基于岩心分析的页岩气压裂工艺参数优选

陈勉, 金衍

陈勉, 金衍. 基于岩心分析的页岩气压裂工艺参数优选[J]. 石油钻探技术, 2012, 40(4): 7-12. DOI: 10.3969/j.issn.1001-0890.2012.04.002
引用本文: 陈勉, 金衍. 基于岩心分析的页岩气压裂工艺参数优选[J]. 石油钻探技术, 2012, 40(4): 7-12. DOI: 10.3969/j.issn.1001-0890.2012.04.002
Chen Mian, Jin Yan. Shale Gas Fracturing Technology Parameters Optimization Based on Core Analysis[J]. Petroleum Drilling Techniques, 2012, 40(4): 7-12. DOI: 10.3969/j.issn.1001-0890.2012.04.002
Citation: Chen Mian, Jin Yan. Shale Gas Fracturing Technology Parameters Optimization Based on Core Analysis[J]. Petroleum Drilling Techniques, 2012, 40(4): 7-12. DOI: 10.3969/j.issn.1001-0890.2012.04.002

基于岩心分析的页岩气压裂工艺参数优选

基金项目:

国家自然科学"超低渗透页岩多井多裂缝同步压裂机理研究"(编号:51074171)、国家科技重大专项"复杂结构井优化设计与控制关键"(编号:2011ZX05009-005)资助。

详细信息
    作者简介:

    陈勉(1962—),男,辽宁沈阳人,1982年毕业于北京大学力学系,1991年获中国矿业大学矿山工程力学博士学位,教授,博士生导师,主要从事石油工程岩石力学与页岩气钻、完井过程中的岩石力学问题研究。联系方式(010)89732209,chenmian@vip.163.com。

  • 中图分类号: TE357.1+1

Shale Gas Fracturing Technology Parameters Optimization Based on Core Analysis

  • 摘要: 页岩气藏的特异性显著。新的页岩气井压裂改造前要进行室内实验,根据实验结果了解气藏特征,提高开发策略的针对性。采用室内实验和理论分析相结合的方法,对中国和北美主要页岩气储层进行了矿物组成、力学参数、微观成像研究,推导出了适用于页岩压裂的闭合压力和缝宽计算方法,计算了埋藏条件下的页岩脆性指数、闭合压力和缝宽,提出了压裂液体系、黏度、排量和支撑剂类型的优选原则,利用黑色页岩进行了室内模拟压裂。结果表明,岩心分析技术能够为压裂工艺参数优选提供必要支撑,龙马溪组页岩的力学特性与Haynesville页岩较为相似,低黏度、大排量压裂时产生的裂缝网络更加复杂。实例计算表明,根据室内分析方法计算的压裂工艺参数具有较强的实用性,能够提高压裂的效果。
    Abstract: Specificities of shale gas reservoirs are usually practically common.It’s important to conduct a systematic laboratory experiment before the fracturing treatment of a new shale gas well to enhance the pertinency of development strategy.A combination method of laboratory experiment and theoretical analysis was used.Mineral composition,mechanical parameters and micro-imaging results for shale gas reservoirs in North America and South China were presented.Calculation methods of closure pressure and fracture width for shale fracturing were derived and the brittleness index,closure pressure and ideal fracture width were calculated for a real well case.Optimization principles of fracture fluid system,viscosity,pump rate and proppant type were introduced and indoor simulating fracture was conducted on black shale samples.The result shows that core analysis technology can provide necessary support for the optimization of fracturing parameter and the mechanical properties of Longmaxi shale are much more similar to that of Haynesville shale.It tends to generate more complex fracture networks with low-viscosity fluid and high pump rate.Case calculation results show that hydraulic fracture parameters selected from core analysis results have a practical advantage and can improve the fracturing effect.
  • [1] 李庆辉,陈勉,Fred P W,等.工程因素对页岩气产量的影响:以北美Haynesville页岩气藏为例[J].天然气工业,2012,32(4):54-59. Li Qinghui,Chen Mian,Fred P W,et al.Influences of engineering factors on shale gas productivity: a case study from the Haynesville shale gas reservoir in North America[J].Natural Gas Industry,2012,32(4):54-59.
    [2]

    Mark D Zoback.Reservoir geomechanics[M].New York:Cambridge University Press,2007:206-211.

