Mechanical Model for Setting the Liner Hanger with Embedded Slips

Han Feng; Gu Lei; Cui Xiaojie; Li Fuping; Ruan Chenliang; Feng Bin

doi:10.11911/syztjs.201506019

Volume 43 Issue 6

Nov. 2015

Turn off MathJax

Article Contents

Abstract

References

Petroleum Drilling Techniques > 2015 > 43(6): 103-107. > DOI: 10.11911/syztjs.201506019

Han Feng, Gu Lei, Cui Xiaojie, Li Fuping, Ruan Chenliang, Feng Bin. Mechanical Model for Setting the Liner Hanger with Embedded Slips[J]. Petroleum Drilling Techniques, 2015, 43(6): 103-107. DOI: 10.11911/syztjs.201506019

Citation:

PDF (1269 KB)

Mechanical Model for Setting the Liner Hanger with Embedded Slips

1.
Sinopec Research Institute of Petroleum Engineering, Beijing, 100101, China;
2.
CNOOC EnerTech-Drilling & Production Co., Tianjin, 300452, China

More Information

Received Date: June 03, 2015
Revised Date: November 08, 2015

Graphical Abstract

Abstract

Abstract

Liner hangers with embedded slips are structurally complex, and the slip clamping force is the key factor for successful setting the liner hangers. Based on the structures and manufacturing process of embedded slip setting systems, a mechanic model of setting system for embedded slip liner hangers was built by using matrix theories, the theoretical calculation methods were worked out for clamping force of slips, the relationship among the slip clamping force, liner weights, cutter rotation angle and friction coefficient on contact surface were analyzed. Setting tests were performed for the embedded slip liner hanger and casing, outside strain of casing was collected and analyzed with different axial loads by means of strain testing systems, the contact stress between the casing inner wall and the slip was calculated by using Lame’s Equation. Research results showed that the calculated value of contact strain between the slip and casing coincided with measured mean value. Maximum and minimum stresses are 150% and 75% of the average value respectively. The analysis and test results of setting the mechanical models can provide an important basis for structural design and the optimization of liner hangers.
- liner hanger,
- slip,
- casing,
- stress,
- strain
