深水钻井防喷器温度场数值模拟研究

赵欣欣, 吴雪峰, 高永海, 李昊, 郭艳利

赵欣欣, 吴雪峰, 高永海, 李昊, 郭艳利. 深水钻井防喷器温度场数值模拟研究[J]. 石油钻探技术, 2013, 41(3): 46-50. DOI: 10.3969/j.issn.1001-0890.2013.03.009
引用本文: 赵欣欣, 吴雪峰, 高永海, 李昊, 郭艳利. 深水钻井防喷器温度场数值模拟研究[J]. 石油钻探技术, 2013, 41(3): 46-50. DOI: 10.3969/j.issn.1001-0890.2013.03.009
Zhao Xinxin, Wu Xuefeng, Gao Yonghai, Li Hao, Guo Yanli. Numerical Simulation of Temperature Distribution of Blowout Preventers in Deepwater Drilling[J]. Petroleum Drilling Techniques, 2013, 41(3): 46-50. DOI: 10.3969/j.issn.1001-0890.2013.03.009
Citation: Zhao Xinxin, Wu Xuefeng, Gao Yonghai, Li Hao, Guo Yanli. Numerical Simulation of Temperature Distribution of Blowout Preventers in Deepwater Drilling[J]. Petroleum Drilling Techniques, 2013, 41(3): 46-50. DOI: 10.3969/j.issn.1001-0890.2013.03.009

深水钻井防喷器温度场数值模拟研究

基金项目:

国家自然科学"深水钻井中的气液两相流传热规律研究"(编号:51004113)、国家科技重大专项子课题"深水钻井水力学及井控关键技术研究"(编号:2011ZX05026-001-02)、教育部"长江学者和创新团队发展计划"项目"海洋油气井钻完井理论与工程"(编号:IRT1086)和中央高校基本科研业务费专项资金资助项目(编号:13CX05006A)资助。

详细信息
    作者简介:

    赵欣欣(1977—),女,河北涿州人,2000年毕业于山东工程学院机械电子工程专业,2003获石油大学(华东)油气井工程专业硕士学位,讲师,现从事油气井流体力学和传热方面的教学与研究工作。

  • 中图分类号: TE52;TE921+.5

Numerical Simulation of Temperature Distribution of Blowout Preventers in Deepwater Drilling

  • 摘要: 深水防喷器所处环境为低温高压,如有气侵出现,容易在防喷器位置生成天然气水合物,阻塞防喷器,产生井口安全隐患。为此,结合深水钻井工况,建立了深水钻井条件下闸板防喷器与环形防喷器的三维空间模型,并利用Fluent软件进行了温度场数值模拟,得到了防喷器不同位置的温度场分布。在此基础上,结合天然气水合物生成条件分析了防喷器的温度场分布,以及加热管对防喷器温度场的影响规律,并优选了加热管的布置位置。结果表明,在模拟环境条件下,闸板防喷器横向位置依靠防喷器通径内壁加热即可满足天然气水合物预防要求,在纵向侧面1/4处布置加热管效果较好;管线数量对环形防喷器温度场的影响很大,为满足温度高于天然气水合物形成温度的要求,可以将优化加热管数量与保温措施结合起来进行。
    Abstract: In case of gas cutting,hydrate is likely to form in deep water blowout preventers due to low temperature and high pressure and block the blowout preventers,which might compose safety threat at wellhead.Combining deepwater drilling conditions,3D models of ram preventers and annular blowout preventers in deepwater drilling condition were built-up,and numerical simulation of temperature field was performed to obtain the temperature distribution across the preventer.Then optimal heating locations of pipes were chosen according to the effect of heating pipe on blowout preventer temperature field.Result showed in the simulated temperature that heating by annulus itself in the transverse direction of the ram BOP,and heating pipe around 1/4 part of the longitudinal section could meet the requirements of preventing gas hydrate formation.Quantity of heating pipes has large influence on the temperature field of annular BOP.Optimization of pipe quantity and insulation combination should be considered to keep the temperature at annular BOP over hydrate formation temperature.
  • [1]

    Shing-Ming Chen.Un-planned shut-in and deepwater gas hydrate prevention.OTC 20436,2010.

    [2] 苏堪华,管志川,苏义脑.深水钻井水下井口力学稳定性分析[J].石油钻采工艺,2008,30(6):1-4,15. Su Kanhua,Guan Zhichuan,Su Yinao.Mechanical stability analysis of subsea wellhead for deepwater drilling[J].Oil Drilling Production Technology,2008,30(6):1-4,15.
    [3] 王定亚,邓平,刘文霄.海洋水下井口和采油装备技术现状及发展方向[J].石油机械,2011,39(1):75-79. Wang Dingya,Deng Ping,Liu Wenxiao.Technology and trend of subsea wellhead and production equipment[J].China Petroleum Machinery,2011,39(1):75-79.
    [4]

    Lin C R, Bunch P D,Li Yousun,et al.Thermal analysis of subsea blowout preventer.OTC 6999,1992.

    [5] 许亮斌,张红生,周建良,等.深水钻井防喷器选配关键因素分析[J].石油机械,2012,40(6):49-53. Xu Liangbin,Zhang Hongsheng,Zhou Jianliang,et al.Analysis of the key factors for configuring deepwater drilling BOP[J].China Petroleum Machinery,2012,40(6):49-53.
    [6] 曹式敬.超深水防喷器组及其控制系统配置探讨[J].石油钻探技术,2012,40(5):115-118. Cao Shijing.Discussion on configuration of subsea BOP stack and its control system in ultra-deep water[J].Petroleum Drilling Techniques,2012,40(5),115-118.
    [7] 谢新设,秦疆,张宝彦,等.FZ35-105 防喷器的研制与应用[J].石油钻探技术,2009,37(4):65-67. Xie Xinshe,Qin Jiang,Zhang Baoyan,et al.Study and application of FZ35-105 blow out preventer[J].Petroleum Drilling Techniques,2009,37(4):65-67.
    [8] 高永海,孙宝江,王志远,等.深水钻探井筒温度场的计算与分析[J].中国石油大学学报:自然科学版,2008,32(2):58-62. Gao Yonghai,Sun Baojiang,Wang Zhiyuan,et al.Calculation and analysis of wellbore temperature field in deepwater drilling[J].Journal of China University of Petroleum:Edition of Natural Science,2008,32(2):58-62.
    [9] 唐晓东,陈广明,王治红,等.注空气开采海上稠油井筒传热模型研究[J].特种油气藏,2009,16(1):87-91. Tang Xiaodong,Chen Guangming,Wang Zhihong,et al.Wellbore heat transfer model of recovering offshore heavy oil by air injection[J].Special Oil and Gas Reservoirs,2009,16(1):87-91.
    [10] 任韶然,刘建新,刘义兴,等.多孔介质中甲烷水合物形成与分解实验研究[J].石油学报,2009,30(4):583-587. Ren Shaoran,Liu Jianxin,Liu Yixing,et al.Experimental study on formation and dissociation of methane hydrate in porous media[J].Acta Petrolei Sinica,2009,30(4):583-587.
