011,31(8):73-75.
    [4]
    侯珊珊,罗春芝,张炳杰,等.泥页岩抑制剂LFW-1的室内研究[J].断块油气田,2015,22(6):833-836. HOU Shanshan,LUO Chunzhi,ZHANG Bingjie,et al.Laboratory study on LFW-1 shale inhibitor[J].Fault-Block Oil Gas Field,2015,22(6):833-836.
    [5]
    丁乙,梁利喜,刘向君,等.温度和化学耦合作用对泥页岩地层井壁稳定性的影响[J].断块油气田,2016,23(5):663-667. DING Yi,LIANG Lixi,LIU Xiangjun,et al.Influence of temperature and chemical on wellbore stability in clay shale formation[J].Fault-Block Oil Gas Field,2016,23(5):663-667.
    [6]
    周玉良,孟英峰,李皋,等.气体钻井条件下泥页岩自发吸水规律研究[J].石油钻探技术,2009,37(6):31-34. ZHOU Yuliang,MENG Yingfeng,LI Gao,et al.A study on shale spontaneous water imbibition in gas drilling wells[J].Petroleum Drilling Techniques,2009,37(6):31-34.
    [7]
    刘厚彬,孟英峰,李皋,等.泥页岩水化作用对岩石强度的影响[J].钻采工艺,2010,33(6):18-20. LIU Houbin,MENG Yingfeng,LI Gao,et al.Theoretical simulation and experimental evaluation of the effect of hydration on the shale rock strength[J].Drilling Production Technology,2010,33(6):18-20.
    [8]
    SMITH F W.Advancements in air drilling during 1958[R].API-59-244,1959.
    [9]
    冯光通,胥豪,唐波,等.超吸水材料在气体钻井井眼干燥中的应用探讨[J].石油钻探技术,2014,42(3):38-44. FENG Guangtong,XU Hao,TANG Bo,et al.Discussion on the application of super-absorbent polymer in gas drilling to dry wellbore[J].Petroleum Drilling Techniques,2014,42(3):38-44.
    [10]
    孙久荣,戴振东.仿生学的现状和未来[J].生物物理学报,2007,23(2):109-115. SUN Jiurong,DAI Zhendong.Bionics today and tomorrow[J].Acta Biophysica Sinica,2007,23(2):109-115.
    [11]
    姜立萍,黄磊.荷叶效应功能在防污涂料中的应用[J].材料保护,2013,46(2):44-47. JIANG Liping,HUANG Lei.Application of self-cleaning effect of lotus leaf in development of antifouling paints[J].Materials Protection,2013,46(2):44-47.
    [12]
    BHUSHAN B,JUNG Y C,NOSONOVSKY M.Springer handbook of nanotechnology[M].Berlin/Heidelberg:Springer,2010:1437-1524.
    [13]
    黄志宇,张太亮,鲁红升.表面及胶体化学[M].北京:石油工业出版社,2012:19-28. HUANG Zhiyu,ZHANG Tailiang,LU Hongsheng.Surface and colloid chemistry[M].Beijing:Petroleum Industry Press,2012:19-28.
    [14]
    袁志庆.超疏水表面的仿生构建[D].长沙:中南大学,2008. YUAN Zhiqing.Bionic fabrication of superhydrophobic surfaces[D].Changsha:Central South University,2008.
    [15]
    CASSIE A B D,BAXTER S.Wettability of porous surfaces[J].Transactions of the Faraday Society,1944,40:546-551.