    [3] 陈勉,金衍,张广清.石油工程岩石力学[M].北京:科学出版社,2008:11-13. Chen Mian,Jin Yan,Zhang Guangqing.Petroleum engineering related rock mechanics[M].Beijing:Science Press,2008:11-13.
    [4] 付永强,马发明,曾立新,等.页岩气储层压裂实验评价关键技术[J].天然气工业,2011,31(4):51-54. Fu Yongqiang,Ma Faming,Zeng Lixin,et al.Key techniques of experimental evaluation in the fracturing treatment for shale gas reservoirs[J].Natural Gas Industry,2011,31(4):51-54.
    [5] 金衍,陈勉,张旭东,等.利用测井资料预测深部地层岩石断裂韧性[J].岩石力学与工程学报,2001,20(4):454-456. Jin Yan,Chen Mian,Zhang Xudong,et al.Determination of fracture toughness for deep well rock with geophysical logging data[J].Chinese Journal of Rock Mechanics and Engineering,2001,20(4):454-456.
    [6] 陈勉,金衍,袁长友.围压条件下岩石断裂韧性的实验研究[J].力学与实践,2001,23(4):32-35. Chen Mian,Jin Yan,Yuan Changyou.Study on the experiment for fracture toughness under confining pressure[J].Mechanics in Engineering,2001,23(4):32-35.
    [8]

    Hucka V,Das B.Brittleness determination of rocks by different methods[J].International Journal of Rock Mechanics and Mining Sciences Geomechanics,1974,11(10):389-392.

    [9]

    Bishop A W.Progressive failure with special reference to the mechanism causing it.Oslo:Proceedings of the Geotechnical Conference,1967.

    [10] 陈颙,黄庭芳.岩石物理学[M].北京:北京大学出版社,2001:9-11. Chen Yong,Huang Tingfang.Rock physics [M].Beijing:Peking University Press,2001:9-11.
    [11] 刘向君,梁利喜,成竹,等.裂缝闭合临界流体压力对油气田开发的影响[J].天然气工业,2005,25(10):89-90. Liu Xiangjun,Liang Lixi,Cheng Zhu,et al.Effects of critical fluid pressure of fracture closure on oil/gas exploitation [J].Natural Gas Industry,2005,25(10):89-90.
    [12] 沈建中.宣页1井钻井技术难点及对策[J].石油钻探技术,2011,39(3):41-45. Shen Jianzhong.Drilling technical difficulties and counter measures in Well Xuanye 1[J].Petroleum Drilling Techniques,2011,39(3):41-45.
    [13] 莫里斯·杜索尔特,约翰·麦克力兰,蒋恕.大规模多级水力压裂技术在页岩油气藏开发中的应用[J].石油钻探技术,2011,39(5):63-67. Maurice Dusseault,John McLennan,Jiang Shu.Massive multi-stage hydraulic fracturing for oil and gas recovery from low mobility reservoirs in China[J].Petroleum Drilling Techniques,2011,39(5):63-67.
    [14] 刘红磊,熊炜,高应运,等.方深1井页岩气藏特大型压裂技术[J].石油钻探技术,2011,39(3):46-52. Liu Honglei,Xiong Wei,Gao Yingyun,et al.Large scale fracturing technology of Fangshen 1 shale gas well[J].Petroleum Drilling Techniques,2011,39(3):46-52.
    [15] 孙海成,汤达祯,蒋廷学.页岩气储层裂缝系统影响产量的数值模拟研究[J].石油钻探技术,2011,39(5):63-67. Sun Haicheng,Tang Dazhen,Jiang Tingxue.Numerical simulation of the impact of fracture system on well production in shale formation[J].Petroleum Drilling Techniques,2011,39(5):63-67.
