Effect of Choke Valve Action on Annular Pressure with Micro-Flux Control in MPD Drilling
-
摘要: 为解决窄安全密度窗口的复杂压力剖面问题，基于质量守恒方程及动量守恒方程，建立了节流阀动作引发的环空波动压力模型，并应用中心差分法对模型进行了求解。研究表明，随钻井液排量增大、节流阀动作时间减小，环空所受波动压力呈增大趋势；阀芯所受波动压力大于环空段；钻井液排量从36 L/s增至56 L/s时，阀芯所受波动压力峰值从1.26 MPa增至1.56 MPa，钻铤段波动压力峰值为0.22 MPa；节流阀动作时，套管鞋处引发故障的概率比井底高至35%。研究结果表明，两步、多步线性关阀较一步关阀，不但关阀手段灵活，更可有效减小环空波动压力峰值。Abstract: To address effectively the complex pressure profile with narrow density window,the effects of choke valve action on fluctuation pressure in annulus have been studied during drilling operations.Based on the mass and momentum conservation equations,the model was established to simulate fluctuation pressure in annulus caused by choke valve action,and calculated by central difference method.In the calculation example,the fluctuation pressure in annular space will be higher with the increases of flow rate and the shorter time of choke valve action.The fluctuation pressure in the valve core is higher than that in the annulus,and the maximum fluctuation pressure increased from 1.26 MPa to 1.56 MPa with the flow rate of drilling fluids increased from 0.036 m3/s to 0.056 m3/s.The maximum fluctuation pressure is 0.22 MPa in drill collar section.When adjusting choke valve,the trouble probability at the casing shoe is 35% greater than that at the bottomhole.The research results indicate that the two-step or multi-step valve closing linearly is more flexible than the one-step valve closing,and can effectively lower the peak fluctuation pressure in annular space.
-
-
[1] 于继飞, 李丽, 何保生, 等.海上自喷油井关井井口压力预测方法[J].石油钻探技术, 2012, 40(1):83-86. Yu Jifei, Li Li, He Baosheng, et al.Wellhead pressure prediction method during well shut-in for offshore flowing oil wells[J].Petroleum Drilling Techniques, 2012, 40(1):83-86. [2] 李宗清, 燕修良, 陈永明, 等.三参数自动控压钻井系统的研制与试验[J].石油钻探技术, 2012, 40(6):99-103. Li Zongqing, Yan Xiuliang, Chen Yongming, et al.Development and test of three-parameter automatic pressure control drilling system[J].Petroleum Drilling Techniques, 2012, 40(6):99-103. [3] 金业权, 孙泽秋, 刘刚.控压钻井液动节流压力控制系统仿真分析与试验研究[J].石油钻探技术, 2013, 41(2):109-113. Jin Yequan, Sun Zeqiu, Liu Gang.Simulation analysis and experimental study of managed pressure drilling hydraulic throttle pressure control system[J].Petroleum Drilling Techniques, 2013, 41(2):109-113. [4] Santos H, Leuchtenberg C, Shayegi S.Micro-flux control:the next generation in drilling process[R].SPE 81183, 2003.
[5] Santos H, Reid P, Leuchtenberg C, et al.Micro-flux control method combined with surface BOP creates enabling opportunity for deepwater and offshore drilling[R].OTC 17451, 2005.
[6] Santos H M, Catak E, Kinder J I, et al.First field applications of microflux control show very positive surprises[R].SPE 108333, 2007.
[7] 苏勤, 赵向阳.一种精细控压钻井流动模型的研究与应用[J].石油钻探技术, 2013, 41(1):8-13. Su Qin, Zhao Xiangyang.The research and application of a fine MPD flow model[J].Petroleum Drilling Techniques, 2013, 41(1):8-13. [8] Kong Xiangwei, Lin Yuanhua, Qiu Yijie, et al.A new model for predicting dynamic surge pressure in gas and drilling mud two-phase flow during tripping operations[J].Mathematical Problems in Engineering, 2014, Artical ID916798:1-16.
[9] 李相方, 郑权方.硬关井水击压力计算及其应用[J].石油钻探技术, 1995, 23(2):1-4. Li Xiangfang, Zheng Quanfang.Calculation and application of surge pressure for hard closing[J].Petroleum Drilling Techniques, 1995, 23(2):1-4. [10] 张涛, 柳贡慧, 李军, 等.精细控压多级并联节流管汇系统研究[J].石油钻探技术, 2012, 40(2):98-103. Zhang Tao, Liu Gonghui, Li Jun, et al.Research on multi-level parallel choke manifold system[J].Petroleum Drilling Techniques, 2012, 40(2):98-103. [11] Xuan Lijun, Mao Feng, Wu Jiezhi.Water hammer prediction and control:the Green’s function method[J].Acta Mechanica Sinica, 2012, 28(2):266-273.
[12] Zhang Yongliang, Miao Mingfei, Ma Jiming.Analytical study on water hammer pressure in pressurized conduits with a throttled surge chamber for slow closure[J].Water Science and Engineering, 2010, 3(2):174-189.
[13] Weyler M E, Streeter V L, Larsen P S.An investigation of the effect of cavitation bubbles on the momentum loss in transient pipe flow[J].Journal of Fluids Engineering, 1971, 93(1):1-7.
[14] Freddy Crespo, Ramadan Ahmed.A simplified surge and swab pressure model for yield power law fluids[J].Journal of Petroleum Science and Engineering, 2013, 101:12-20.
[15] Lin Yuanhua, Kong Xiangwei, Qiu Yijie, et al.Calculation analysis of pressure wave velocity in gas and drilling mud two-phase fluid in annulus during drilling operations[J].Mathematical Problems in Engineering, 2013, Article ID318912:1-17.
-
