Fast Drilling Technique through Igneous Rocks in Well Hashan 3
-
摘要: 为解决准噶尔盆地火成岩地层岩石坚硬、可钻性差、井斜问题突出等技术难点，进行了火成岩地层“PDC钻头+扭转冲击工具”复合钻井技术研究。针对火成岩地层岩性特点和钻井技术难点，通过研制具有较强耐磨性的φ311.1 mm PK6245MJD型PDC钻头，与适合PDC钻头机械剪切破岩机理的SLTIT型扭转冲击工具配合形成了“高效PDC钻头+SLTIT型扭转冲击工具”复合钻井技术，并在哈山3井火成岩地层取得了较好的应用效果。现场应用发现，“φ311.1 mm PK6245MJD型PDC钻头+SLTIT型扭转冲击工具”一次入井连续工作649 h，单趟钻进尺457.50 m，平均机械钻速1.0 m/h，行程钻速0.7 m/h，与相邻上部火成岩井段相比，至少节约了11趟起下钻的时间与钻头费用；同时井斜角由入井前的4.2°（井深2 882.00 m）降至1.2°（井深3 310.00 m），纠斜效果明显。现场应用表明，“φ311.1 mm PK6245MJD型PDC钻头+SLTIT型扭转冲击工具”复合钻井技术是实现准噶尔盆地火成岩地层优快钻井的一种有效技术手段。Abstract: A drilling technique combining PDC bit and torsional impact tool has been developed and applied in drilling through the igneous rocks of Junggar Basin which solves the technical difficulties such as high hardness,poor drillability and serious well deviation,etc in drilling through igneous rock formation.In view of the lithologic characteristics and technical difficulties of igneous rocks,PK6245MJD PDC bit for φ311.1 mm diameter borehole with strong wear resistance was developed,which combined with SLTIT type torsional impact tool suitable for PDC’s rock shear breaking mechanism,forming a composite drilling technique.The technique showed effective performance in drilling igneous rocks in Well Hashan 3.In field application,φ311.1 mm PK6245MJD PDC bit and SLTIT type torsional impact tool reached a continuous working time of 649 h with 457.50 m of drilling footage in one trip.The ROP was 1.0 m/h,and its roundtrip ROP was 0.7 m/h.Compared with the drilling situation of adjacent upper igneous rocks,at least 11 trip times and bit cost were saved.At the same time well deviation dropped from 4.2° at 2 882 m down to 1.2° at 3 310 m.So the composite drilling technique with φ311.1 mm PK6245MJD PDC bit and SLTIT type torsional impact tool is an effective way to realize optimal and fast drilling in igneous rock formations of Junggar Basin.
-
Keywords:
- igneous rock /
- PDC bit /
- torsional impact tool /
- compound drilling /
- Junggar Basin /
- Well Hashan 3
-
-
[1] 易浩,白彬珍,赵志国,等.玉北地区深井快速钻井技术[J].石油钻探技术,2011,39(6):27-30. Yi Hao,Bai Binzhen,Zhao Zhiguo,et al.Faster drilling technology in Yubei Area[J].Petroleum Drilling Techniques,2011,39(6):27-30. [2] 杨明合,夏宏南,蒋宏伟,等.火山岩地层优快钻井技术[J].石油钻探技术,2009,37(6):44-47. Yang Minghe,Xia Hongnan,Jiang Hongwei,et al.Optimized drilling techniques to increase drilling speed in volcanic formations[J].Petroleum Drilling Techniques,2009,37(6):44-47. [3] 赵洪山,冯光通,唐波,等.准噶尔盆地火成岩钻井提速难点与技术对策[J].石油机械,2013,41(3):21-26. Zhao Hongshan,Feng Guangtong,Tang Bo,et al.Difficulties in igneous rock drilling in Dzungaria Basin and technological solutions[J].China Petroleum Machinery,2013,41(3):21-26. [4] 肖国益,胡大梁,廖忠会,等.川西须家河组地层PDC钻头结构参数优化及选型[J].石油钻探技术,2012,40(3):28-32. Xiao Guoyi,Hu Daliang,Liao Zhonghui,et al.Parameter optimization and selection of PDC bits for Xujiahe Formation in Western Sichuan[J].Petroleum Drilling Techniques,2012,40(3):28-32. [5] 张建平.桥古1井快速钻进PDC钻头优化设计与效果分析[J].石油钻探技术,2012,40(6):119-123. Zhang Jianping.Design optimization and effect analysis of fast drilling PDC bit for Well QG-1[J].Petroleum Drilling Techniques,2012,40(6):119-123. [6] 邹德永,曹继飞,袁军,等.硬地层PDC钻头切削齿尺寸及后倾角优化设计[J].石油钻探技术,2011,39(6):91-94. Zou Deyong,Cao Jifei,Yuan Jun,et al.Optimization design of the cutter size and back rake for PDC bit in hard formation[J].Petroleum Drilling Techniques,2011,39(6):91-94. [7] 高航献,瞿佳,曾鹏珲.元坝地区钻井提速探索与实践[J].石油钻探技术,2010,38(4):26-29. Gao Hangxian,Qu Jia,Zeng Penghui.Research and practice to improve drilling speed in Yuanba Area[J].Petroleum Drilling Techniques,2010,38(4):26-29. [8] 张金成,张东清,张新军.元坝地区超深井钻井提速难点与技术对策[J].石油钻探技术,2011,39(6):6-10. Zhang Jincheng,Zhang Dongqing,Zhang Xinjun.Difficulties of improving rate of penetration and its technical solutions in Yuanba Area[J].Petroleum Drilling Techniques,2011,39(6):6-10. [9] 孙起昱,张雨生,李少海,等.钻头扭转冲击器在元坝10井的试验[J].石油钻探技术,2010,38(6):84-87. Sun Qiyu,Zhang Yusheng,Li Shaohai,et al.Application of bit torsional impact generator in Well Yuanba 10[J].Petroleum Drilling Techniques,2010,38(6):84-87. [10] 周燕,安庆宝,蔡文军,等.SLTIT型扭转冲击钻井提速工具[J].石油机械,2012,40(2):15-17,98-99. Zhou Yan,An Qingbao,Cai Wenjun,et al.Model SLTIT torsional impact drilling speedup tool[J].China Petroleum Machinery,2012,40(2):15-17,98-99. [11] 周燕,金有海,董怀荣,等.SLTIDT型钻井提速工具研制[J].石油矿场机械,2013,42(1):67-70. Zhou Yan,Jin Youhai,Dong Huairong,et al.Development of SLTIDT type torsion impact fast drilling tool[J].Oil Field Equipment,2013,42(1):67-70. -
