Failure Analysis of API Tubing Round Threaded Connection Induced by Flow Field
-
摘要: 油管柱失效的主要形式是油管螺纹连接失效。目前对油管螺纹连接失效的研究主要集中在载荷作用下的螺纹受力和变形分析,对螺纹连接处流场突变导致失效的研究较少。利用流体动力学计算方法,对API圆螺纹油管接箍流场内部的流体建立控制方程,采用FLUENT软件进行流场模拟,对接箍连接的"J"形区的压力、速度分布情况进行了分析,并提出了改进措施,对流道进行优化。"J"形区的流场模拟计算发现,流体因高速流动产生涡流和压力突变,进一步影响流体性质并冲击接箍内壁。API油管接箍结构优化后,避免了压力和速度的突变,有利于流体流通,为油管的优化设计提供了理论依据。Abstract: The thread connections invalid of API tubing is the main form of tubing string failure according to the statistics from oilfields.Study on thread connection failure has been mainly focused on the force and deformation analysis under loads,few have been related to the flow field mutations of threaded connections.Therefore,it is necessary to study the failure mechanism by flow field mutations.In this paper,based on the computation fluid dynamics,governing equations of flowing fluid in thread connection have been built.Then,flow characteristics(distribution of pressure and velocity)in the connection of API round thread tube were simulated by FLUENT.Finally,technical measures that can improve the flow mutations have been proposed.According to the simulation and calculation of flow field in the "J"-shaped area,it was concluded that vortex and pressure mutation induced by high-speed flow would affect the fluid properties,leading the fluid to attack the inner wall of the connection.The newly designed API round thread could avoid the mutation of pressure and velocity,which was favorable for fluid flow,providing theoretical basis for the optimization design of tube.
-
Keywords:
- tubing connection /
- failure analysis /
- flow induced /
- structure design
-
-
[1] Schwind B.Mobile qualifies three tubing/casing connection product lines[J].Hart’s Petroleum Engineer International,1998,71(11):59-62.
[2] 刘绘新,苏永平.川东气田油管腐蚀现象的基本特征[J].天然气工业,2008,20(5):388-390. Liu Huixin,Su Yongping.Essential features of tubing corrosion phenomena in Chuandong Gas Field[J].Natural Gas Industry,2008,20(5):388-390. [3] 杨海滨,狄勤丰,王文昌.抽油杆柱与油管偏磨机理及偏磨点位置预测[J].石油学报,2005,26(2):100-103. Yang Haibin,Di Qinfeng,Wang Wenchang.Prediction of serious abrasion position and mechanism of uneven abrasion between sucker rod string and tubing[J].Acta Petrolei Sinica,2005,26(2):100-103. [4] Zhu Hongjun,Lin Yuanhua,Zeng Dezhi.Flow induced corrosion of API round thread connection.SPE 132053,2010.
[5] Jordau K G.Erosion in multiphase production of oil gas.NACE 98058,1998.
[6] 张智,施太和,周理志,等.油气田开发过程中的流场诱导腐蚀[J].石油钻探技术,2005,35(3):79-81. Zhang Zhi,Shi Taihe,Zhou Lizhi,et al.Flow induced corrosion during reservoir development[J].Petroleum Drilling Techniques,2005,35(3):79-81. [7] 陈义良.湍流计算模型[M].合肥:中国科学技术大学出版社,1991:8-20. Chen Yiliang.Turbulent model[M].Hefei:University of Science and Technology of China Press,1991:8-20. [8] 朱红钧,林元华,谢龙汉.FLUENT流体分析及仿真实用教程[M].北京:人民邮电出版社,2010:106-111. Zhu Hongjun,Lin Yuanhua,Xie Longhan.FLUENT analysis and simulation tutorial[M].Beijing:Posts and Telecom Press,2010:106-111. -
